- Page 6 2. Insert the barrel nuts (#C), use a screwdriver to align the hole for the bolt. Back Front 3. Insert the bolt (#A) into the pre- 1. Align the ends of the lower front side drilled holes along the side and rail (#5) and the lower back side rail (#6) into the barrel nut (#C).
- Page 7 1. Align a guard rail (#20) to the pre-drilled holes along the ends of the front guard rails (#18) and upper front side 2. Align a guard rail (#19) to the pre- rail (#16). Then insert drilled holes along the center of the 4 bolts (#E) and secure rails.
- Page 8 Align the top and bottom of the ladder (#7) to the pre-drilled holes along the front rails. Insert a bolt (#D) into each end from within the rails and secure using the Allen wrench (#K). Apply the twin slat kit (#9) onto the top bunk.
- Page 9 2. Insert a wood dowel (#H) into the pre-drilled holes along the corners of the front panel (#10). 1. Place the front panel (#10) face down. 3. Place the right side (#12) and left side (#11) onto the other end of those wood Note: Right and left is determined dowels (#H).
- Page 10 Align the bottom panel (#14) to the ridges along the sides and carefully slide in. Place the back panel (#13) and insert 2 screws (#G) into each end. Secure using a Phillips screwdriver.
- Page 11 Align the center support (#15) to the pre-drilled holes along the center of the front and back panel (#10/13). Insert a screw (#G) into each end and secure using a screwdriver. From Diagonal Repeat process for second drawer. Make sure all screws and bolts are firmly secured.
