Renesas Starter Kit User's Manual
Rev. 1.00 Nov 2015
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Renesas RX Series
Summary of Contents for Renesas RX Series
- Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corporation without notice. Please review the latest information published by Renesas Electronics Corporation through various means, including the Renesas Electronics Corporation website (http://www.renesas.com).
- Page 2 Electronics product for any application for which it is not intended. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for which the product is not intended by Renesas Electronics.
- Page 3 After use the equipment cannot be disposed of as household waste, and the WEEE must be treated, recycled and disposed of in an environmentally sound manner. Renesas Electronics Europe GmbH can take back end of life equipment, register for this service at http://www.renesas.eu/weee EETS-CD-0098-1.0...
- Page 4 WEB-00171583-02.00M Part Name Toxic and Hazardous Substance and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated diphenyl (Hg) (Cd) Chromium biphenyls ethers (Pb) (Cr(VI)) (PBB) (PBDE) Case Board Cable Socket AC-Adapter SJ/T11363-2006 If certain toxic and hazardous substances or elements do not exist in this part, then mark for the corresponding column, which indicates that this toxic and hazardous substance or element contained in all of the homogeneous materials for this part is below the limit requirement in SJ/T11363-2006.
- Page 5 WEB-00171583-02.00M ● 有毒有害物质或元素 有情况表 Table of Toxic and Hazardous Substance and Elements 部件名称 有毒有害物质或元素 Part Name Toxic and Hazardous Substance and Elements 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated diphenyl (Pb) (Hg) (Cd) Chromium biphenyls ethers (Cr(VI)) (PBB)
- Page 6 RSK. Renesas expressly disclaims all such warranties. Renesas or its affiliates shall in no event be liable for any loss of profit, loss of data, loss of contract, loss of business, damage to reputation or goodwill, any economic loss, any reprogramming or recall...
- Page 7 The following documents apply to the RSKRX130. Make sure to refer to the latest versions of these documents. The newest versions of the documents listed may be obtained from the Renesas Electronics Web site. Document Type...
- Page 8 Digital-to-Analog Converter Dual In-line Package Direct Memory Access DMAC Direct Memory Access Controller Do Not Fit E1/E2 Lite Renesas On-chip Debugging Emulator EEPROM Electronically Erasable Programmable Read Only Memory Electromagnetic Compatibility Electrostatic Discharge General PWM Timer C (IIC) Philips™ Inter-Integrated Circuit Connection Bus...
-
Page 9: Table Of Contents
Table of Contents 1. Overview .......................... 11 Purpose ..............................11 Features ..............................11 Board specification ........................... 12 2. Power Supply ........................13 Requirements ............................13 Power-Up Behaviour ..........................13 3. Board Layout ........................14 Component Layout ........................... 14 Board Dimensions ............................ 15 Component Placement .......................... - Page 10 Address Space ............................40 9. Additional Information ...................... 41...
-
Page 11: Overview
Nov 30, 2015 1. Overview Purpose This RSK is an evaluation tool for Renesas microcontrollers. This manual describes the technical details of the RSK hardware. The Quick Start Guide and Tutorial Manual provide details of the software installation and debugging environment. -
Page 12: Board Specification
RSKRX130 1. Overview Board specification Board specification was shown in Table 1-1 below. Item Specification Part No : R5F51305ADFN Microcontroller Package : 80-pin LFQFP On-Chip Memory : ROM 128KB, RAM 16KB On-Board Memory C EEPROM : 2Kbit RX130 Main : 8MHz Input Clock RX130 Sub : 32.768kHz RL78/G1C Main: 12MHz... -
Page 13: Power Supply
Power-Up Behaviour When the RSK is purchased, the RSK board has the 'Release' build of the example tutorial software pre- programmed into the Renesas microcontroller. Please consult the 'Renesas Starter Kit Code Generator Tutorial Manual' for further information of this example. -
Page 14: Board Layout
RSKRX130 3. Board Layout 3. Board Layout Component Layout Figure 3-1 below shows the top component layout of the board. Application Board Interfaces PMOD2 Connector Reset Switch PMOD1 Connector PMOD1 USB Function (RL78/G1C) EEPROM DC Power Jack(5V) RL78/G1C Touch Interface (slider) E1/E2 Lite Connector LIN power connector... -
Page 15: Board Dimensions
RSKRX130 3. Board Layout Board Dimensions Figure 3-2 below gives the board dimensions and connector positions. All the through-hole connectors are on a common 0.1 inch grid for easy interfacing. 7.0mm 3.2mm 33.88mm 4-R3.0 45.00mm 25.40mm PMOD1 27.00mm 10.00 48.26mm 50.80mm 55.88mm 86.36mm... -
Page 16: Component Placement
RSKRX130 3. Board Layout Component Placement Figure 3-3 below shows placement of individual components on the top-side PCB – bottom-side component placement can be seen in Figure 3-4. Component types and values are shown on the board schematics. USB0 R88 R89 POWER LED0 LED1... - Page 17 RSKRX130 3. Board Layout R165 R152 R176 R178 R179 R168 R143 R163 R162 R169 R144 R180 R145 R181 R146 R182 R147 R131 R148 R183 R149 R132 R184 R133 R150 R151 R134 R136 R137 R138 R139 R170 R171 R172 R173 R174 R175 SERIAL NUMBER Figure 3-4 Bottom-Side Component Placement...
-
Page 18: Connectivity
RSKRX130 4. Connectivity 4. Connectivity Internal RSK Connections Figure 4-1 below shows the RSK board components and their connectivity to the MCU. DC PWR IN USB to Serial (5V) LDO Regulator 1.86V or 3.3V VBUS 5V output) RL78/G1C Microcontroller Application Board Interfaces Function (Application Headers) RX130... -
Page 19: Debugger Connections
RSKRX130 4. Connectivity Debugger Connections Figure 4-2 below shows the connections between the RSK, E1/E2 Lite debugger and the host PC. User Interface Cable USB Cable E1 Emulator E2 Emulator Lite CPU Board Host PC Figure 4-2: Debugger Connection Diagram R20UT3444EG0100 Rev.1.00 Page 19 of 45 Nov 30, 2015... -
Page 20: User Circuitry
RSKRX130 User Circuitry 5. User Circuitry Reset Circuit A reset control circuit is fitted to the RSK to generate a reset signal from the RES switch. Refer to the RX130 hardware manual for details regarding the reset signal timing requirements, and the RSK schematics for information regarding the reset circuitry in use on the board. -
Page 21: Leds
RSKRX130 User Circuitry LEDs There are five LEDs on the RSK. The function of each LED, its colour, and its connections are shown in Table 5-3. Colour Function Port POWER Green Indicates the status of the Board_VCC power rail LED0 Green User operated LED LED1... -
Page 22: Pmod
RSKRX130 User Circuitry Pmod™ The RSK board are equipped with connectors for Digilent Pmod™ interface. Please connect the PMOD1 connector that is compatible with Debug LCD. Care should be taken when installing the LCD module to ensure pins are not bent or damaged. The LCD module is vulnerable to electrostatic discharge (ESD);... -
Page 23: Usb Serial Port
User Circuitry USB Serial Port A USB serial port is implemented in a Renesas low power microcontroller (RL78/G1C) and is connected to the RX130 Serial Communications Interface (SCI) module. Multiple options are provided to allow the selection of the connected SCI1 port. Connections between the USB to Serial converter and the microcontroller are listed in Table 5-6 below. -
Page 24: C Bus (Inter-Ic Bus)
RSKRX130 User Circuitry C Bus (Inter-IC Bus) The RX130 features one I C (Inter-IC Bus) interface modules. RIIC is connected to a 2Kbit EEPROM. Specific details of the EEPROM device and the connections can be found in the board schematics. 5.10 Touch Interface The RSK Board is fitted with a Touch Interface (slider) and two Touch Interfaces (key). -
Page 25: Configuration
RSKRX130 Configuration 6. Configuration Modifying the RSK This section lists the option links that are used to modify the way RSK operates in order to access different configurations. Configurations are made by modifying link resistors or headers with movable jumpers. A link resistor is a 0Ω... -
Page 26: Power Supply Configuration
RSKRX130 Configuration Power Supply Configuration Table 6-2 and Table 6-3 below details the function of the option links associated with power supply configuration. Reference Configuration Explanation Related Ref. Connects Board_VCC to UC_VCC. Shorted Pin1-2 J8 * All open Enables current probe for MCU current consumption. Enables 1.86V regulator output. -
Page 27: Analog Power & Adc & Dac Configuration
RSKRX130 Configuration Analog Power & ADC & DAC Configuration Table 6-5 below details the function of the option links associated with Analog Power & ADC & DAC configuration. MCU Peripheral Selection Destination Selection Signal name Interface Signal /Function JA1.13 JA1.14 R184 ADTRG0n_IRQ6 ADTRG0n_IRQ6... -
Page 28: General I/O & Led Configuration
RSKRX130 Configuration General I/O & LED Configuration Table 6-7 below details the function of the option links associated with the General I/O & LED configuration. MCU Peripheral Selection Destination Selection Signal name Interface Signal /Function R116 JA1.15 IO0_MTIOC4A MTIOC4A R116 JA2.15 R113 JA1.16... -
Page 29: Irq & Switch Configuration
RSKRX130 Configuration IRQ & Switch Configuration Table 6-9 below details the function of the option links associated with the IRQ & Switches configuration. MCU Peripheral Selection Destination Selection Signal name Interface Signal /Function IRQ7 IRQ7 PMOD1.8 R184 ADTRG0n_IRQ6 ADTRG0n_IRQ6 JA1.6 MTCLKB R106 R154... -
Page 30: Mtu & Poe Configuration
RSKRX130 Configuration 6.11 MTU & POE Configuration Table 6-11 below details the function of the option links associated with MTU & POE configuration. MCU Peripheral Selection Destination Selection Signal name Interface Signal /Function MTIOC0A_IRQ4 R124 R156, R160 JA2.7 MTIOC0A_IRQ4_RL78G1 RL78G1CCTS R160 R124, R156 U6.2... -
Page 31: Pmod1 Interface Configuration
RSKRX130 Configuration 6.12 PMOD1 Interface Configuration Table 6-12 below details the function of the option links associated with PMOD1 Interface configuration. MCU Peripheral Selection Destination Selection Signal name Interface Signal /Function JA1.18 IO3_CTS6RTS6 CTS6RTS6 PMOD1.1 R149 JA1.17 IO2_TXD6 TXD6 R149 PMOD1.2 MTIC5W R146... -
Page 32: Serial & Usb To Serial Configuration
RSKRX130 Configuration 6.14 Serial & USB to Serial Configuration Table 6-14 below details the function of the option links associated with Serial & USB to Serial configuration. MCU Peripheral Selection Destination Selection Signal name Interface Signal /Function MTIOC0A_IRQ4 R124 R156, R160 JA2.7 MTIOC0A_IRQ4_RL78G1... -
Page 33: Touch Interface Configuration
RSKRX130 Configuration 6.15 Touch Interface Configuration Table 6-15 below details the function of the option links associated with Touch Interface configuration. MCU Peripheral Selection Destination Selection Signal name Interface Signal /Function TSCAP TSCAP TSCAP_CON TSCAP_CON R170 touch slider TS7_CON TS7_CON R170 R171 touch slider... -
Page 34: Headers
7. Headers 7. Headers Application Headers This RSK is fitted with application headers, which can be used to connect compatible Renesas application devices or as easy access to MCU pins. Table 7-1 below lists the connections of the application header, JA1. - Page 35 RSKRX130 7. Headers Table 7-2 below lists the connections of the application header, JA2. Application Header JA2 Header Name Header Name MCU Pin MCU Pin Circuit Net Name Circuit Net Name RESET EXTAL RESn CON_EXTAL Vss1 GROUND WDT_OVF SCIaTX A-TXD1 IRQ/WKUP/M_HSIN SCIaRX 15/NC/15...
- Page 36 RSKRX130 7. Headers Table 7-3 below lists the connections of the application header, JA5. Application Header JA5 Header Name Header Name MCU Pin MCU Pin Circuit Net Name Circuit Net Name ADC4 ADC5 AN004 AN005 ADC6 ADC7 AN006 AN007 CAN1TX CAN1RX CAN2TX CAN2RX...
- Page 37 RSKRX130 7. Headers Table 7-4 below lists the connections of the application header, JA6. Application Header JA6 Header Name Header Name MCU Pin MCU Pin Circuit Net Name Circuit Net Name DREQ DACK TEND STBYn RS232TX RS232RX RS232TX RS232RX SCIbRX SCIbTX A-RXD5 A-TXD5...
-
Page 38: Microcontroller Pin Headers
RSKRX130 7. Headers Microcontroller Pin Headers This RSK is fitted with MCU pin headers, which are used to access all the MCU’s pins. Table 7-5 below lists the connections of the microcontroller pin header, J1. Microcontroller Pin Header J1 Circuit Net Name MCU Pin Circuit Net Name MCU Pin... - Page 39 RSKRX130 7. Headers Table 7-7 below lists the connections of the microcontroller pin header, J3. Microcontroller Pin Header J3 Circuit Net Name MCU Pin Circuit Net Name MCU Pin MTIOC3B MTIOC3D IO6_POE1n IO5_PB4 IO4_SCK6 IO3_CTS6RTS6 IO2_TXD6 UC_VCC RXD6_MTIC5W GROUND MTIC5V_CTS5RTS5 MTIC5U_A-TXD5_P-TXD5 IO1_MTIOC0D A-RXD5_P-RXD5...
-
Page 40: Code Development
8. Code Development Overview For all code debugging using Renesas software tools, the RSK board must be connected to a PC via an E1/E20/E2 Lite debugger. An E1/E2 Lite debugger is supplied with this RSK product. For further information regarding the debugging capabilities of the E1/E20/E2 Lite debuggers, refer to E1/E20 Emulator, E2 Emulator Lite Additional Document for User's Manual (R20UT0399EJ). - Page 41 Copyright This document may be, wholly or partially, subject to change without notice. All rights reserved. Duplication of this document, either in whole or part is prohibited without the written permission of Renesas Electronics Europe Limited. © 2015 Renesas Electronics Europe Limited. All rights reserved.
- Page 42 REVISION HISTORY RSKRX130 User’s Manual Description Rev. Date Page Summary 1.00 Nov 30, 2015 First Edition issued Page 42 of 45...
- Page 43 Renesas Starter Kit Manual: User’s Manual Publication Date: Rev.1.00 Nov 30, 2015 Published by: Renesas Electronics Corporation...
- Page 44 SALES OFFICES Refer to "http://www.renesas.com/" for the latest and detailed information. Renesas Electronics America Inc. 2801 Scott Boulevard Santa Clara, CA 95050-2549, U.S.A. Tel: +1-408-588-6000, Fax: +1-408-588-6130 Renesas Electronics Canada Limited 9251 Yonge Street, Suite 8309 Richmond Hill, Ontario Canada L4C 9T3...
- Page 45 RX130 Group R20UT3444EG0100...
