Unregular

One Port
1. First, make sure that the device is in normal operation.
2. Select the input source, for example, DVI.
3. Connect the cable to any output, for example, OUT-U1/1.
4. Push the [MAP] button (Or push the [MENU] button, and enter to the menu items. Turn the rotary knob, and
select <OUTPUT>, push the knob to confirm. Turn the rotary knob again, and select <LED Display> option).
5. Turn the rotary knob, and select <Unregular> option, push the knob and enter to the unregular menu items.
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
->Regular
Unregular
Set Width
Offset Settings
->Position Settings
Regular
->Unregular
Set Width
Offset Settings
>>
>>
>>
>>
>>
>>
>>
>>
>>
