H-7442
DRYWALL CART

TOOLS NEEDED

17 mm Socket Wrench
Deck x 1
Swivel Caster x 2
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
13 mm Wrench
14 mm Wrench
Left Frame x 1
Swivel with Brake
Locknut x 6
Caster x 2

PARTS

Right Frame x 1
Lock Washer x 16

ASSEMBLY

1. Attach casters to deck using short bolts, lock washers
and large washers. (See Figure 1)
NOTE: Make sure both swivel with brake casters
go on one end of the deck and both swivel
casters go on the other end.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Support x 2
Small Washer x 6
Large Washer x 16
Short Bolt x 16
Long Bolt x 6
0321 IH-7442
