Summary of Contents for EC Line EC-AHT-O1
- Page 1 User Manual EC-AHT-O1 Handheld Terminal...
-
Page 2: Disclaimer
EC Electronics Limited reserves the right to revise this document at any time without prior notice. EC-AHT-O1 User Manual V1.0... -
Page 3: Regulatory Information
The use of accessories that do not satisfy these requirements may not comply with RF exposure requirements, and should be avoided. Hereby, EC Electronics Limited declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. EC-AHT-O1 User Manual V1.0... -
Page 4: Safety Information
When charging, please place the device in an environment that has a normal room temperature and good ventilation. It is recommended to charge the device in an environment with a temperature that ranges from 0°C~40°C. For altitude 2km below use only EC-AHT-O1 User Manual V1.0... -
Page 5: Table Of Contents
Inserting a SIM card ...................... 16 Setting up Mobile Data ....................16 Disconnect Mobile Data ....................17 6. Using NFC ........................18 Reading a NFC Tag ....................... 18 Enable NFC ........................18 Disable NFC ........................19 EC-AHT-O1 User Manual V1.0... -
Page 6: Product Specifications
E3 2D Barcode Scanner Buttons Power Button Multi-function Button Microphone 1pcs Speaker 1pcs System I/O connector Type-C Ver 5.0 WLAN IEEE 802.11 ac/a/b/g/n, 2.4G/5G Printer 2" printer Thermal paper Width 57 mm, Diameter 40 mm Charger 1, 5V2A EC-AHT-O1 User Manual V1.0... - Page 7 ③ Close the cover of the paper container to finish printing paper feeding. Note: If the printed paper is blank, please check whether the paper roll has been installed in the correct direction. EC-AHT-O1 User Manual V1.0...
- Page 8 Scan QR Code (Optional) 2D Scanner Rear Camera Supports photographing and 1D/2D code quick scanning SIM Card Slot MicroSIM card slot (SIM 1 & SIM 2) Battery Connector Connect the battery Battery 3.6V 5200mAh battery EC-AHT-O1 User Manual V1.0...
-
Page 9: Getting Started
Soft reset shuts down and reboots the device. It preserves installed applications, settings, and saved data. To perform a soft reset: 1. Open the rear cover. 2. Unplug the battery connector and plug in again. 3. The terminal shuts down and reboots. Battery Connector EC-AHT-O1 User Manual V1.0... -
Page 10: Fixing The Phone Strap
Fixing the Phone Strap An optional phone strap is available for the terminal. To fix the phone strap on the terminal: 1. Turn over the terminal. 2. Tight the phone strap into the phone strap hole EC-AHT-O1 User Manual V1.0... -
Page 11: Using Wi-Fi
2. Select a network from the AP list, input the network password, and click Connect. Once connected, it displays Connected under the network name, also shows the WIFI symbol on the right top of the screen. EC-AHT-O1 User Manual V1.0... -
Page 12: Disconnecting From A Wi-Fi Network
Go to “Settings”, choose ‘Network & Internet”, choose WIFI, your selected network shows connected. Click the select network and choose “Forget”, then it will not shown “Connected” on the AP list. If needs to re-connect the previous AP after the above step is made, repeat step 4.1. EC-AHT-O1 User Manual V1.0... -
Page 13: Using Bt
3. Turn on the “BT”, select a device from the BT device list. A “BT pairing code” will appear on the terminal and the selected device, click “Pair” on both devices. Once paired, the connected device will shown on the “Currently connected” page. Note: Some BT devices may require software driver installation. EC-AHT-O1 User Manual V1.0... -
Page 14: Disconnecting A Bt Device
4.2 Disconnecting a BT Device To disconnect a BT Device: 1. Go to “Settings”, choose ‘Connected Device”, select “Connection Preferences”, Click “BT” and switch it off. EC-AHT-O1 User Manual V1.0... -
Page 15: Disconnecting The Selected Ap Name From A Wi-Fi Network Permanently
4.3 Disconnecting the Selected AP Name from a Wi-Fi Network Permanently 1. Go to “Settings”, choose ‘Connected Device”, select “Previously Connected Device”, choose the setting icon of connected device that needs to disconnect permanently, click “Forget” and “Forget Device”. EC-AHT-O1 User Manual V1.0... -
Page 16: Using Cellular
1. Go to “Settings”, choose ‘Network & Internet”, turn on the “SIM Slot 1 or 2” that had installed the SIM card, enable the “Mobile Data” and “Automatically Select Network”. 2. Mobile data will be connect automatically EC-AHT-O1 User Manual V1.0... -
Page 17: Disconnect Mobile Data
5.3 Disconnect Mobile Data Go to “Settings”, choose ‘Network & Internet”, turn off the “SIM Slot 1 or 2”. EC-AHT-O1 User Manual V1.0... -
Page 18: Using Nfc
6. Using NFC EC-AHT-O1 is equipped with an NFC controller operating at 13.56MHz for reading and writing NFC tags. It supports the following protocols: ISO 14443 A/B MIFARE Felica NFC Forum Tags ISO 15693 Reading a NFC Tag NFC is turned on by default. -
Page 19: Disable Nfc
Disable NFC 1. Go to “Settings”, choose ‘Connected Device”, select “Connection Preferences”, Click “NFC” and switch it off. - End of Document - EC-AHT-O1 User Manual V1.0... - Page 20 Manufacturer: EC LINE Thank you very much for using EC Line product For service, please contact service@ecline.com.hk www.eclinepos.com www.ecline.com.hk EC-AHT-O1 User Manual V1.0...
