Custom TP Button

1. Push the [MENU] button, and enter to the menu items. Turn the rotary knob, and select <SYSTEM>.
2. Push the knob to confirm. Turn the rotary knob, and select <Customized Button>, push the knob to confirm.
3. Push and turn the rotary knob, TP and BLACK can be selected.
If select <TP>, push [BLACK/TP] button, the button is lit, and enter to the TP menu items.
Port: Select the port.
Test Grid: Select "On" or "Off".
Automatic: The test grid automatically matches the port, based on the LEDs/Row and Column.
Manual size: Set the width and height of each cell in the test grid.
Grid Color: Assign the grid color.
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
BACKUP
TEST PATTERN
->SYSTEM
FACTORY RESET
OLED Brightness
Front Panel Lock
->Customized Button
Tech Support
Customized Button
->TP
->Port
Test Grid
Grid Color
Type
->Test Patterns
Moving
Patterns Color
>>
>>
>>
>>
12
>>
>>
>>
TP
Port 1
Off
Red
Cross
Auto Move
30
White
18
