Daikin ARM09MV2S Service Manual page 11

Si011356EA
Step
Pull out the terminals
10
from the magnetic
contactor (K1M).
Remove the 2 screws
11
and remove the
magnetic contactor
(K1M).
Pull out the terminals
12
from the compressor
capacitor (C1R).
Remove the 2 screws
13
to loosen the capacitor
fixing band and remove
the compressor
capacitor (C1R).
Pull out the harnesses
14
from the terminal board
(X1M).
Removal Procedure
Procedure
to X1M (3)
: white
to X1M (2)
K1M
: white
to compressor (S terminal)
: yellow
to compressor
(R terminal)
: red
to X1M (3)
: black
to K1M (0): white
to K1M (4): red
to K1M (8)
X1M
: red (fuse)
(1)
to X1M (1)
: red (fuse)
to X1M (1)
: red
to compressor
(C terminal)
: blue
(R20772)
red
C1R
(R20746)
to C1R: black
X1M
X1M
(3)
(2)
Electrical Components
Points
Compressor lead wire
For R-410A models
R (V)
S (W)
C (U)
(R15375)
For R-32 models
R ( V )
C ( U )
S ( W )
( R20742 )
S (W): yellow
C (U): blue
R (V): red
to K1M (1): white
to earth / ground wire
: green / yellow
X1M
(R20741)
9
