- Page 1 Installation and user manual 5P750RC 5P1000RC 5P1500RC Copyright © 2015 EATON All right s reserved. 5P 750VA -1. 5 KVA EU_EN Page 1...
- Page 2 Certification Standards Unint errupt ible power syst ems (UPS) direct ives: • IEC 62040-1: General and saf et y requirement s f or UPS • IEC 62040-2: Elect romagnet ic compat ibilit y (EMC) requirement s • IEC 62040-3: Met hod of specif ying t he perf ormance and t est requirement s .
- Page 3 Bat t ery Module provided wit h t he UPS t o maint ain an ident ical level of perf ormance and saf et y. In case of doubt , don't hesit at e t o cont act your EATON represent at ive.
-
Page 4: Table Of Contents
1. Introduction ................. 5 1. -
Page 5: Introduction
To discover t he ent ire range of EATON product s and t he opt ions avail able f or t he 5P range, we invit e you t o visit our web sit e at www. -
Page 6: Presentation
2. 1 Standard installations Rack model Description Weights Dimensions (mm/inch) (kg/lb) D x W x H 5P750RC 14. 1/ 31. 1 370*440*86. 2 / 14. 6*17. 3*3. 4 5P1000RC 15. 0/ 33. 1 370*440*86. 2 / 14. 6*17. 3*3. 4 5P1500RC 18. -
Page 7: Rear Panel
2. 2 Rear panel & & 5P750RC 5P1000RC 5P1500RC ① ③ ④ ② At t ached 1. 8 m input power cord f or AC power source Slot f or opt ional communicat ion card Primary group : Out let s f or connect ion... -
Page 8: Control Panel
2. 3 Control panel The UPS has a five-button graphical LCD. It provides useful information about the UPS itself, load status, events, measurements and settings. 100% 19min 1EBM The f ollowing t able shows t he indicat or st at us and descript ion: Indicator Status Description... -
Page 9: Lcd Description
2. 4 LCD description As def ault , or af t er 5 minut es of inact ivit y, t he LCD displays t he screen saver. The backlight LCD aut omat ical ly dims af t er 10 minut es of inact ivit y. Press any but t on t o rest ore t he screen. The f ollowing t able describes t he st at us inf ormat ion provided by t he UPS Note: If ot her indicat or appear s, see t roubleshoot ing on sect ion 5. -
Page 10: User Settings
2. 5 Display functions Press t he Ent er ) but t on t o act ivat e t he menu opt ions. Use t he t wo middle but t ons ( ) t o scroll t hrough t he menu st ruct ure. - Page 11 Submenu Available settings Default settings [Disable] [Enable] Enable Cold st art Enables the product to be started on battery power. First cold start always disabled. [Disable] [Enable] Forced reboot Enable If mains recover during a shutdown sequence: - if enabled, shutdown sequence will complete and wait 10 seconds prior to restart - if disabled, shutdown sequence will...
-
Page 12: Installation
3. Installation 3. 1 Unpacking and contents check ⑨ ⑫ ⑬ ⑪ ⑩ (9) 5P UPS (10) Rail and wall mounting kits (11) Quick start, safety instructions and environmental document (12) RS232 communication cable (13) USB communication cable Packing materials must be disposed of in compliance with all local regulations concerning waste. Recycling symbols are printed on the packing materials to facilitate sorting. -
Page 13: Battery Module Connection
3. 2 Battery module connection Caution: Before starting the UPS, please connect the internal battery. A. Remove the center panel ○ B. Remove the left-hand side of the front panel ○ C. Connect the battery module (never pull on the wires) ○... -
Page 14: Rack Installation
Follow steps 14 to 16 for model mounting on the rails. Use provided screws on step 15 of installation. Using a longer screw could present a safety risk. ⑮ ⑭ ⑮ ⑯ ⑯ ③ The rails and necessary hardware are supplied by EATON. 5P 750VA-1. 5 KVA US_EN Page 14... -
Page 15: Wall Mounting Of Rack Model
3. 4 Wall mounting of rack model Use provided screws on step 17 of installation. Using a longer screw could present a safety risk. ⑰ ⑱ ⑱ ⑰ Page 15 5P 750VA-1. 5 KVA US_EN... -
Page 16: Communication Ports
UPS. ⑥ The UPS can now communicat e wit h ⑬ EATON power management sof t ware. ⑫ It is not necessary t o shut down t he UPS bef ore inst alling a communicat ion Installation of the communication cards (optional) card 1. -
Page 17: Operation
4. 1 Start-up and Normal operation To start the UPS: 1. Verify that the UPS power cord is plugged in. 2. The UPS front panel display illuminates and shows EATON logo. 3. Verify that the UPS status screen shows 4. Press the button on the UPS front panel for at least 2 seconds. -
Page 18: Return Of Ac Input Power
Low-battery warning • The indicator illuminates solid. • The audio alarm beeps every three seconds. The remaining battery power is low. Shut down all applications on the connected equipment because automatic UPS shutdown is imminent. End of battery backup time •... -
Page 19: Maintenance
5. Maintenance 5. 1 Troubleshooting Operation status Possible cause Action If t he condit ion persist s, cont act your The UPS does not recognize t he int ernal bat t eries Batteries disconnected service represent at ive Verify that all batteries are properly The bat t eries are disconnect ed connected. -
Page 20: Battery-Module Replacement
Mounting the new battery module Carry out the above instructions in reverse order. • To ensure safety and high performance, use only batteries supplied by EATON. • Take care to firmly press together the two parts of the connector during remounting. -
Page 21: Appendices
6. Appendices 6. 1 Technical specifications Rack 5P750RC 5P1000RC 5P1500RC Output Power 750 VA 1000 VA 1440 VA @ 120 V 600 W 770 W 1100 W Output Power 625 VA 833VA 1080 VA @ 100 V 500 W 641W... -
Page 22: Glossary
6. 2 Glossary Backup time Time during which the load can be supplied by the UPS operating on battery power. Battery test Internal UPS test to check battery status. Cold start The devices connected to the UPS can be started even if AC input power is not available. - Page 23 Page 23 Eaton 5P 5P 750VA-1. 5 KVA US_EN...
