Step 4: Connect The Inputs And Outputs; Step 5: Connect The Power; Step 6: Configure Via Connect² - Kramer VIA Connect2 Quick Start Manual

Step 4: Connect the inputs and outputs

Always switch OFF the power on each device before connecting it to your
that you always use Kramer high-performance cables to connect AV equipment to
may cause damage!
1. Connect the
keyboard and
mouse.
2. Connect an HDMI
display.
3. Connect to the LAN
(default mode).
4. If required, connect
a wired HDMI video
source.
If you wish to use
a Kramer active
optical pluggable
HDMI cable with
your VIA
Connect², contact
your local Kramer
office to assist in
purchasing the
correct cable.

Step 5: Connect the power

Connect the 12V DC power adapter to
Caution: There are no operator serviceable parts inside the unit.
Caution: The device is intended to be installed at a height of 2 meters or less.
Warning: Use only the Kramer Electronics power adapter that is provided with the unit.
Warning: Disconnect the power and unplug the unit from the wall before installing.
See www.KramerAV.com
Step 6: Configure VIA Connect²
A wizard guides you through configuration. If you choose to skip the wizard, follow these steps for configuration:
General Settings Configuration
1. On the main display, click the VIA icon in the lower left corner. The VIA gateway dashboard appears.
2. Click Settings. The settings login window appears.
3. Enter the User Name (default = su) and Password (default = supass) and
click Login. The VIA Settings window appears.
The VIA Settings tabs are:
▪ LAN Settings – Configure network parameters (default = DHCP)
▪ System Controls – Define audio input and output sources, change
display resolution, view system health indicators, and activate your unit.
▪ Wi-Fi – Activate and configure the built-in Wi-Fi capability.
4. When you have finished configuring settings, click Reboot to apply all
settings.
Change to AP Wi-Fi Mode
Set up the built-in Wi-Fi module as a secondary Access Point (for guests).
1. On the Wifi tab, click the Wifi Settings switch. The switch turns green and additional Wi-Fi settings appear.
2. Click AP Mode, and enter a new name in the SSID field and a new password or use the default name and password.
3. Select a Wi-Fi channel for the Access Point.
4. Select Enable Internet (if the primary LAN network is connected to the Internet) OR Activate Standalone Wifi (to create an
autonomous network without Internet access) and click Apply.
Switch to Client Wi-Fi Mode
Attach your VIA Connect² as a client device to your main network:
1. On the Wifi tab, click the Wifi Settings switch. The switch turns green and additional Wi-Fi settings appear.
2. Click Client Mode, select an available network from the drop-down.
3. Enter the required password and click Apply.
4. Disconnect the LAN cable (if connected) before rebooting the device.
VIA Connect² and plug it into the mains electricity.
for updated safety information.
VIA Connect². For best results, we recommend
VIA Connect². Using third-party cables
