Roverpet WB3044DSF Assembly Instructions

30” high 4' x 4' whelping box

Roverpet

20 Kiji Dava Circle Prescott, Arizona 86301

Roverpet #WB3044DSF 30" high 4' x 4' Whelping Box Assembly Instructions

Inventory list for The Roverpet #WB3044DSF Whelping Box:

(7) #130 30" high panels

(1) #44PR4 4" high puppy rail assembly (two leg bars, two cross-bars and four legs

(1) #44DPK Designer Puppy Keeper (6" high)

(12) #250 floor/divider clips (24) #200 panel clips (pre-assembled onto frames by Roverpet)

Assembly Procedure

1.) Unpack contents of shipping carton and compare to parts list above.

2.) Layout the two #130 panels / #D30 door sub-assemblies as show below, with the assembly containing the door

positioned on the right side.

#200 panel clips- pre-attached

to end panels here by Rover

Co.

3.) Connect the ends of the sub-assemblies together with the #200 panel clips that are already attached to the end

panels; reposition panels into a square shape resembling the main photo at the top of this page.

4.) Install #180 straight stabilizers onto the top of in-line connected panels (left photo below) and install #90 corner

stabilizers onto the top of corner connected panels (right photo below).

5.) Lay floor trays side-by-side into the bottom of the Roverpet whelping box with the frame pipes facing up to allow

connection to the side panels.

(1) #D30 30" high door (2) #F24 2'x4' floors

1-800-658-5925

(4) #180 straight stabilizers

rover@roverpet.com

(4) #90 corner stabilizers

Page 1 of 3
