NOTE:
TECHNICAL SPECIFICATIONS - ASSEMBLY PROCEDURE
Assembly procedure
Check on unpacking
Assembly
Inflation system
Inflating the boat
THE OWNER'S MANUAL IS IN TWO VOLUMES:
- VOLUME 1
DEALS
WITH
OPERATING
RECOMMENDATIONS THAT MUST BE OBSERVED.
- VOLUME 2
DEALS WITH TECHNICAL SPECIFICATIONS AND ASSEMBLY
PROCEDURE OF THE BOAT AND ITS EQUIPMENT.
VOLUME 2
ZODIAC
CLASSIC
MARK 1 - MARK 2C - MARK 2
CONTENTS
Page
2
2
3-4
5-6
7
1 /10
PRECAUTIONS
AND
Pressure
Deflation - folding the boat
APPENDIX
Table of technical specifications
General description
Assembly of bench (option)
Assembly of bow bag
SAFETY
E
N
G
L
I
S
H
Page
8
9
I - II
III – IV
V
VI
Advertisement
Related Manuals for Zodiac CLASSIC MARK 1
Summary of Contents for Zodiac CLASSIC MARK 1
- Page 1 RECOMMENDATIONS THAT MUST BE OBSERVED. - VOLUME 2 DEALS WITH TECHNICAL SPECIFICATIONS AND ASSEMBLY PROCEDURE OF THE BOAT AND ITS EQUIPMENT. VOLUME 2 TECHNICAL SPECIFICATIONS - ASSEMBLY PROCEDURE ZODIAC CLASSIC MARK 1 - MARK 2C - MARK 2 CONTENTS Page Page Assembly procedure...
- Page 2 V - VI ASSEMBLY OF EQUIPMENT CHECK ON UNPACKING DO NOT USE A SHARP TOOL (CUTTER, KNIFE, ETC.) ATTENTION The pack must contain: 1 buoyancy tube + ZODIAC CLASSIC MARK 1 MARK 2C MARK 2 Owner’s manual (2 volumes) ✓ ✓...
- Page 3 ASSEMBLY Choose a smooth and clean surface. IF THE BUOYANCY TUBE WAS STORED AT A TEMPERATURE BELOW 0°C / 32°F, LEAVE IT AT 20°C / 68°F FOR 12 HOURS BEFORE UNFOLDING. FLOORBOARD ASSEMBLY - INSTALLATION OF THE RIGID FLOORBOARD: • Sprinkle some starch in the angle (joint of the buoyancy tubes to the bottom – see figure 1.B) to facilitate fitting.
- Page 4 ASSEMBLY fig 1-A fig 1-B a- floorboard b- buoyancy tube c- angle d- bottom fig 2 fig 3 fig 4 4 / 10...
- Page 5 INFLATION SYSTEM THE FOOT PUMP a. connecting tip b. hose end piece c. hose base d. outlet for inflation THE STANDARD VALVES (1) cap (2) valve insert (3) base To activate the standard valves into INFLATION position: • Free the valve insert from its protection. •...
- Page 6 INFLATION SYSTEM PRESSURE INDICATOR 6 / 10...
- Page 7 INFLATING THE BOAT Activate all valves in inflating position Fix the hose base in the inflator inflating orifice To inflate your boat properly, the inflator should be correctly placed on the ground. The boat inflates rapidly if the inflator is used smoothly and without haste.
- Page 8 PRESSURE The correct pressure for the buoyancy tube and the keel is 240 mb/3,48 PSI (middle of the green area of the pressure indicator). ACCESS If your boat is not equipped with an pressure indicator, we recommend that you purchase one from your Dealer. This will permit a quick and efficient control of the pressure during inflation.
- Page 9 9 /10...
- Page 10 DEFLATING / FOLDING THE BOAT 1. Deflate the boat. 2. Put the valve protections back in position for storage. 3. Remove the various equipment items. 4. Remove the floorboard (apply the assembly procedure in the reverse order). 5. Empty the boat of all water and sand by opening the self-bailers (dry the boat thoroughly in case of long storage).
