Roverpet KK2 Assembly Instructions

Roverpet
20 Kiji Dava Circle Prescott, Arizona 86301
Roverpet #KK2 Cat Climber Assembly Instructions
Inventory: The Roverpet #KK2 Cat Climber consists of:
(2) #24TLC legs, (2) #18TAC arms, (4) #34URP uprights,
(4) #17CBC crossbars (17" long), (4) #23CBC crossbars (23" long),
(10) #250 clips, (2) FDC wall attachment clips (2) sheepskin pads
(2) #CSR12 cat scratch rollers
Note: #250 clips are for attaching this #KK2 Cat Climber module to an existing #KK3 Cat
Climber for purposes of expansion.
1.) Unpack shipping carton and inspect quantity of components against
inventory list above.
2.) Connect the two #24TLC legs together by inserting two #17 CBC
crossbars into the holes between them as seen in the photo below.
3.) Insert the four #34URP uprights into the upward facing holes of the
#24TLC legs in the following manner: the two pipes identified with red
marks on their tops are to go into the lower left and upper right locations
as viewed with one of the long faces of the assembly positioned in front of
you. Turn the upper-most holes in the uprights to face each other across
the longer faces of the assembly as shown in the left photo at the top of
the next page.
