RGBlink G3 NET 2K Quick Start Manual page 28

6. Select <Port 1>, and set the Wall Size W/H and Panel Pixel W/H. For example, set Wall Size W as 3, Wall Size H
as 2, Panel Pixel W as 128 and Panel Pixel H as 256, shown as follows.
7. Turn the rotary knob, and select <Connection Type>, push the knob to confirm. G3 NET 2K support 8 kinds of
connection type, including
8. Turn the rotary knob, and select <Send To Port>, push the knob to confirm. All current settings with the G3
NET 2K are saved to Port 1.
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Port 1
->Wall Size W*H: 1*1
Panel Pixel W*H: 1*1
Connection Type
Port 1
->Wall Size W*H: 3*2
Panel Pixel W*H: 128*256
Connection Type
, ,
Port 1
Wall Size W*H: 3*2
Panel Pixel W*H: 128*256
->Connection Type
e
->Save To Port
Port 2
Wall Size W*H: 1*1
Panel Pixel W*H: 1*1
, , , ,
27
