- Page 6 1. Insert 2 barrel nuts (#I) into the holes along the sides of the lower front/back side rails (#6), then align the ends of those side rails to the lower end guardrails (#3). 2. Insert 2 bolts (#A) into the lower end guardrails (#3) to connect with the rails.
- Page 7 1. Insert 2 barrel nuts (#I) into the ends of the upper front side rails (#4,5) , 1 barrel nut into the ends of the back guard rails (#7), and 1 barrel nut into one end of the front guardrails (#8) with the openings facing the hole.
- Page 8 1. Align (#J) to each end, then insert 2 screws (#F) into the two top holes and secure using a Phillips screwdriver. 2. Prepare 4 bolt assemblies by inserting a washer (#K) onto the bolts (#C). Insert and bolt into each end. Secure using the Allen wrench (#L).
- Page 9 Insert a metal dowel (#G) into the holes along the top of the lower bed. Then carefully place the top bed onto those metal dowels. 1. Align each end the ladder rungs (#14) to the left and right ladder rails (#12,13). 2.
- Page 10 Hook the top of the ladder, then insert a screw (#F) into each hook and secure using a Phillips screwdriver. Make sure all parts are firmly secured.
