- Page 1 OPERATING INSTRUCTIONS Translation of the original instructions TVV 001 Fore-vacuum safety valve...
-
Page 2: Table Of Contents
Table of contents Table of contents About this manual ..........3 1.1 Validity. -
Page 3: About This Manual
About this manual Validity This operating manual is for customers of Pfeiffer Vacuum. It describes the functioning of the designated product and provides the most important information for safe use of the unit. The description follows applicable EU guidelines. All information provided in this operating manual refers to the current state of the product's development. -
Page 4: Safety
● The fore vacuum safety valve serves to the installation in a fore-vacuum line between a turbopump and a backing pump. ● The fore vacuum valve TVV 001 serves to protect a turbopump against unintended venting via the fore-vacuum line in the case the backing pump stops. -
Page 5: Product Description
115 V AC, 50/60 Hz Function The fore vacuum safety valve TVV 001 is a direct acting 2/2-way solenoid valve with manual override and adjustable switch-on delay. The valve is qualified for the fitting into a fore vacuum line between a turbopump and a backing pump. It protects the turbopump against unintended venting in case the backing pump stops. -
Page 6: Installation
Ensure the system is adequately earthed. Potentiometer for switch-on delay Fig. 2: Contact diagram and components plan on valve plug for TVV 001 Observe the information on the rating plae. Unscrew the protection cover from the valve plug. -
Page 7: Operation
Anti-clockwise Delay time becomes longer Manual operation The fore-vacuum safety valve TVV 001 can be opened by manual actuation in an emer- gency. Press the button on the valve body and turn it clockwise to lock it. – In locked manual actuation the valve is blocked electrically. -
Page 8: Technical Data
Technical data Technical data Parameter TVV 001 TVV 001 Flange (in) DN 16 ISO-KF DN 16 ISO-KF Flange (out) DN 16 ISO-KF DN 16 ISO-KF Leak rate 1 · 10 Pa m 1 · 10 Pa m Ambient temperature 0-55 °C 0-55 °C... -
Page 9: Declaration Of Conformity
We hereby declare that the product cited below satisfies all relevant provisions accord- ing to the following EC directives: ● Electromagnetic Compatibility 2014/30/EU ● Low Voltage 2014/35/EU TVV 001 Harmonised standards and national standards and specifications which have been ap- plied: EN 50081-2... - Page 10 VACUUM SOLUTIONS FROM A SINGLE SOURCE Pfeiffer Vacuum stands for innovative and custom vacuum solutions worldwide, technological perfection, competent advice and reliable service. COMPLETE RANGE OF PRODUCTS From a single component to complex systems: We are the only supplier of vacuum technology that provides a complete product portfolio.
