Manuel du Propriétaire
Owner's Manual
Eigner Handbuch
Manuele del Propriétario
Manual del Propietario
HEAVY DUTY
MARK 4 – MARK 5 – MARK 6
Z65071
Octobre 2013
LIRE ATTENTIVEMENT CE MANUEL AVANT LA MISE EN SERVICE DE VOTRE ZODIAC.
READ THIS MANUAL CAREFULLY BEFORE USING YOUR BOAT.
VOR BENUTZUNG IHRES BOOTES LESEN SIE DIESES HANDBUCH SORGFÄLTIG DURCH.
LEGGERE ATTENTAMENTE IL PRESENTE MANUALE PRIMA DI UTILIZZARE IL BATTELLO.
ANTES DE UTILIZAR LA EMBARCACIÓN, LEA ESTE MANUAL CON ATENCIÓN.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Zodiac MILPRO HEAVY DUTY Series
Summary of Contents for Zodiac MILPRO HEAVY DUTY Series
- Page 1 MARK 4 – MARK 5 – MARK 6 Z65071 Octobre 2013 LIRE ATTENTIVEMENT CE MANUEL AVANT LA MISE EN SERVICE DE VOTRE ZODIAC. READ THIS MANUAL CAREFULLY BEFORE USING YOUR BOAT. VOR BENUTZUNG IHRES BOOTES LESEN SIE DIESES HANDBUCH SORGFÄLTIG DURCH.
-
Page 2: Table Of Contents
VOLUME 2 • • • • READ THIS MANUAL CAREFULLY BEFORE USING YOUR BOAT. • • • • THIS OWNER’S MANUAL CONSISTS OF 2 VOLUMES THAT SHOULD BE KEPT TOGETHER. WARNING - The Owner’s Manual is divided into 2 volumes: - Volume 1 gives general rules of the road and boat use recommendations, which should be followed onboard during NOTE... -
Page 3: Warning
PROCEDURE FOR PUTTING THE BOAT INTO USE To identify the boat, turn to the APPENDIX: • technical specifications (page A-2, A-3), • description (page A-4, A-5). BOAT ASSEMBLY PROCEEDS IN A CERTAIN ORDER THAT WE RECOMMEND YOU FOLLOW CAREFULLY. REFER TO THE PAGES INDICATED BELOW FOR THE STEP BY STEP INSTRUCTIONS ATTENTION Procedure for putting the boat into use and storage... -
Page 4: The Inflation System
THE INFLATION SYSTEM The inflation system is composed of: INFLATION PUMP (a) adaptater (b) hose tip (c) hose base (d) air outliet To inflate : Place the hose tip in the air outlet, To inflate correctly, the pump should be flat on the ground, The boat will inflate rapidly if pumping is done at a regular calm rhythm,... - Page 5 Inflation position To deflate the buoyancy tube : Put the I/C valve in the « inflation » zone (red), Take the valve insert, with its cap, off the base. Navigation position 4/10...
-
Page 6: Boat Assembly
BOAT ASSEMBLY Illustrations in APPENDIX page A-8 Assemble the boat on a smooth clean surface. If the boat is stored in a temperature inferior to 32°F (0°C), before unfolding, let it warm up for 12 hours at room temperature, 72°F (about 20°C). -
Page 7: Boat Inflation
BOAT INFLATION Illustrations in APPENDIX page A-9 DO NOT USE AN AIR COMPRESSOR OR AN AIR CYLINDER. WARNING NOTE Do not inflate boats stacked one over the other. Insure that all valves are in the inflation position. Attach the pump hose tip to the valve on the buoyancy. - Page 8 AIR PRESSURE Before to check air pressure, put the I/C valve in the "INFLATION ZONE” NOTE (red). Operating pressure for the buoyancy tube and the keel is 240mb/3,4 PSI (in the middle of the green zone on the pressure indicator). We recommend the use of a manometer to check the inflation pressure.
-
Page 9: Air Pressure
AIR PRESSURE IN CASE OF UNDER PRESSURE Do some topping up : The standard valve: take off the cap, attach the pump to the valve, inflate to adjust the pressure, screw on the cap. I/C Valve: take off the cap, attach the pump to the valve, put all the I/C valves in the “inflation”... -
Page 10: Deflation/Folding Of The Boat
DEFLATION/FOLDING OF THE BOAT Take off all equipment. Deflate the boat: - put the valves in the inflation position (red), - take the valve inserts off the bases. Take off the floorboard, execute the assembly procedure in reverse. Put the valve inserts back on the bases. Take off the self bailer. -
Page 11: Inflatable Boat Storage After Use
INFLATABLE BOAT STORAGE AFTER USE To store the boat inflated: open the self bailers. Rince the boat with fresh water in order to remove any sand, seaweed, etc. Remove all water; make sure that no water is left in the boat before storage. 10/10... - Page 12 ANNEXES – APPENDIX – ANHANG – ALLEGATO – ANEXO ANNEXES Caractéristiques Techniques A2-A3 Description A4-A5 Illustrations : Montage du bateau Le systpeme de gonflage APPENDIX Technical Specifications A2-A3 Description A4-A5 Illustrations: Assembly of the boat Inflation system ANHANG Technische daten A2-A3 Beschreibung A4-A5...
- Page 13 CARACTERISTIQUES TECHNIQUES – TECHNICAL SPECIFICATIONS – TECHNISCHE DATEN – CARATTERISTICHE TECHNICHE - CARACTERISTICAS TECNICAS HEAVY DUTY MARK 4 MARK 5 MARK 6 DIMENSIONS – DIMENSIONS – ABMESSUNGEN – DIMENSIONI – DIMENSIONES 5,85 5,30 7,00 19’2” 17’5” 23’ (ft) 4,20 3,70 5,10 13’9”...
- Page 14 CARACTÉRISTIQUES TECHNIQUES – TECHNICAL SPECIFICATIONS – TECHNISCHE DATEN – CARATTERISTICHE TECHNICHE – CARACTERISTICAS TECNICAS Toutes les mesures indiquées sont susceptibles de varier de ± 3% NOTE All dimensions indicated have a tolerance of ± 3% NOTICE Alle angegebenen Abmessungen haben eine Toleranz von ± 3%. HINWEIS Tutte le dimensioni indicate hanno una tolleranza del ±...
- Page 15 DESCRIPTION – BESCHREIBUNG – DESCRIZIONE – DESCRIPCION...
- Page 16 DESCRIPTION – BESCHREIBUNG – DESCRIZIONE – DESCRIPCION Français English Deutch Italiano Español Quille gonflable Inflatable keel Aufblasbarer Kiel Chiglia gonfiabile Quilla hinchable Valve de gonflage Ventil für das Valvola di Válvula hinchado Keel inflation valve quille Aufblasen des Kiels gonfiaggio chiglia quilla Robinet d’inter- Rubinetto...
- Page 17 BOAT ASSEMBLY Fig. 1 a – floorboards b – hull/main buoyancy tubes Mark 4 – Mark 5 HD c – corner reinforcement d – bottom-hull Mark 6 HD Fig. 2: Make a tent & step on it to push boards down Mark 4 –...
-
Page 18: Inflation System
INFLATION SYSTEM... - Page 19 32 bis, boulevard Haussmann 75009 PARIS Z65071 Octobre 2013 © ZODIAC MILPRO INTERNATIONAL...
