FD201CV-LP
Installation and Operation Manual
20.1" Low-Profile LCD
TECHNICAL SUPPORT
678-867-6717, or
www.FlightDisplay.com

Advertisement

Table of Contents
loading

Summary of Contents for Flight Display Systems FD201CV-LP

  • Page 1 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 1 of 18 FD201CV-LP Installation and Operation Manual 20.1” Low-Profile LCD TECHNICAL SUPPORT 678-867-6717, or www.FlightDisplay.com...
  • Page 2 Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 2 of 18 FD201CV-LP 20.1” Low-Profile LCD © 2006 Flight Display Systems. All Rights Reserved. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004 678-867-6717 Phone 678-867-6742 Fax sales@flightdisplay.com www.flightdisplay.com For the most current copy of all product manuals, please visit our website at www.flightdisplay.com...
  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 3 of 18 Table of Contents General Information ........................4 1. Front View ..........................4 2. Additional Information ....................4 Installation Instructions ......................5 1. Power ..........................5 2.
  • Page 4: General Information

    Front View Additional Information The FD201CV-LP utilizes a state of the art digital video decoding chipset for the analog video input. The three video sources in order of picture quality are VGA (computer graphics like moving maps), S-Video and Composite Video (DVD, camera or VCR). Both NTSC and PAL formats are auto-detected.
  • Page 5: Installation Instructions

    FAA/PMA Approved Installation Instructions All cabin entertainment equipment, such as the FD201CV-LP, should be installed on a non-essential bus and have a dedicated circuit breaker. It is a requirement that a switch be installed in the cockpit so that the pilot can de-energize the entertainment system should it become necessary.
  • Page 6: Remote Eye

    Remote Eye The FD201CV-LP has a relocatable IR sensor, to maximize sensor visibility throughout the cabin. For example, an FD201CV-LP mounted on the right side of the bulkhead, may have its sensor located on the left side of the unit.
  • Page 7: Wiring Instructions

    All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 7 of 18 Wiring Suggestions All shields should be grounded to the connector at the source, and floating at the display. Avoid routing video wiring parallel to: ...
  • Page 8: Vga Wiring

    Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 8 of 18 VGA Wiring Recommended cable for VGA purpose is ECS P/N 453005. This is a single shielded cable containing 5 separate coaxial cables, color-coded to match the functions of the wires.
  • Page 9: Power & Ground Wiring

    Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 9 of 18 Power and Ground Wiring This is a 28VDC monitor that requires 3 amps of power to operate. To operate properly this monitor requires an input voltage of 24-29VDC.
  • Page 10: Power/Video

    All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 10 of 18 Power/Video Pin out for P1 (High Density DB-15 Receptacle) Connector P/N: M24308/2-286 or Equivalent Crimp Contacts P/N: M39029/57-354 or Equivalent...
  • Page 11: Operations Instructions

    No pilot or aircrew action is necessary during flight or ground operation. The passengers will be able to change the video output from the FD201CV-LP using the video source select button on the display, or remotely throughout the cabin with the included IR remote.
  • Page 12: Remote Control

    All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 12 of 18 Remote Control Buttons Refer to Button Controls on previous page.
  • Page 13: Technical Drawing

    All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 13 of 18 Technical Drawing...
  • Page 14 All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 14 of 18...
  • Page 15: Troubleshooting

    All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 15 of 18 Troubleshooting Video Noise Check for an incorrect ground in the installation wiring. See specific examples of video noise below, or visit http://flightdisplay.com/Grounding.pdf...
  • Page 16: Technical Support

    01/19/2012 MAN – FD201CV-LP Page 16 of 18 Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (678) 867-6717. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004...
  • Page 17: Warranty

    If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion.
  • Page 18: Log Of Revisions

    All manuals and user guides at all-guides.com Document Number: Rev: Revision Date: 01/19/2012 MAN – FD201CV-LP Page 18 of 18 Log of Revisions Date Page Description 01/25/2007 03/07/2007 Changed “12VDC” to “28VDC” 03/12/2007 Added “Remote Eye” section 04/17/2007 Removed excess text...
