- Page 1 UNI-ClipDoc Users’ Manual FERNO/MAN/0721/220-R2/UK Stock Code 2003-0150 Read this Manual and Retain for Future Reference...
- Page 2 ALL OTHER LOCATIONS For assistance or information, please contact your Ferno SERIAL Number plate 2 _________________________________ distributor. If you do not have a Ferno distributor, please contact your nearest Ferno Customer Services office. UNI-ClipDoc serial number(s) are marked on the manufacturer's...
-
Page 3: Table Of Contents
1 - Safety Information _______________________________ 4 Warnings ___________________________________ 4 Important Notices ____________________________ 4 Cautions ___________________________________ 4 Trolley and Lock Compatibility with UNI-ClipDoc ___ 4 Safety and Instruction Labels ___________________ 5 Symbol Glossary _____________________________ 5 2 - Operator Skills and Training _______________________ 6... -
Page 4: Safety Information
UNI-ClipDoc, operate the controls and direct all strap cross bars to attach to a trolley with tubular top-rail or using helpers. the clamp cross bars to attach to the Ferno siderail interface on trolleys such as PowerX and iNX. Improper maintenance can cause injury. Maintain the UNI-ClipDoc only as described in this manual. -
Page 5: Safety And Instruction Labels
Safety and instruction labels place important information from The symbols defined below are used on the trolley and/or in this the user manual on the trolley. user manual. Ferno uses symbols recognised by the International Standards Organisation (ISO). Read and follow label instructions. Replace worn or damaged labels immediately. -
Page 6: Operator Skills And Training
To have a working knowledge of manual handling procedures WARNING Untrained operators can cause injury or be injured. Permit only trained personnel to operate the UNI-ClipDoc WARNING Improper use of the UNI-ClipDoc can cause injury. Use the UNI-ClipDoc only for the purpose described in this manual. FERNO/MAN/0721/220-R2/UK... -
Page 7: About Uni-Clipdoc
3.2 - Auxiliary Bridging plate (Optional) Also available as an option for UNI-ClipDoc is a bridging plate, to bridge the gap between aircraft floor and trolley where the trolley cannot be brought directly up to the aircraft, facilitating transfer directly from aircraft floor to UNI-ClipDoc without the need to lift the patient platform. -
Page 8: General Product Information
UNI-ClipDoc 4.0 - GENERAL PRODUCT INFORMATION 4.1 Product Specification Overall length: 1955 mm Overall width (Max. over clamp bars): 585 mm Overall depth (Max. over clamp bars): 205 mm Overall weight (full kit including carry bags): 32.3 kg (not including optional bridging plate) -
Page 9: Uni-Clipdoc Components And Storage
4.3 UNI-ClipDoc Components and Storage It is important that the various Uni Clip Doc components Each UNI-ClipDoc half-section has its own storage bag. are all stored according to the instructions above to avoid The serial number of each section is also displayed on the parts going missing or getting mixed up with other UNI- outside of the bag. -
Page 10: Operation Of Uni-Clipdoc
PANELS INTO THE FULLY FLAT POSITIONS 5.2 Assembly of UNI-ClipDoc • REMOVE ANY OTHER ACCESSORIES WHICH UNI-ClipDoc can be split into two sections to aid storage MAY INTERFERE WITH CORRECT OPERATION and transport when not in use. Assembly / dis-assembly OF THE UNI-CLIP DOC of the UNI-ClipDoc requires two operators and does not require the use of any tools. -
Page 11: Installation Using Clamp Fixing-Bars
5.0 - OPERATION Installation using clamp fixing-bars The clamp fixing-bars are used when attaching the UNI-ClipDoc to Ferno PowerX or iNX trolleys. The clamp fixing-bars have three different configurations. The correct configurations required for installation on the various trolleys are shown below. -
Page 12: Installation Using Ratchet-Strap Fixing-Bars
The Uni-ClipDoc is now ready for use. Installation using the ratcheting fixing-bars With the ratcheting fixing-bars installed in the appropriate positions, offer the UNI-ClipDoc up to the trolley and position it centrally across the length and width of the trolley top. - Page 13 STRAP AROUND ANY OTHER PART OF THE TROLLEY FIG 5 FIG 6 Hook the tang onto one of the two fixing points on the UNI-ClipDoc fixing-bar. FIG 7 FIG 8 Pull on the loose end of the strap to take up the slack.
-
Page 14: Removal Of Fixing-Bars
The tang can then be removed from the fixing point. The strap can be left hanging freely as the Uni-ClipDoc is lifted clear of the trolley. Remember to return the ratchet handle to the locked position to prevent damage during storage. -
Page 15: Emergency Pin Release
5.0 - OPERATION Emergency pin release The UNI-ClipDoc features an emergency pin release system to be used if the locking pins on the incubator / AeroSled are damaged in an accident or get stuck in the locked position. To release stuck locking pins, apply force / use a blunt object to drive the four spring loaded release pins as shown below. -
Page 16: Spare Parts, Service
UNI-ClipDoc Parts and Service 6.0 - SPARE PARTS, SERVICE Spare Parts Below are the Part Numbers and names of parts available to maintain your UNI-ClipDoc 6.2 UK Support Numbers In the United Kingdom to order parts or for professional repair,... -
Page 17: Maintenance
º º Wipe all surfaces with disinfectant. Follow the disinfectant Your Ferno Trolley will work efficiently and safely only when it is manufacturer’s instructions for application method and contact lubricated. You MUST lubricate all moving and sliding parts after time. Ferno recommends you inspect the trolley for damage as every inspection or preventative maintenance programme, or if you clean and disinfect it. -
Page 18: Inspecting The Trolley And Uni-Clipdoc
7.6 - Inspecting the Trolley and UNI-ClipDoc before use To ensure consistently safe operation of the trolley and UNI-ClipDoc interface and to monitor wear and tear, prior to each use, ensure the trolley is thoroughly checked in compliance with the following checklist.
