Valve Body Material:
Actuator Material:
Applicable Water Pipe Size:
Valve Dimension:
Environment:
(Indoor Use Only!)
Brass
Engineering Plas cs
1/2 inch (DN15), 3/4 inch (DN20), 1 inch (DN25),
1-1/4 inch (DN32)
Dn15: 1/2ʺ NPT female thread connec on, 0.59inch (15mm)
full bore
DN20: 3/4ʺ NPT female thread connec on, 0.79inch (20mm)
full bore
DN25: 1ʺ NPT female thread connec on, 0.91inch (23mm)
reduce bore
DN32: 1-1/4ʺ NPT female thread connec on, 1.14inch (29mm)
reduce bore
Working Temperature: 5°F - 122°F (-15°C - 50°C)
(liquid temperature: 35.6°F - 194°F(2°C - 90°C))
47
