  • Page 1 LUMIPAR12UAW SUpER-SLiM pARLED MANUALE UTENTE USER MANUAL IT - EN...
  • Page 2 Music & Lights S.r.l. si riserva ogni diritto di elaborazione in qualsiasi forma delle presenti istruzioni per l’uso. La riproduzione - anche parziale - per propri scopi commerciali è vietata. Al fine di migliorare la qualità dei prodotti, la Music&Lights S.r.l. si riserva la facoltà di modificare, in qualunque momento e senza preavviso, le specifiche menzionate nel presente manuale di istruzioni.
  • Page 3: Table Of Contents

    3. 15 Funzionamento tramite il controller IRC 4 Manutenzione 4. 1 Manutenzione e pulizia del sistema ottico 4. 2 Sostituzione fusibile 4. 3 Risoluzione dei problemi Certificato di garanzia Contenuto dell'imballo: • LUMIPAR12UAW • Staffa di fissaggio (2pz.) • Cavo di alimentazione • Manuale utente...
  • Page 4: Sicurezza

    LUMipAR12UAW ATTENZIONE! Prima di effettuare qualsiasi operazione con l’unità, leggere con attenzione questo manuale e conservarlo accuratamente per riferimenti futuri. Contiene informazioni importanti riguardo l’installazione, l’uso e la manutenzione dell’unità. SICUREZZA Avvertenze generali • I prodotti a cui questo manuale si riferisce sono conformi alle Direttive della Comunità Europea e per- tanto recano la sigla .
  • Page 5: Informazioni Generali

    LUMipAR12UAW INFORMAZIONI GENERALI Spedizioni e reclami Le merci sono vendute “franco nostra sede” e viaggiano sempre a rischio e pericolo del distributore/clien- te. Eventuali avarie e danni dovranno essere contestati al vettore. Ogni reclamo per imballi manomessi dovrà essere inoltrato entro 8 giorni dal ricevimento della merce.
  • Page 6: Introduzione

    PAR, offrendo una maggiore versatilità, rapidità di montaggio e cablaggio, facilità di trasporto. LUMIPAR12UAW è compatibile con il controller remoto ad infrarossi, per un utilizzo intuitivo ed interatti- vo senza la necessità di unità DMX esterne; può essere controllato in wireless attraverso il ricevitore Wi-Fi USB opzionale, in combinazione con Wifibox e l’App SmartColor per smartphone.
  • Page 7 LUMipAR12UAW ELETTRONICA • Dimmer: 0~100% lineare, Elettronico • Temperatura d’esercizio: -10° / 45° • Flicker: Flicker free ALIMENTAZIONE • Power Supply: 100-240V – 50/60Hz • Potenza assorbita (a 230V): 61 W • Potenza assorbita (a 120V): 61,5 W • Output (a 230V): 40 • Output (a 120V): 21...
  • Page 8: Elementi Di Comando E Di Collegamento

    LUMipAR12UAW 1.3 ELEMENTI DI COMANDO E COLLEGAMENTI Versione con DMX 3/5 poli Fig.2 - Pannello posteriore con 5 pole DMX 1. STAFFA DI MONTAGGIO 8. MICROFONO per il comando tramite segnale 2. MANOPOLA DI FISSAGGIO per la staffa di musicale montaggio.
  • Page 9: Installazione

    - 2 - INSTALLAZIONE 2.1 MONTAGGIO Il LUMIPAR12UAW può essere collocata su un piano solido. Inoltre, grazie alle possibilità di fissaggio sulla doppia staffa (fig.3), l’unità può essere montata anche a testa in giù, su una traversa. Per il fissaggio oc- corrono dei supporti robusti per il montaggio.
  • Page 10: Funzioni E Impostazioni

    Per maggiore comodità è consigliabile collegare l’unità con una presa comandata da un interruttore. 3.2 IMPOSTAZIONE BASE Il LUMIPAR12UAW dispone di un LED display e 4 pulsanti per accesso alle funzioni del pannello di controllo (fig.4). MENU UP DOWN ENTER...
  • Page 11: Struttura Menu

    LUMipAR12UAW 3.3 STRUTTURA MENU MENU ð 3 CH d1 - d512 DMX Personality and Selects DMX personality and DMX starting ð Starting Address value 7 CH d1 - d512 ð Static Colors C1 - C7 Selects 1 of 7 static colors ð...
  • Page 12: Modalità Musicale

    3.10 CONFIGURAZIONE CANALI DMX Il LUMIPAR12UAW dispone di due configurazioni dei canali DMX a cui si può accedere dal pannello di con- trollo. • Premere il tasto MENU per selezionare la configurazione dei canali DMX che si desidera (3CH - 7CH). Pre- mere il tasto ENTER per confermare.
  • Page 13: Indirizzamento Dmx

    DMX per il primo canale DMX. Se, per esempio, sull’unità di comando è previsto l’indirizzo 33 per comandare la funzione del primo canale DMX, si deve impostare sul LUMIPAR12UAW l’indirizzo di start 33. Le altre funzioni del pannello saranno assegnate automaticamente agli indirizzi successivi.
  • Page 14: Collegamenti Della Linea Dmx

    LUMipAR12UAW 3.12 COLLEGAMENTI DELLA LINEA DMX La connessione DMX è realizzata con connettori standard XLR. Utilizzare cavi schermati, 2 poli ritorti, con impedenza 120Ω e bassa capacità. Per il collegamento fare riferimento allo schema di connessione riportato di seguito: DMX - INPUT...
  • Page 15: Canali Dmx

    LUMipAR12UAW 3.14 CANALI DMX 3 CANALI 7 CANALI MODE MODE FUNCTION FUNCTION Value Value 3 Ch 7 Ch AMBER AMBER 0~100% 000 - 255 0~100% 000 - 255 COLD WHITE COLD WHITE 0~100% 000 - 255 0~100% 000 - 255...
  • Page 16: Funzionamento Tramite Il Controller Irc

    LUMipAR12UAW 3.15 FUNZIONAMENTO TRAMITE IL CONTROLLER IRC Per comandare Il LUMIPAR12UAW con il telecomando a raggi infrarossi: • Premere il tasto MENU fino a quando sul display non appare SET, quindi premere ENTER per confermare. • Utilizzare i tasti UP/DOWN per selezionare On oppure Off a seconda che si voglia attivare oppure disatti- vare il controllo con il telecomando a raggi infrarossi.
  • Page 17: Manutenzione

    LUMipAR12UAW - 4 - MANUTENZIONE 4.1 MANUTENZIONE E PULIZIA DEL SISTEMA OTTICO • Durante gli interventi, assicurarsi che l’area sotto il luogo di installazione sia libera da personale non qualificato. • Spegnere l’unità, scollegare il cavo di alimentazione ed aspettare finché l’unità non si sia raffreddata.
  • Page 19 LUMipAR12UAW...
  • Page 20 All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be reproduced in any form or by any means for any commercial use. In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
  • Page 21 3. 14 DMX control 3. 15 Operation through the IRC controller 4 Maintenance 4. 1 Maintenance and cleaning the unit 4. 2 Fuse replacement 4. 3 Troubleshooting Warranty Packing content • LUMIPAR12UAW • Mount bracket (2pc.) • Power cable • User manual...
  • Page 22: General Instructions

    LUMipAR12UAW WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit. SAFETY General instruction • The products referred to in this manual conform to the European Community Directives and are there- fore marked with .
  • Page 23: General Information

    LUMipAR12UAW GENERAL INFORMATION Shipments and claims The goods are sold “ex works” and always travel at the risk and danger of the distributor. Eventual dam- age will have to be claimed to the freight forwarder. Any claim for broken packs will have to be forwarded within 8 days from the reception of the goods.
  • Page 24: Introduction

    - 1 - INTRODUCTION 1.1 DESCRIPTION LUMIPAR12UAW is a super-slim ParLED for professional use, designed to be a powerful wash-light. It’s equipped with 12x8W high efficiency tunable white/ambra LEDs light source, conceived to offer an ad- vanced color generation with full control on color saturation and temperature. LUMIPAR12UAW is compat-...
  • Page 25 LUMipAR12UAW • Master/Slave: for synchronized operation of more units linked in a chain ELECTRONICS • Dimmer: Linear 0~100% electronic dimmer • Operating Temperature: -10° / 45° • Flicker: Flicker free operation ELECTRICAL • Power Supply: 100-240V – 50/60Hz • Power Consumption (at 230V): 61 W •...
  • Page 26: Operating Elements And Connections

    LUMipAR12UAW 1.3 OPERATING ELEMENTS AND CONNECTIONS Fig.2 - Rear panel with 5 pole DMX 1. MOUNTING BRACKET external audio signal. 2. LOCKING KNOB for the mounting bracket 9. DMX OUT (5-pole XLR): 3. GND POINT grounding the fixture to the earth.
  • Page 27: Installation

    2.1 MOUNTING LUMIPAR12UAW may be set up on a solid and even surface. The unit can also be mounted upside down to a cross arm. For fixing, stable mounting clips are required. The mounting place must be of sufficient stabil- ity and be able to support a weight of 10 times of the unit’s weight.
  • Page 28: Functions And Settings

    LUMipAR12UAW - 3 - FUNCTIONS AND SETTINGS 3.1 OPERATION Connect the supplied main cable to a socket (100-240 VAC-50/60 Hz). Then the unit is ready for operation and can be operated via a DMX controller or it independently performs its show program in succession.
  • Page 29: Menu Structure

    LUMipAR12UAW 3.3 MENU STRUCTURE MENU ð 3 CH d1 - d512 DMX Personality and Selects DMX personality and DMX starting ð Starting Address value 7 CH d1 - d512 ð Static Colors C1 - C7 Selects 1 of 7 static colors ð...
  • Page 30: Sound Mode

    3.10 DMX CONFIGURATION LUMIPAR12UAW is equipped with different DMX configuration. • Press the button MENU to select the desired DMX configuration (3CH - 7CH), then press the button ENTER. • Press the button UP/DOWN to select the desider value (001 - 512), then press the button ENTER to con- firm.
  • Page 31: Dmx Addressing

    3.11 DMX ADDRESSING To able to operate the LUMIPAR12UAW with a light controller, adjust the DMX start address for the first a DMX channel. If e. g. address 33 on the controller is provided for controlling the function of the first DMX channel, adjust the start address 33 on the LUMIPAR12UAW.
  • Page 32: Connection Of The Dmx Line

    LUMipAR12UAW 3.12 CONNECTION OF THE DMX LINE DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω imped- ance and low capacity. The following diagram shows the connection mode: DMX - INPUT DMX - OUTPUT XLR plug XLR socket...
  • Page 33: Dmx Control

    LUMipAR12UAW 3.14 DMX CONTROL 3 CHANNELS 7 CHANNELS MODE MODE FUNCTION FUNCTION Value Value 3 Ch 7 Ch AMBER AMBER 0~100% 000 - 255 0~100% 000 - 255 COLD WHITE COLD WHITE 0~100% 000 - 255 0~100% 000 - 255...
  • Page 34: Operation Through The Irc Controller

    LUMipAR12UAW 3.15 OPERATION THROUGH THE IRC CONTROLLER To control the LUMIPAR12UAW with the infrared remote control: • Press the button MENU repeatedly until SET, then press button ENTER to confirm. • Using UP/DOWN button to select On or Off to enable or disable the infrared remote control.
  • Page 35: Maintenance

    LUMipAR12UAW - 4 - MAINTENANCE 4.1 MAINTENANCE AND CLEANING THE UNIT • Make sure the area below the installation place is free from unwanted persons during setup. • Switch off the unit, unplug the main cable and wait until the unit has cooled down.
  • Page 36 LUMipAR12UAW...
  • Page 37 Place Stamp Here Affrancare Spett.le Music&Lights S.r.l. Via Appia Km 136.200 04020 Itri (LT) Italy "...
  • Page 40 MUSIC & LIGHTS S.r.l. Via Appia, km 136,200 - 04020 Itri (LT) - ITALY Phone +39 0771 72190 - Fax +39 0771 721955 www.musiclights.it - email: info@musiclights.it ISO 9001:2008 Certified Company...
