User Guide
HARDWARE
Table 3. Default Firmware Mode Configuration, S403 (Labeled uC CFG)
Switch Position
1
2
3
4
1
Mode 15 media converter (default positions for S403 when shipped). All switches off. See
Table 4. ADIN1100 Hardware Configuration, S201 (Labeled HW CFG)
Switch Position Switch Name
1 MEDIA_CNV
2 MACIF_SEL1
3 SWPD_N
4 MACIF_SEL0
5 TX2P4_DIS
6 MS_SEL
7 PHYAD_0
8 PHYAD_1
Table 5. Board LED Indicators
Name Colour Reference Designator
uC0 Green LED400
uC1 Red LED401
uC2 Yellow LED402
uC3 Blue LED403
LED_0 Green LED200
LED_1 Yellow LED201
RJ45 Green P5
RJ45 Yellow P5
POWER Green LED1
analog.com
1
Switch Name
CFG_0
CFG_1
CFG_2
CFG_3
Table
Default Position Description
Off Media converter (only for RMII interface mode, not used on this board)
Off MAC Interface Select 1
Off Software power-down
On MAC Interface Select 0
Off Transmit amplitude 2.4 V disable (always turn this switch on if AVDD_H = 1.8 V
Off Master/slave select (used as preference for autonegotiation)
Off PHY Address 0 for management interface (MDIO)
Off PHY Address 1 for management interface (MDIO)
Description
In media converter mode, uC0 indicates media converter is working and both PHY links are up
Error detected by firmware
Short flash: heartbeat
Long flash or on: receiving UART commands
Reserved
10BASE-T1L link up/activity
In firmware managed modes: 10BASE-T1L transmit amplitude 2.4 V
10BASE-T link up
10BASE-T activity
Board 3.3 V power supply is present
EVAL-ADIN1100
Default Position
Off
Off
Off
Off
6.
Rev. 0 | 6 of 11
