  • Page 1 LASERCOMBY COMBO LASER EFFECT WITH LASER+LED SOURCE Manuale Utente User Manual...
  • Page 2 Music & Lights S.r.l. si riserva ogni diritto di elaborazione in qualsiasi forma delle presenti istruzioni per l’uso. La riproduzione - anche parziale - per propri scopi commerciali è vietata. Al fine di migliorare la qualità dei prodotti, la Music&Lights S.r.l. si riserva la facoltà di modificare, in qualunque momento e senza preavviso, le specifiche menzionate nel presente manuale di istruzioni.
  • Page 3: Table Of Contents

    3. 12 Collegamenti della linea DMX 3. 13 Costruzione del terminatore DMX 3. 14 Tabella canali DMX 4 Manutenzione 4. 1 Manutenzione e pulizia dispositivo 4. 2 Risoluzione dei problemi Certificato di garanzia Contenuto dell'imballo: • LASERCOMBY • Cavo di alimentazione • Manuale utente...
  • Page 4: Avvertenze Generali

    LASERCOMBY ATTENZIONE! Prima di effettuare qualsiasi operazione con l’unità, leggere con attenzione questo manuale e conservarlo accuratamente per riferimenti futuri. Contiene informazioni importanti riguardo l’installazione, l’uso e la manutenzione dell’unità. SICUREZZA Avvertenze generali • I prodotti a cui questo manuale si riferisce sono conformi alle Direttive della Comunità Europea e per- tanto recano la sigla .
  • Page 5: Sicurezza Laser E Istruzioni Operative

    LASERCOMBY Sicurezza laser e istruzioni operative • Non utilizzare il proiettore laser senza lettura e comprensione sulla sicurezza laser e sulle istruzioni operative contenute in questo manuale. • Il raggio laser può causare danni permanenti agli occhi ed alla pelle.
  • Page 6: Informazioni Generali

    LASERCOMBY I dispositivi laser con radiazioni accessibili recano etichette in modo da indicare: • il segnale d’avvertimento laser; • la classe di appartenenza del dispositivo laser unitamente all’indicazione cautelativa e di avvertimento pertinente, nonché • i dati di identificazione e i dati del tipo.
  • Page 7: Introduzione

    LASERCOMBY - 1 - INTRODUZIONE 1.1 DESCRIZIONE Effetto combo Laser+LED per la proiezione di raggi puntiformi, animazioni ed illuminazione d’ambiente. La sorgente LED tri-Colour, in combinazione ai diodi di colore rosso e verde, offrono all’utente una vasta generazione di effetti controllabili in remoto o dal pannello di controllo.
  • Page 8: Elementi Di Comando E Di Collegamento

    LASERCOMBY 1.3 ELEMENTI DI COMANDO E DI COLLEGAMENTO LASER APERTURE LASER RADIATION Vista frontale Fig.1 1. STAFFA DI MONTAGGIO 2. MANOPOLA DI FISSAGGIO per la staffa di montaggio. 3. APERTURA RAGGIO LED 4. APERTURA RAGGIO LASER...
  • Page 9 LASERCOMBY Vista posteriore Fig.2 5. DMX OUT (XLR 3 poli): 10. GND POINT usato per la messa a terra del 1 = massa, 2 = DMX -, 3 = DMX + dispositivo.REGOLATORE ROTAZIONE LED. 6. DMX IN (XLR 3 poli): 11.
  • Page 10: Installazione

    - 2 - INSTALLAZIONE 2.1 MONTAGGIO Il LASERCOMBY può essere collocato su un piano solido. Inoltre, grazie alle possibilità di fissaggio sul- la staffa (fig.3), l’unità può essere montata con versatilità su una traversa. Per il fissaggio occorrono dei supporti robusti per il montaggio. L’area di collocazione deve avere una stabilità sufficiente e supportare almeno 10 volte il peso dell’unità.
  • Page 11: Funzioni E Impostazioni

    • In caso di gravi problemi di funzionamento, smettere di usare il dispositivo e contattare immediata- mente un centro di assistenza tecnica autorizzato. 3.2 IMPOSTAZIONE BASE Il LASERCOMBY dispone di un LED display e 4 pulsanti per accesso alle funzioni del pannello di controllo (fig.5). Fig.5...
  • Page 12: Struttura Menu

    Set DMX starting address Slave Mode Sets Slave Mode FUNZIONAMENTO STANDALONE Il LASERCOMBY dispone di diverse opzioni per il funzionamento senza un controller DMX: 3.4 MODALITÀ AUTOMATICA Per entrare nella modalità automatica e permettere all’unità di svolgere il suo programma Show autono- mamente: • Premere il tasto [MENU] ripetutamente fino a quando sul display non appare [AuF], [AuS], [Sou] o [rdn].
  • Page 13: Modalità Color Mixing

    Per questa modalità è necessatirio impostare correttamente le unità: IMPOSTAZIONE UNITÀ MASTER • Servirsi dei connettori DMX del LASERCOMBY e di un cavo XLR per formare una catena di unità. • Impostare una delle modalità standalone (Modalità Automatica o Mmodalità Musicale) per l’unità ma- ster.
  • Page 14: Modalità Dmx

    LASERCOMBY 3.10 MODALITÀ DMX Il LASERCOMBY dispone di 12 canali DMX. Le tabelle a pagina 16 indicano le modalità di funzionamento e i relativi valori DMX. Come interfaccia DMX, l’unità possiede dei contatti XLR a 3 poli. • Per poter entrare nella modalità DMX, premere il tasto [MENU] fino a quando sul display non appare [001], quindi premere il tasto ENTER per confermare.
  • Page 15: Collegamenti Della Linea Dmx

    LASERCOMBY 3.12 COLLEGAMENTI DELLA LINEA DMX La connessione DMX è realizzata con connettori standard XLR. Utilizzare cavi schermati, 2 poli ritorti, con impedenza 120Ω e bassa capacità. Per il collegamento fare riferimento allo schema di connessione riportato di seguito: DMX - INPUT...
  • Page 16: Tabella Canali Dmx

    LASERCOMBY 3.14 TABELLA CANALI DMX CH12 CH Function in CH12 mode Value CH Function in CH12 mode Value Green AUTO MODE DMX Mode 000 - 049 Green 000 - 127 Fade in (0-100%) 128 - 169 Automatic Slow 050 - 099...
  • Page 17: Manutenzione

    LASERCOMBY - 4 - MANUTENZIONE 4.1 MANUTENZIONE E PULIZIA DISPOSITIVO • Durante gli interventi, assicurarsi che l’area sotto il luogo di installazione sia libera da personale non qualificato. • Spegnere l’unità, scollegare il cavo di alimentazione ed aspettare finché l’unità non si sia raffreddata.
  • Page 18 All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be reproduced in any form or by any means for any commercial use. In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
  • Page 19: Lasercomby

    3. 12 Connection of the DMX line 3. 13 Construction of the DMX termination 3. 14 DMX control 4 Maintenance 4. 1 Maintenance and cleaning the unit 4. 2 Trouble shooting Warranty Packing content • LASERCOMBY • Power cable • User manual...
  • Page 20: General Instructions

    LASERCOMBY WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit. SAFETY General instruction • The products referred to in this manual conform to the European Community Directives and are there- fore marked with .
  • Page 21: Laser Safety And Operating Instructions

    LASERCOMBY Laser safety and operating instructions • Do not operate laser without first reading and understanding all safety and technical data in this man- ual. • This laser product can potentially cause instant eye injury or blindness if laser light directly strikes the eyes.
  • Page 22: General Information

    LASERCOMBY LASER SAFETY LABEL REPRODUCTIONS • Class 3B laser radiation, when open, avoid exposure to beam. • Laser radiation avoid exposure to beam class 3B laser product. • The label indicates the laser beam output aperture. CAUTION LASER APERTURE CLASS 3B LASER LIGHT WHEN OPEN...
  • Page 23: Introduction

    LASERCOMBY - 1 - INTRODUCTION 1.1 DESCRIPTION Combo laser effect with Laser+LED source for multi-beam laser projection, motion effects and lounge deco. The Tri-Colour LED source combined with green and red laser diode offers a wide effect generation, that can be controlled by DMX or from the control panel. Its concept and versatility makes DIAMOND142L suitable for application in clubs, disco and mobile DJ se.
  • Page 24: Operating Elements And Connections

    LASERCOMBY 1.3 OPERATING ELEMENTS AND CONNECTIONS LASER APERTURE LASER RADIATION Front view Fig.1 1. MOUNTING BRACKET 2. LOCKING KNOB for the mounting bracket 3. LED APERTURE 4. LASER APERTURE...
  • Page 25 LASERCOMBY Rear view Fig.2 5. DMX OUT (3-pole XLR): 10. GND POINT grounding the fixture to the earth 1 = ground, 2 = DMX -, 3 = DMX + 11. SAFETY EYE to attach safety cable 6. DMX IN (3-pole XLR): 12.
  • Page 26: Installation

    2.1 MOUNTING LASERCOMBY may be set up on a solid and even surface. The unit can also be mounted upside down to a cross arm. For fixing, stable mounting clips are required. The mounting place must be of sufficient stability and be able to support a weight of 10 times of the unit’s weight.
  • Page 27: Functions And Settings

    3.1 OPERATION Connect the supplied main cable to a socket (230 V~/50 Hz). Switch on the LASERCOMBY with the mains switch (13). To switch on the laser beam, connect the supplied key to the lock of the switch (9) and turn the key to position ON.
  • Page 28: Menu Structure

    LASERCOMBY 3.3 MENU STRUCTURE MODE PROGRAMMING STEPS DESCRIPTION Automatic Mode, Fast Automatic Mode, Slow Automatic Programs Sound Active Mode Random Effect Mode Sound Sensitivity S 0 - S 9 Manually adjust the LED color and strobe rate (r 0 - r 9)
  • Page 29: Led Color Mixing

    LASERCOMBY • Press the button ENTER to save the setting. 3.6 LED COLOR MIXING You are able to manually mix the colors and strobe rate of the LED portion of the product. To do so, follow the steps below: • Press [MENU] button repeatedly until [LEd], [rGb], or [FdE] shows on the display.
  • Page 30: Dmx Operation

    3.11 DMX ADDRESSING To able to operate the LASERCOMBY with a light controller, adjust the DMX start address for the first a DMX channel. If e. g. address 33 on the controller is provided for controlling the function of the first DMX channel, adjust the start address 33 on the LASERCOMBY.
  • Page 31: Connection Of The Dmx Line

    LASERCOMBY 3.12 CONNECTION OF THE DMX LINE DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω imped- ance and low capacity. The following diagram shows the connection mode: DMX - INPUT DMX - OUTPUT XLR plug XLR socket...
  • Page 32: Dmx Control

    LASERCOMBY 3.14 DMX CONTROL CH12 CH Function in CH12 mode Value CH Function in CH12 mode Value Green AUTO MODE DMX Mode 000 - 049 Green 000 - 127 Fade in (0-100%) 128 - 169 Automatic Slow 050 - 099...
  • Page 33: Maintenance

    LASERCOMBY - 4 - MAINTENANCE 4.1 MAINTENANCE AND CLEANING THE UNIT • Make sure the area below the installation place is free from unwanted persons during setup. • Switch off the unit, unplug the main cable and wait until the unit has cooled down.
  • Page 35 Place Stamp Here Affrancare Spett.le Music&Lights S.r.l. Via Appia Km 136.200 04020 Itri (LT) Italy "...
  • Page 40 Music & Lights S.r.l. entertainment technologies Via Appia km 136,200 - 04020 Itri (LT) ITALY ISO 9001:2008 tel. +39 0771 72190 fax +39 0771 721955 Certified Company www.musiclights.it info@musiclights.it...
