Permitted torch coolant

Coolant
blueCool -10
KF 23E (Standard)
KF 37E
blueCool -30
5.3.2.2

Maximal hose package length

All information relates to the total hose package length of the complete welding system and presents ex-
emplary configurations (of components of the EWM product portfolio with standard lengths). A straight
kink-free installation is to be ensured, taking into account the max. delivery height.
Pump: Pmax = 3,5 bar (0.35 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
Pump: Pmax = 4.5 bar (0.45 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
099-011445-EW501
24.06.2021
Hose package Wire feeder
(20 m / 65 ft.)
(25 m / 82 ft.)
(15 m / 49 ft.)
Hose package Wire feeder
(30 m / 98 ft.)
(40 m / 131 ft.)
(40 m / 131 ft.)
Temperature range
-10 °C to +40 °C (14 °F to +104 °F)
-10 °C to +40 °C (14 °F to +104 °F)
-20 °C to +30 °C (-4 °F to +86 °F)
-30 °C to +40 °C (-22 °F to +104 °F)
miniDrive
(25 m / 82 ft.)
(10 m / 32 ft.)
miniDrive
(25 m / 82 ft.)
(25 m / 82 ft.)
Design and function
Transport and installation
Welding torch Max.
(5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
(5 m / 16 ft.)
Welding torch Max.
(5 m / 16 ft.)
131 ft.
(5 m / 16 ft.)
147 ft.
(5 m / 16 ft.)
229 ft.
(5 m / 16 ft.)
30 m
98 ft.
30 m
98 ft.
40 m
45 m
70 m
