10. Turn the rotary knob, and select <Offset Settings>, push the knob to confirm, turn the rotary knob, and set
Port 1/2 Offset X, Port 1/2 Offset Y, Port 3/4 Offset Y as 0, and set Port 3/4 Offset X as 128, shown as follows:
11. Turn the rotary knob, and select <Position Settings>, push the knob to confirm, turn the rotary knob, and set
all the parameters as 0, shown as follows:
The connection figure is shown as below:
V 1/2 (Connect Port1 and Port 2, or connect Port 3 and Port 4)
1. First, make sure that the device is in normal operation.
2. Select the input source, for example, DVI.
3. Connect the cable to outputs, for example, OUT-U1/1 and OUT-D1/2.
4. Push the [MAP] button (Or push the [MENU] button, and enter to the menu items. Turn the rotary knob, and
select <OUTPUT>, push the knob to confirm. Turn the rotary knob again, and select <LED Display> option).
