Daikin ARM09MV2S Service Manual page 5

Si011356EA
Step
Lift up the left side and
4
unfasten the hooks.
Release the right side
5
hooks and remove the
front panel.
Press the 2 projections
6
from the rear side and
rotate the discharge
grille to remove it.
Removal Procedure
Procedure
Discharge grille
Projection (rear side)
Points
(R20743)
(R20744)
(R16323)
Outer Panels
3
