Addi Buffet
Assembly Instructions
15
NOTE: If the doors are uneven or
there is a gap in the middle, loosen
or tighten the screw on the door
hinge until they are sitting flush.
3
12
Secure panels [11] and [12] to panels [3], [4] and [6] by attaching the
other end of the 4x hinges (F) and 2x hinges (G) with 24x screws (E).
Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
E
F
G
11
E
6
11
G
E
E
16
V
Z
W
1
V
Z
W
8
Attach 8x wedges (J) into the corners of the back of the unit and secure
with 8x screws (K). Tighten with a screwdriver. Attach 2x safety straps (V)
to the top of the back side of the unit as shown using 2x washers (Z) and
2x screws (W). Tighten with a screwdriver.
J
K
V
J
Z
K
W
8
8
