Communication Ports
The RUGGEDCOM RS910W can be equipped with various types of communication
ports to enhance its abilities and performance.
2
1
1
2
3
Figure 4.1
4.1
Copper Ethernet Ports
The RUGGEDCOM RS910W supports multiple 10/100Base-TX Ethernet ports that
allow connection to standard Category 5 (CAT-5) shielded or unshielded twisted-pair
cables with RJ45 male connectors.
RUGGEDCOM RS910W
Installation Manual, 04/2021, C79000-G8976-1031-12
3
Ports 1 and 2
Ports 3 and 4
Port 9
Port Assignment
Port
1 and 2
3 and 4
9
Serial Ports
Copper (10/100Base-TX) or Fiber Optic (100Base-FX) Ethernet Ports
Wireless Antennas
Type
4
23
