The Ph Amp - ADInstruments pH Amp Owner's Manual

Figure 2–4
The pH Amp dialog
(LabChart for Windows)
Figure 2–5
The pH Amp dialog
(LabChart for Macintosh)
Chapter 2 Setting Up

The pH Amp

The pH Amp dialog appears when you choose the
command in LabChart (or click the
dialog allows software control of the various amplifiers and filters of
the hardware. Change settings in the dialog, then click
them. To set up many channels quickly, click the arrows by the dialog
title, or press the right or left arrow keys on the keyboard, to move to
the equivalent dialogs for adjacent channels. This skips channels that
are turned off. The channel number is shown next to the arrows.
Signal amplitude
Click this button to open the Units Conversion dialog
Amplitude axis Signal amplitude
Click this button to open the Units Conversion dialog
pH Amp...
Pause and Scroll buttons
Pause/Scroll button
menu
pH Amp...
button in Scope). This
to apply
OK
Range pop-up
menu
Low-pass filter
pop-up menu
Amplitude axis
Range pop-up
menu
Low-pass filter
pop-up menu
Compression
buttons
21
