Roverpet Kali-Ko Kathouses K666W Assembly Instructions

Kali-Ko Kathouses 20 Kiji Dava Circle Prescott, Arizona 86301 1-800-658-5925 rover@roverpet.com
Assembly Instructions Kali-Ko Kathouse #K666W
72" high
Inventory: The Kali-Ko Kathouse #K666W consists of (11) #C72
panels (with #FDC fold down clips attached) (1) #C72 72" high single door (1)
#F26 shelves (2) #F26W pre drilled floor (6) #S31 shelf support braces (84) #250
floor divider clips (3) #C72C lids (tops) (84) #200 panel clips (3) #175 door clips
(3) #LC locking casters (3) #NLC non locking casters (6) #CWC caster wheel
clips. The panels will already have been snapped together in marked sections
(front right, front left, etc.). Each section consists of 4 panels each.
*NOTE: Please make sure your inventory is complete!
Step 1: Unwrap the marked sections, placing them where described, and stretch
out the panels in the shape of a 6' x 6' enclosure, making sure the door is in the
middle of one side of the enclosure. Connect the sections together by snapping
the #200 panel clips to the adjoining sections. DO NOT connect the door panel
with the panel to its right yet.
Step 2: With the door panel open step inside the enclosure and 'fold down' all
the #FDC fold down clips around the perimeter of the enclosure. Next, take a
#F26 shelf and place it to the left on the fold down clips which are 2/3 of the way
up the enclosure. Place the shelf with the flat side up, and let the pipe rest on the
#FDC fold down clips. Secure in place by snapping on (10) #250 floor divider
clips (2 per 2 ft. section); snapping them to the shelf's pipe and the panel's
centerbar. Place the #250 floor divider clips underneath and inside of the #FDC
clips. (See figure 1 below of the underside of the shelf.) Place the next shelf on
the fold down clips to the right and secure in the same manner. The last shelf
will go 1/3 of the way up on the back panels of the enclosure.
