For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-BK589
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 11
(Included)
(Not Included)
Rev: 18-07-2 5
Advertisement
Related Manuals for Furniture of America California CM-BK589
Summary of Contents for Furniture of America California CM-BK589
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-BK589 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 11...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #9 x 1pc Center Front Side Rail Lower End Guardail(L) #2 x 1pc #10 x 2pcs Upper/Center Back Side Rail Lower End Guardail(R)
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #17 x 1pc #19 x 7pcs Short Ladder Rail (R) Ladder Rung #18 x 1pc #20 x 3set Short Ladder Rail (L) Twin Slat Kit #A x 36pcs...
- Page 5 Exploded View Page 5 of 11...
- Page 6 Align side rails (#7,8) to the guardrails (#1,2), then secure by tightening bolts (#A) to barrel nuts (#B). #A x 8pcs #B x 8pcs Insert dowels (#F) to guardrails (#12,13), then align guardrails (#12,13) and side rails (#9,10) to end guardrails (#3,4). Secure by tightening bolts (#A) with barrel nuts (#B).
- Page 7 Align guardrail supports (#14) to the holes of the guardrails (#12,13), then secure by tightening bolts (#D) to hex cap (#J). #D x 9pcs #J x 9pcs Insert dowels (#F) to guardrails (#12,13), then align guardrails (#12,13) and side rails (#10,11) to end guardrails (#5,6). Secure by tightening bolts (#A) with barrel nuts (#B).
- Page 8 Align guardrail supports (#14) to the holes of the guardrails (#12,13), then secure by tightening bolts (#D) to hex cap (#J). #D x 9pcs #J x 9pcs #G x 8pcs Insert metal dowels (#G) before stacking each layer of bunk beds.
- Page 9 Align ladder rungs (#19) to the ladder rails (#15,16), then secure by using screws (#E). #E x 10pcs Align ladder rungs (#19) to the ladder rails (#17,18), then secure by using screws (#E). #E x 4pcs Page 9 of 11...
- Page 10 #C x 14pcs #F x 8pcs Align longer and shorter ladders to the appropriate spot as shown in the diagram, then secure by using bolts (#C). Align slats (#20) to the bunk bed, then secure by using screws (#H). #H x 24pcs Page 10 of 11...
- Page 11 Page 1 1 of 11...
