RGBlink G3 NET 2K Quick Start Manual page 25

Vertical
1. First, make sure that the device is in normal operation.
2. Select the input source, for example, DVI.
3. Connect the cable to outputs, for example, OUT-U1/1 and OUT-D1/2.
4. Push the [MAP] button (Or push the [MENU] button, and enter to the menu items. Turn the rotary knob, and
select <OUTPUT>, push the knob to confirm. Turn the rotary knob again, and select <LED Display> option).
5. Default <Regular> option, push the knob and enter to the regular menu items.
6. Turn the rotary knob, and select <Connection Type>, push the knob to confirm. Turn the rotary again, and
select <Vertical>.
7. Turn the rotary knob, and set <Panel Pixel W*H>. For example, set Panel Pixel W as 128 and Panel Pixel H as
256, shown as follows:
8. Select <Port 1>, and set the Wall Size W/H. For example, set Wall Size W and Wall Size H as 1, shown as
follows.
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
->Regular
Unregular
Set Width
Offset Settings
->Position Settings
->Connection Type
Panel Pixel W*H:
Save to Port
Port 1
->Connection Type
Panel Pixel W*H:
Save to Port
Port 1
Connection Type
->Panel Pixel W*H:
Save to Port
Port 1
>>
>>
>>
>>
>>
Crisscross
1*1
Vertical
1*1
Vertical
128*256
24
