EC Line EC-15i5 User Manual

All-in-one touch pos terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
EC-15i5
All-in-one Touch POS Terminal

Advertisement

Table of Contents
loading

Related Manuals for EC Line EC-15i5

Summary of Contents for EC Line EC-15i5

  • Page 1 User Manual EC-15i5 All-in-one Touch POS Terminal...

  • Page 2: Safety Information

    When the following occurs: Liquid gets inside the POS terminal; Accidental physical damage; POS terminal produces a burning smell; immediately disconnect the power supply, unplug the power cord, and contact a qualified service technician. EC-15i5 User Manual...

  • Page 3: Electromagnetic Compatibility Statement

    T h i s p r o d u c t s h o u l d n o t b e m i x e d w i t h o t h e r c o m m e r c i a l w a s t e s f o r d i s p o s a l . EC-15i5 User Manual...
  • Page 4 , r e p r o d u c e d o r t r a n s l a t e d t o a n o t h e r l a n g u a g e w i t h o u t t h e p r i o r w r i t t e n c o n s e n t o f t h e m a n u f a c t u r e r . EC-15i5 User Manual...

  • Page 5: Specifications

    L E D I n d i c a t o r s L E D I n d i c a t o r s L E D I n d i c a t o r s P o w e r ( R e d ) EC-15i5 User Manual...

  • Page 6: Optional Peripherals

    C e r t i f i c a t e s a t e s a t e s F C C C l a s s A / C E / R o H S EC-15i5 User Manual...
  • Page 7 3 . P o w e r A d a p t o r 4 . A C P o w e r C o r d EC-15i5 User Manual...

  • Page 8: About Your System

    Unplug the AC power of the adapter before opening any part of the system since the standby power is always on whenever the adapter is plugged in. It may cause permanent damage to your system when you open any part of it. Front View Power USB 2.0 Button EC-15i5 User Manual...
  • Page 9 Rear View Cable Cover Slot for installing Slot for installing Magnetic Card Custom Display or Reader (Optional) Second Display (Optional) VESA 75 VESA 100 EC-15i5 User Manual...
  • Page 10 It may cause permanent damage to your system when you open any part of it. As illustrated in the following Release the screw Move these two sides upward EC-15i5 User Manual...
  • Page 11 The connector panel 1. TOP of machine Power IN USB 2.0 COM1 Hard Disk 1 USB 3.0 COM3 Microphone COM4 Hard Disk 2 Earphone COM2 RJ11 PS/2 2. Bottom of machine USB 2.0 Power Button EC-15i5 User Manual...

  • Page 12: Setting Up Your System

    2 . O p e n t h e c a b l e c o v e r a n d h i n g e c o v e r 3. Plug in all the cable on the ports 4. Through the cable between hinge and foot EC-15i5 User Manual...
  • Page 13 Magnetic Card R Magnetic Card R eader (MSR) eader (MSR) 1. Remove the rubber mat. Loosen the screw and remove the MSR cover 2. Connected to the cable on the MSR and host, then lock two screws EC-15i5 User Manual...
  • Page 14 3. Installation VFD cover and lock the two screws Note: Provides VFD DC + 5V . If use COM3, see Page 72, COM4, see Page 71 If use COM1, COM2, change UART1 and UART2 RI Function , see Page 32 EC-15i5 User Manual...
  • Page 15 Installing Second Display 1. Remove the metal bezel 2. Connected the cable, lock the two screws on cable cover 3. Installation VFD cover and lock the two screws Replace and Installing Hard Disk EC-15i5 User Manual...
  • Page 16 1. Release the screw 2. Move these two sides upward Grab the handle and pull up or down 3. Release the screw Remove or Installation hard disk Replace and Installing Memory EC-15i5 User Manual...
  • Page 17 Release the screw Grasp the both sides, and pulled down the back cover Replace or Install the memory EC-15i5 User Manual...
  • Page 18 1. Release the screw 2. Grasp the both sides, and pulled down the back cover 5. Install WIFI Card Lock 2 screws 3. Remove the plastic pad on the both sides of the Main cover 4. Install Antenna EC-15i5 User Manual...

  • Page 19: Bios Setting

    When starting up the computer, press <Del> during the Power-On Self-Test (POST) to enter the UEFI BIOS setup utility. In the UEFI BIOS setup utility, it can find the General Help description at the top right corner, and this is providing a brief description of the selected item. Navigation Keys for EC-15i5 User Manual...
  • Page 20 The content of this manual is subject to be changed without notice. We will not be responsible for any mistakes found in this user’s manual and any system damage that may be caused by wrong-settings EC-15i5 User Manual...
  • Page 21 Shows system memory size, VGA shard memory will be excluded System Date Set the system date. Note that the ‘Day’ automatically changes when you set the date System Time Set the system internal clock Access Level Shows the access level of current user EC-15i5 User Manual...

  • Page 22: Advanced Menu

    Enables or disables boot options for legacy mass storage devices with option ROM. Options: Enabled (Default) / Disabled Launch Video OpROM Enables or disables execution of the legacy option ROM for video devices. Options: Enabled (Default) / Disabled / Enabled when no UEFI Driver EC-15i5 User Manual...

  • Page 23: Pci Subsystem Settings

    Options: 32 PCI Bus Clocks (Default) / 64 PCI Bus Clocks / 96 PCI Bus Clocks / 128 PCI Bus Clocks / 160 PCI Bus Clocks / 192 PCI Bus Clocks / 224 PCI Bus Clocks / 248 PCI Bus Clocks VGA Palette Snoop Enables or disables VGA palette registers snooping Options: Disabled (Default) / Enabled EC-15i5 User Manual...

  • Page 24: Pci Express Settings

    Options: Disabled (Default) / Enabled Extended Tag Enabled allows device to use 8-bit tab field as a requester Options: Disabled (Default) / Enabled No Snoop Enables or disables PCI Express Device no snoop option Options: Enabled (Default) / Disabled EC-15i5 User Manual...
  • Page 25 Value range is from 10 to 1000 Options: 100 (Default) Unpopulated Links In order to save power, software will disable unpopulated PCI Express links, if this option set to ‘Disable Link’ Options: Keep Link ON (Default) / Disable Link EC-15i5 User Manual...

  • Page 26: Acpi Settings

    Options: S1 (CPU Stop Clock) (Default) / Suspend Disabled / S3 (Suspend to RAM) Lock Legacy Resources Enables or disables lock of legacy resources Options: Disabled (Default) / Enabled S3 Video Repost Enables or disables S3 Video Repost Options: Disabled (Default) / Enabled EC-15i5 User Manual...
  • Page 27 Options: Disabled (Default) / Ctrl + Esc / Ctrl + F1 / Ctrl + Space / Any Key / Wake Key / Power Key / Ctrl + Alt + Space / Space PS2 Mouse PowerOn Control the mouse power on function Options: Disabled (Default) / Enabled EC-15i5 User Manual...

  • Page 28: Cpu Configuration

    OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3.) Options: Enabled (Default) / Disabled Intel Virtualization Technology Virtualization Technology can virtually separate your system resource into several parts, thus enhance the performance when running virtual machines or multi interface systems. Options: Disabled (Default) / Enabled EC-15i5 User Manual...
  • Page 29 Offset from the factory TCC activation temperature Options: 0 (Default) CPU Max Current limit value (Amp) The Maximum instantaneous current allow for Primary Plane IGFX Max Current limit value (Amp) The Maximum instantaneous current allow for Secondary Plane EC-15i5 User Manual...

  • Page 30: Sata Configuration

    SATA Configuration SATA Controller(s) Enables / disables Serial ATA Device. Options: Enabled (Default) / Disabled SATA Mode Selection Determines how SATA controller(s) operate. Options: IDE (Default) / AHCI Note: mSATA function is optional EC-15i5 User Manual...

  • Page 31: Usb Configuration

    XHCI driver Options: Enabled (Default) / Disabled EHCI Hand-Off This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver Options: Disabled (Default) / Enabled Port 60/64 Emulation EC-15i5 User Manual...
  • Page 32 “Auto” uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor Options: Auto (Default) / Manual Device power-up delay in seconds Delay range is 1 ~ 40 seconds, in one second increments. Options: 5 (Default) EC-15i5 User Manual...

  • Page 33: Serial Port 1 Configuration

    F81866 Super IO Configuration Serial Port 1 Configuration Serial Port Enables or disables Serial Port (COM) Options: Enabled (Default) / Disabled Change Settings EC-15i5 User Manual...

  • Page 34: Serial Port 2 Configuration

    Options: Auto (Default) / IO=2F8h; IRQ=3 / IO=3F8h; IRQ= 3, 4, 5, 6, 7,10, 11, 12 / IO=2F8h; IRQ= 3, 4, 5, 6, 7,10, 11, 12 / IO=3E8h; IRQ= 3, 4, 5, 6, 7,10, 11, 12 / IO=2E8h; IRQ= 3, 4, 5, 6, 7,10, 11, EC-15i5 User Manual...

  • Page 35: Serial Port 3 Configuration

    Options: Enabled (Default) / Disabled Change Settings Selects an optimal setting for Super IO device Options: Auto (Default) / IO=2C0h; IRQ=6 / IO=3F8h; IRQ=6 / IO=2F8h; IRQ=6 / IO=2C0h; IRQ=6 / IO=2C8h; IRQ=6 / IO=2D0h; IRQ=6 / IO=2D8h; IRQ=6 EC-15i5 User Manual...

  • Page 36: Serial Port 4 Configuration

    Options: Enabled (Default) / Disabled Change Settings Selects an optimal setting for Super IO device Options: Auto (Default) / IO=2C8h; IRQ=6 / IO=3F8h; IRQ=6 / IO=2F8h; IRQ=6 / IO=2C0h; IRQ=6 / IO=2C8h; IRQ=6 / IO=2D0h; IRQ=6 / IO=2D8h; IRQ=6 EC-15i5 User Manual...

  • Page 37: Serial Port 5 Configuration

    Options: Enabled (Default) / Disabled Change Settings Selects an optimal setting for Super IO device Options: Auto (Default) / IO=2D0h; IRQ=6 / IO=3F8h; IRQ=6 / IO=2F8h; IRQ=6 / IO=2C0h; IRQ=6 / IO=2C8h; IRQ=6 / IO=2D0h; IRQ=6 / IO=2D8h; IRQ=6 EC-15i5 User Manual...

  • Page 38: Serial Port 6 Configuration

    Options: Auto (Default) / IO=2D8h; IRQ=6 / IO=3F8h; IRQ=6 / IO=2F8h; IRQ=6 / IO=2C0h; IRQ=6 / IO=2C8h; IRQ=6 / IO=2D0h; IRQ=6 / IO=2D8h; IRQ=6 UART IRQ Mode Allows you to determine PCI IRQ sharing for OS (EX. Windows) ISA IRQ for DOS. Options: PCI IRQ Sharing (Default) / ISA IRQ EC-15i5 User Manual...

  • Page 39: Parallel Port Configuration

    UART1 RI Function Selects COM1 port pin 9 function Options: RING (Default) / +5V / +12V UART2 RI Function Selects COM2 port pin 9 function Options: No any function (Default) / +5V / +12V Watch Dog Degree EC-15i5 User Manual...
  • Page 40 Allows you to determine the functional degree of Watch Dog Options: Second (Default) / Minute Watch Dog Timer Options: 0 for disabled (Default) / Min=1, Max=65536 Audio AMP Adjusts external audio amplifier Options: +11dB (Default) / +14dB / +19dB / +25dB EC-15i5 User Manual...
  • Page 41 Allows you to set up the CPU shutdown Temperature Options: Disabled (Default) / 70°C/158°F / 75°C/167°F / 80°C/176°F / 85°C/185°F / 90°C/194°F Smart Fan Function Allows you to control the CPU Smart Fan function Options: Disabled (Default) / Enabled EC-15i5 User Manual...

  • Page 42: Cpu Ppm Configuration

    Options: Disabled (Default) / Enabled Long duration power limit Long duration power limit in watts, 0 means factory default Options: 120 (Default) Long duration maintained Time window which the long duration power is maintained Options: 28 (Default) Short duration power limit EC-15i5 User Manual...
  • Page 43 Short duration power limit in watts, 0 means factory default Options: 150 (Default) ACPI T State Enables / disables ACPI T state support Options: Disabled (Default) / Enabled EC-15i5 User Manual...

  • Page 44: Chipset Menu

    I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components ▶ ▶ ▶ ▶ Note » Beware of that setting inappropriate values in items of this menu may cause system problem PCH-IO Configuration EC-15i5 User Manual...

  • Page 45: Pci Express Configuration

    Options: Enabled (Default) / Disabled ASPM Set PCI Express Active State Power Management settings Options: Auto(Default) / Disabled / L0s / L1 / L0sL1 PCIe Speed Selects PCI Express port speed Options: Auto (Default) / Gen1 / Gen2 EC-15i5 User Manual...
  • Page 46 Set the mode of operation of XHCI controller Options: Smart Auto (Default) / Auto / Enabled / Disabled EHCI1/2 Controls the USB EHCI (USB2.0) functions. One EHCI controller must always be enabled Options: Enabled (Default) / Disabled EC-15i5 User Manual...
  • Page 47 When EuP Enabled, System meets EuP requirement Options: Disabled (Default) / Enabled SLP_S4# Min. Assertion Width Options: 4 to 5 seconds (Default) / 1 to 2 seconds / 3 to 4 seconds / 2 to 3 seconds / Disabled EC-15i5 User Manual...

  • Page 48: System Agent (Sa) Configuration

    System Agent (SA) Configuration Graphics Configuration Primary Display Selects which of IGFX / PEG / PCI Graphics device should be Primary Display or select SG for Switchable Gfx Options: Auto (Default) / IGFX / PEG Internal Graphics EC-15i5 User Manual...
  • Page 49 Selects DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device Options: 256MB (Default) / 128MB / MAX Gfx Low Power Mode Applicable for SFF only Options: Disabled (Default) / Enabled Graphics Performance Analyzers Enables/ disables Intel graphics performance analyzers counters Options: Disabled (Default) / Enabled EC-15i5 User Manual...

  • Page 50: Lcd Control

    Selects the LCD panel scaling option used by the Internal Graphics Device Options: Auto (Default) / Force Scaling / Off LVDS Brightness Selects the LCD panel brightness percentage Backlight Control Selects Back Light Control Setting Options: Backlight Inverted (Default) / Backlight Normal Spread Spectrum clock Chip EC-15i5 User Manual...
  • Page 51 Selects the Active LVDS Configuration. No LVDS: VBIOS does not enable LVDS; Int-LVDS: VBIOS enables LVDS driver by integrated encoder Options: Int-LVDS (Default) / No LVDS Panel Color Depth Selects the LFP Panel Color Depth Options: 18Bit (Default) / 24Bit EC-15i5 User Manual...
  • Page 52 Memory Configuration Memory Insight DDR3_A1 / B1 Information EC-15i5 User Manual...
  • Page 53 Options: 9 (Default) / 3 ~ 15 Row Precharge Time (tRP) Selects Row Precharge Time of DDR3 Options: 9 (Default) / 3 ~ 15 RAS# Active Time (tRAS) Selects Row Active Time of DDR3 Options: 24 (Default) / 9 ~ 63 EC-15i5 User Manual...
  • Page 54 Options: Dynamic (Default) / 1 GB / 1.25 GB / 1.5 GB / 1.75 GB / 2 GB / 2.25 GB / 2.5 GB / 2.75 GB / 3 GB / 3.25 GB Memory Scrambler Enables or disables memory scrambler support Options: Enabled (Default) / Disabled MRC Fast Boot Enables or disables MRC Fast Boot Options: Enabled (Default) / Disabled EC-15i5 User Manual...
  • Page 55 Set control memory scrambler seed generation Enable – do not generation scrambler seed. Disable – generation scrambler seed always Options: Disabled (Default) / Enabled Memory Remap Enables or disables memory remap above 4G Options: Enabled (Default) / Disabled EC-15i5 User Manual...
  • Page 56 If enabled, BIOS will skip EFI VGA driver Options: Disabled (Default) / Enabled Skip USB If enabled, USB devices will not be available until after OD boot. If disabled, USB device will be available before OS boot EC-15i5 User Manual...
  • Page 57 Boot Success Beep When this item is set to Enabled, BIOS will let user know boot success with beep Options: Enabled (Default) / Disabled UEFI Boot nables / disables boot from the UEFI Devices Options: Disabled (Default) / Enabled EC-15i5 User Manual...

  • Page 58: Security Menu

    Security Menu Administrator Password Set Administrator Password User Password Set User Password EC-15i5 User Manual...

  • Page 59: Discard Changes And Exit

    Abandon all changes made during the current session and exit setup Save Changes and Reset Reset the system after saving the changes Restore Defaults Reload the BIOS when problem occurs during system booting sequence. These configurations are factory settings optimized for this system EC-15i5 User Manual...

  • Page 60: Rear Panel Connectors

    8. Mainboard Setting Rear Panel Connectors DC-12V Input Connector RJ-11 pin assignment COM1 Connector COM2 Connector EC-15i5 User Manual...
  • Page 61 »» Note1: COM1/2 voltage selection is controlled by BIOS setup. Please see page-34 for detail setting »» Note2: COM1 RS-232/422/485 selection is controlled by JSEL1/JSEL2. Please see page-14 for detail setting »» Note3: COM3 voltage selection is controlled by JPC3. Please see page-15 for detail setting EC-15i5 User Manual...

  • Page 62: Motherboard Layout

    Motherboard Layout ▶ ▶ ▶ ▶ Note »» ■ represents the 1 EC-15i5 User Manual...

  • Page 63: Installing Central Processing Unit (Cpu)

    Step 3: Align the gold triangle on the CPU with the similar marking on the socket. If the processor does not drop completely into the socket, turn the socket actuator to the open position until the processor drops completely plugged in EC-15i5 User Manual...
  • Page 64 4. Tighten each screw halfway to secure the cooler assembly to the motherboard. Then gradually tighten all four screws. Do not fully tighten the first screw before partially tightening the other screws EC-15i5 User Manual...

  • Page 65: Connect Cooling Fans

    System Fan Headers support 3-pin head connectors. When connecting with wires onto connectors, please note that the red wire is the positive nd should be connected to pin#2, and the black wire is Ground and should be connected to GND EC-15i5 User Manual...

  • Page 66: Installing System Memory

    2. Insert the DIMM firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated DIMM Socket Location DDR3 Module Total Memory Size DIMMA1 512MB/1GB/2GB/4GB Max is 8GB DIMMB1 512MB/1GB/2GB/4GB EC-15i5 User Manual...

  • Page 67: Expansion Slots

    PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins PE1: Mini PCI-E Slot (mSATA function is optional) EC-15i5 mainboard is equipped with 1 Mini PCI-E Slot JSIM1: SIM card header EC-15i5 mainboard is equipped with one SIM card header for Mini PCI-E Slot EC-15i5 User Manual...

  • Page 68: Power Supply

    Power Supply JPWR1: ATX Power Source Connector (4-pin) Provides or +12V input to system power circuit JHDD1: HDD Power Connector Provides power connection of SATA devices JP12V: 12V Output Power Connector Provides power connection of 12V output EC-15i5 User Manual...

  • Page 69: Jumpers / Headers / Connectors

    Pin opened Pin closed Pin 1-2 closed JCMOS1: Clear CMOS Jumper Placing the jumper on pin2-3 allows user to restore the BIOS safe setting and the CMOS data. Carefully follow the procedures to avoid damaging the motherboard EC-15i5 User Manual...
  • Page 70 This 10-pin header includes Power-on, Reset, HDD LED, and Power LED connection. It allows user to connect the system case’s front panel switch functions SATA1/SATA2: Serial ATA 6.0 Gb/s Connectors Supports the thin Serial ATA cable for primary internal storage devices EC-15i5 User Manual...
  • Page 71 F_USB1/2/3: USB 2.0 Header EC-15i5 mainboard provides USB 2.0 pin header. Each header allows you to connect 2 additional USB 2.0 ports Serial Port Connectors & Headers JSEL1/JSEL2: RS-232/422/485 Switch Headers for COM1 Determine the COM1 belongs to RS-232 (Default), 422, or 485...
  • Page 72 JCOM4: Serial Port Header JPC4: Serial Port Voltage Switch Jumper for JCOM4 EC-15i5 User Manual...
  • Page 73 JCOM3/JCOM5/JCOM6: Serial Port Headers (The board has built-in COM3 , no JCOM3 Connector) JPC3/JPC5/JPC6: Serial Port Voltage Switch Jumpers for JCOM3/JCOM5/JCOM6 EC-15i5 User Manual...
  • Page 74 JVGA1: VGA Connector (Optional) This header allows you to connect VGA JC1: LCD Backlight Inverter Connector For connecting to LCD for providing backlight control function. It is strongly recommended to use the matching JOY DAY INDUSTRIAL - A1250WV-S-8P connector EC-15i5 User Manual...
  • Page 75 LVDSB_DATA0_P PVDD2, 3.3V/5V (selected by JLV2) LVDSB_DATA1_N LVDSB_DATA1_P LVDSA_DATA0_N LVDSA_DATA0_P LVDSB_DATA2_N LVDSB_DATA2_P LVDSA_DATA1_N LVDSA_DATA1_P LVDSB_CLK_N LVDSB_CLK_P LVDSA_DATA2_N LVDSA_DATA2_P LVDSB_DATA3_N LVDSB_DATA3_P LVDSA_CLK_N LVDSA_CLK_P LVDSA_DDC-CLK +3.3V LVDSA_DATA3_N LVDSA_DATA3_P PVDD2, 3.3V/5V (selected by JLV2) PVDD2, 3.3V/5V (selected by JLV2) LVDSA_DDC_DATA EC-15i5 User Manual...
  • Page 76 JLV1: LCD Backlight Inverter Power Select Jumper For selecting LCD Backlight Inverter Power JLV2: LCD Panel Power Select Jumper For selecting LCD Power(PVDD2) EC-15i5 User Manual...
  • Page 77 This onboard header is for cash drawer function, but when it is in use, you cannot use the I/O RJ11 connector JP2: Voltage Switch Header for Cash Draw Connector For controlling the Pin4 of RJ11 (JRJ11) to switch 12V or 24V EC-15i5 User Manual...
  • Page 78 Offers 4-pair of digital I/O functions and address is set in BIOS Assignment Address GPIO DI-01 548H GPIO71 BIT7 DO-01 50CH GPIO7 BIT7 DI-02 548H GPIO70 BIT6 DO-02 50CH GPIO6 BIT6 JMSR1: MSR Connector DI-03 548H GPIO69 The mainboard provides MSR connector BIT5 EC-15i5 User Manual...
  • Page 79 JMSRS1/JMSRS2: MSR Jumper Enables or disable MSR connector function. EC-15i5 User Manual...

  • Page 80: Before Starting

    If use USB interface or device driver, please install device driver before starting the software. If the connection is OK, execute the software 7.1.1 Select a proper interface After starting the software, the following dialog will pop up. Select a proper interface EC-15i5 User Manual...
  • Page 81 RS-232 interface. After all items are set to desired condition, press SET button to send all the settings to your device. These settings will be stored on the non-volatile memory. Every time when start the device, these settings will be retrieved from non-volatile memory EC-15i5 User Manual...
  • Page 82 Character Set(20h-7Fh) Code Table (80H-FFH) Default U.S.A PC-437 (USA, Standard Europe) France Germany U.K. PC-858 Denmark I Sweden Italy Spain Reserved Norway PC-858 Denmark II U.S.A Slavonic U.S.A Russia U.S.A PC-860 (Portuguese) U.K. Greek User Font EC-15i5 User Manual...

  • Page 83: Baud Rate Selection

    There are three ways to create the font 7.4.1 From an Existing Font See the following dialog by pressing “Open Exist Font” button Select a font to be your font base and modify it to fit your requirement EC-15i5 User Manual...
  • Page 84 “Reload font” button to load the font again. All the modification will be lost after reloading font. Press “Reset” button also let you abandon current modification and restart the whole operation. EC-15i5 User Manual...
  • Page 85 After finishing your edit, it can save font to a file or download the font to device. It is a difficult job to build font from zero and highly recommended to build your font from existing font. EC-15i5 User Manual...

  • Page 86: Software Setting Command

    [02][05][67] n [03] [02] [05] [69] [78] [03] n=49,51,55 Hex. Format [02h][05h][43h] n [03h][02h][05h][45h][4eh][03h] n=31h,33h,37h Description Change the command type and initialize the display Command type Command type ESC/POS UTC/P ADM787/788 (option) UTC/S DSP-800 (option) CD5220 EMAX (AEDEX) EC-15i5 User Manual...

  • Page 87: International Character Set Setting Command

    Character Set (20h– Code Table (80H-FFH) 7Fh) U.S.A. PC-437 (USA, Standard Europe) France Germany U.K. PC-858 Denmark I Sweden Italy Spain Reserved Norway PC-858 Denmark II U.S.A. Slavonic U.S.A. Russia U.S.A. PC-860 (Portuguese) U.K. Greek User Font EC-15i5 User Manual...

  • Page 88: Esc/Pos Mode Command Set

    1F 3B n Specify semicolon n=a displayable character code (period + comma) ESC & s n m 1B 26 1 n m [a(p1..pa)]x m-n+1 21h Define download characters. ≦ [a(p1..pa)]x F Fh; 1 ≦ ≦ ≦ ≦ EC-15i5 User Manual...
  • Page 89 French) Page 5, (PC865, Nordic) Italy Spain Page 6, (Slavonic) Japan Page 7, (Russian) Norway Page 8, (PC858, +Euro symbol) Denmark II Page 9, (WPC1252) Table 5-B Select code table Slavonic Russia Table 5-A Select International font EC-15i5 User Manual...

  • Page 90: Emax (Aedex) Mode Command Set

    4. UTC Mode Command Set UTC/S (STANDARD) Command Code (hex) Function Description Back space Horizontal tab Line feed Carriage return 10 n 00h 2 7h Display cursor position ≦ ≦ Over write display mode Vertical scroll mode Cursor on Cursor off EC-15i5 User Manual...

  • Page 91: Cd5220 Mode Command Set

    ESC [ B 1B 5B 42 Move cursor down Move cursor down ESC [ H 1B 5B 48 Move cursor to home position Move cursor to home position ESC [ L 1B 5B 4C Move cursor to top-left position EC-15i5 User Manual...
  • Page 92 Select code (see Note 4) ESC = n 1B 3D n Select peripheral device n=01, 02h, 03h n=01h, select printer n=02h, select display n=03h, select printer + display ESC s 1 1B 73 01 Store the user defined character into EEPROM. EC-15i5 User Manual...
  • Page 93 4. The parameters of the code table control command “ESC c n”. Parameter “n” International Font Set A ’ Compliance with ASCII code ‘ L ’ Compliance with SLOVONIC code ‘ R ’ Compliance with RUSSIA code ‘ EC-15i5 User Manual...

  • Page 94: Character Set

    Denmark I bit 4=0 Sweden Show mode Italy Spain bit 0=1 Show mode 1 Japan bit 1=1 Show mode 2 Norway Table 5-D Layer table for saving data Denmark II Character Set Table 5-C International Font Set EC-15i5 User Manual...

  • Page 95: Character Code (20H-7Eh)

    1. Character Code (20h-7Eh) 1.1 USA Standard Character Set 1.2 International Character Set 2. Character Code Page (80h-FFh) EC-15i5 User Manual...
  • Page 96 2.1 Page 0 PC437: USA, Standard Europe 2.2 Greek EC-15i5 User Manual...
  • Page 97 2.3 Page 2 PC850: Multilingual 2.4 Page 3 PC860: Portuguese EC-15i5 User Manual...
  • Page 98 2.5 Page 4 PC863: Canadian-French 2.6 Page 5 PC865: Nordic 2.7 Page 6 Slavonic 2.8 Page 7 Russia EC-15i5 User Manual...
  • Page 99 2.9 Page 19 PC858: Multilingual + Euro Symbol EC-15i5 User Manual...
  • Page 100 2.10 Page 16 WPC1252: West European Latin EC-15i5 User Manual...
