EC Line EC-1519 User Manual

All-in-one touch pos terminal
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
EC-1519
All-in-one Touch POS Terminal

Advertisement

loading

Related Manuals for EC Line EC-1519

Summary of Contents for EC Line EC-1519

  • Page 1 User Manual EC-1519 All-in-one Touch POS Terminal...

  • Page 2: Safety Information

    Overview Thank you for purchasing the EC-1519 all-in-one touch POS terminal, EC-Line is committed to continuously improve product quality and provide better after-sales service. In order to take full advantage of our devices, we strongly recommend that you take the time to read this manual before diving into software solution.

  • Page 3: Electromagnetic Compatibility Statement

    to the screen. When the following occurs: Water get inside the POS terminal; Physical damage accidentally; POS terminal produces a burning smell; disconnect the power supply immediately, unplug the power cord, and contact a qualified service technician. 2. Electromagnetic compatibility statement FCC NOTICE This device complies with Part 15 of FCC Rules.
  • Page 4 Installation Guide 1. Appearance 2. Power Button...
  • Page 5 3. Rear panel I/O connectors At the rear panel of the EC-1519 is a row of external I/O device connectors. Detail as follow: Keyboard: Connect ion to PS/2 keyboard RJ11: RJ11 port for connection to cashbox VGA: VGA signal output for connection to external monitor HDMI: Digital image/sound transmission interface COM 1.2.3: RJ45 port for connection to serial devices...

  • Page 6: Specification

    Specification Model name EC-1519 Type 15”All In One Touch POS terminal Color Black Material Magaluma ISO Trick 1/2/3 Magnetic Stripe Reader 2 X 20 VFD Customer Display Monitor (9.7”,12”,15”) Optional Peripherals WIFI Bluetooth Windows OS SSD (32G,64G,128G) Motherboard part Main Board ITX-J1900 Intel®...
  • Page 7 LAN X 1 USB3.0 X 2 Line In X 1 Microphone X 1 DC Out X 1 Power LED X 1 0 ℃ to 40℃ Operating Temperature Storage Temperature -20℃ to 60℃ SIZE 450 X 245 X 400mm NW: 6.1KG Package: carton box with GW: 7.KG Foam packaging...
  • Page 8 Setup and Driver Installation 1. Motherboard BIOS settings The POS terminal has a BIOS (Basic Input Output System) chip on the motherboard. Every time you start the terminals, the system will first run the BIOS self-test routine to check the main components of the system to ensure it is working properly. The terminal is loaded with default BIOS settings in the factory.
  • Page 9 <F9> To load default settings <F10> To store settings and exit the CMOS SETUP program How to enter and exit the COMS interface: Enter the COMS interface Boot the BP-110, press the key “Del” to enter COMS interface. Leave the COMS interface Press the key “F9”...
  • Page 10 2. Touch screen driver installation: Step 1: Navigate to the installer directory to find the “setup.exe” file .Double-click ”setup exe” to start installation. Step 2: When installation starts, click [Next] to proceed to the next step.
  • Page 11 Step 3: Installation in progress Step 4: Skip “Install PSI ” [Next] to continue installation.
  • Page 12 Step 5: Skip “install RS232 interface driver” and click [Next] to continue installation. Step 6: Select option “NONE”, click [Next] to continue installation.
  • Page 13 Step 7: When installing USB touch, connect the USB controller and USB cable Step 8: If there are additional touch monitors connected, please check “Support multi - monitor system”.
  • Page 14 Step 9: Select the destination location to install the touch driver. The default path is “C:\Program Files\eGalaxtouch”. Click [Next] to continue installation. Step 10: Select the Program Folder to install the utility. The default is “eGalaxtouch”. Click [Next] to continue installation.
  • Page 15 Step 11: Check the option to create a desktop shortcut icon. After install the driver successfully, identify the USB controller IS installed as shown below.
  • Page 16 Touch function settings 1. Main page 2. Touch calibration...
  • Page 17 3. Touch device line test...

  • Page 18: Troubleshooting

    Troubleshooting 1. Terminal does not boot If the terminal cannot boot after repeated pressing of the power switch when connect to the power, the terminal power light remains off, the fan does not operate, and the BIOS beeping is not heard, it might be power supply problems. a) Check the power adapter is plugged in correctly to the power outlet.
  • Page 19 3. Touch screen does not response a) Remove the touch driver and then install it again. b) Execute the “eGalaxTouch” utility and check if the interface port is working. 4. Whenever touching the screen, cursor always returns to a fixed position. a) Check if there is anything pressing on the touch screen.
  • Page 20 b) Run the touch screen calibration program to do a 25-point recalibration.
  • Page 21 Manufacturer: EC LINE Thank you very much for using EC Line product For service, please contact service@ecline.com.hk www.eclinepos.com...
