  • Page 1 User Manual EC-1530 All-in-one Touch POS Terminal...

  • Page 2: Table Of Contents

    1.2. Safety Information： ................2 1.3 Electromagnetic compatibility statement: ......... 4 Chapter II: Installation Guide ................ 4 2.1 EC-1530 Appearances: ............... 4 2.2 The front panel Function definition: ......5 2.3 The rear panel I/O signs and description: ........5 Chapter III: Instructions for use ..............

  • Page 3: Chapter I: Overview

    Chapter I: Overview Dear customer： Thank you for purchasing the EC Line All - In One touch POS devices, we are committed to continuously improve the product quality and provide better after-sales service. In order to take full advantage of our devices, we strongly recommend that you take the time to read this manual before diving into software solution.
  • Page 4  Tunr off the power before connecting any devices (except USB device) to the terminal.  Do not attempt to open the chassis .You may be hurt by electric shock.For service,call your place of purchase.  Please do not leave any item or liquid into the product, do not place any objects into the ventilation holes of this product, it may cause short-circuit of the internal components and cause a fire or electric shock.

  • Page 5: Electromagnetic Compatibility Statement

     This product is in full compliance with the relevant requirements of the the People's Republic of China’s national standards of (GB/17625.1-2003) “Electromagnetic Compatibility Limits for harmonic current emission limits” for Class B products . Chapter II: Installation Guide 2.1 EC-1530 Appearances:（MSR and VFD mounting optional）...

  • Page 6: The Rear Panel I/O Signs And Description

    12V DC in:power supply for pos 12V DC out: 12V DC output to other device EC-1530 series of products using the manual handle design which is able to be adjusted within the range of 0 degrees to 90 degrees, the operation is more humane.

  • Page 7: Chapter Iii: Instructions For Use

    Chapter III: Instructions for use 3.1 Motherboard BIOS settings: The POS device has a BIOS (Basic Input Output System) chip on the motherboard. Every time you start the POS devices, the system will first run the BIOS self - test program, to check the main components of the system to ensure it is working properly.
  • Page 8 <F7> To load the last set of values <F8> To load the safest value <F9> To load the optimal value <F10> To store settings and exit the CMOS SETUP program Step 1: Select Load Default Settings to restore optimized default settings CMOS Setup Utility- copyright (c)1985-2008 BIOS Setup Utility- copyright (c)1985-2008 Main...
  • Page 9 WARNING: setting wrong values in the below sections may cause system to Malfunction Advanced setup CPU Configuration IDE Configuration Configure CPU USB Configuration COM/LPT Configuration Hardware monitor Power management ↑↓→←: Move +/-:Value Enter : select F10:Save and Exit F9 : load Defaults Settings F1:General Help Esc : Exit Step 4: Select Boot...

  • Page 10: Touch Screen Driver Installation

    Step 6: Select the menu unit exit North Bridge Configuration Help Ttem Memory Frequency 800MHZ Total Memory 2048MB Configure North Share Memory Size Bridge features DVMT Mode Select DVMT Mode DVMT/FIXED Memory 256MB South Bridge Configuration HD Audio controller Enlabled USB Function Enlabled On board LAN2 Controller...
  • Page 11 Step 2: Double-click the installation as the following figure shows, click Next to proceed to the next installation. Step 3: Install In progress...
  • Page 12 Step 4: Tick “install PS / 2 interface driver” and click Next to proceed installation. Step 5: If the touch interface is RS232, tick “install RS232 interface driver” and click Next to proceed installation.
  • Page 13 Step 6: When choosing the calibrations, select NONE, click Next to proceed installation. Step 7: When installing USB touch, please connect the USB controller and USB cable...
  • Page 14 Step 8: When there are two or more touch screen, please tick “Support multi- monitor system”. Step 9: Select the destination location to store the driver, the default path is C: \ Program Files \ eGalaxtouch; we use the default path here, click Next to proceed to installation.
  • Page 15 Click Next to proceed to installation Step 10: Check the projects to create a desktop shortcut icon in the following figure...
  • Page 16 After install the driver successfully, identify the USB controller card and RS232 control card as the following two figures shows.
  • Page 17 Related touch function setting Touch calibration...
  • Page 18 Touch device line test Touch screen setting...
  • Page 19 Touch device edge correction setting Touch device hardware information display...

  • Page 20: Chapter Iv: Common Faults And Exclusion

    Chapter IV: Common Faults and exclusion 1. POS device does not boot If the POS devices cannot boot after repeated pressing of the power switch (POWER) when connect to the power, the POS device power light remains off, the fan does not operate, and the BIOS beeping is not heard.
  • Page 21 4) If the POS device does not boot after a sudden power failure or illegal shutdown, unplug the adapter from the POS device, and press the power button (POWER) for several times, then plug the adapter and boot again. (5)If the adapter light blinks or go off, unplug the adapter immediately and do not plugged in again, then contact with our products service center.
  • Page 22 the driver installation instructions "); (4) Check the IP address is set correctly (according to the "Driver Installation Instructions"), If you do not know how to. Please apply "Obtain an IP address automatically". (5) Not available to access internet or the network speed is very slow, it may be too many pages opened or affected by viruses, so please clean the virus immediately.
  • Page 23 also recommend you to do this after change the monitor resolution or refresh rate. When running the calibration, press the center of calibration point to avoid in accuracy. 9. The cursor moves opposite to the touch movement (1) Please run the 4/9/25 point calibration; (2) The touch screen driver is not installed properly, reinstall the driver.
  • Page 24 (1) Make sure the printer is normal; (2) Check the printer and POS devices are connected; (3) Check the driver of printer is installed; (4) Try to find the printer hardware in the POS device properties, if found, please re-install the correct printer driver; (5) In the POS device properties if the printer hardware is not found, please re-check printers and POS device is connected and the printer is available.
