Technical Specifications
5.7 Operating Environment
Copper Serial Ports
Baud Rate
Connector
Isolation
Fiber Serial Ports
Mode
Connector
Typical Distance (km)
Optical Wavelength
(nm)
Cable Size
5.7

Operating Environment

The RUGGEDCOM RS910W is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
5.8

Mechanical Specifications

Weight
Ingress Protection
Enclosure
5.9

Dimension Drawings

Note
All dimensions are in millimeters, unless otherwise stated.
34
300 to 230 kbps
DB9 or RJ45
2.5 kV
Multimode
ST
5
820
50/125 or 62.5/125
-40 to 85 °C (-40 to 185 °F)
a
-40 to 85 °C (-40 to 185 °F)
b
5% to 95%
2000 m (6562 ft)
1.2 kg (2.7 lbs)
IP30
20 AWG Galvanized Steel
RUGGEDCOM RS910W
Installation Manual, 04/2021, C79000-G8976-1031-12
