- Page 1 Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 1 of 16 FD104CV Installation and Operation Manual 10.4” LCD TECHNICAL SUPPORT 678-867-6717, or www.FlightDisplay.com...
- Page 2 Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 2 of 16 FD104CV 10.4” LCD © 2006 Flight Display Systems. All Rights Reserved. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004 678-867-6717 Phone 678-867-6742 Fax sales@flightdisplay.com www.flightdisplay.com For the most current copy of all product manuals, please visit our website at...
- Page 3 Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 3 of 16 Table of Contents General Information ........................4 1. Front View ..........................4 2. Additional Information ....................4 Specifications ..........................5 Installation Instructions ......................5 1. Rear Connector Orientation ....................6 2. Power ..........................6 Wiring Instructions ........................7...
-
Page 4: General Information
MAN – FD104CV Page 4 of 16 General Information The FD104CV is a 10.4” LCD. Built with retrofit aircraft integration in mind, this display can switch between three video input sources using buttons on the bezel or the infrared Remote. -
Page 5: Specifications
IR, included Installation Instructions All cabin entertainment equipment, such as the FD104CV, should be installed on a non- essential bus and have a dedicated circuit breaker. It is a requirement that a switch be installed in the cockpit so that the pilot can de-energize the entertainment system should it become necessary. -
Page 6: Power
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 6 of 16 Power This is a 28V DC monitor that requires 1.0 Amps (28 watts) of power. -
Page 7: Wiring Suggestions
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 7 of 16 Wiring Suggestions All shields should be grounded to the connector at the source, and floating at the display. Avoid routing video wiring parallel to: • AC wiring •... -
Page 8: Vga Wiring
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 8 of 16 VGA Wiring Recommended cable for VGA purpose is ECS P/N 453005. This is a single shielded cable containing 5 separate coaxial cables, color-coded to match the functions of the wires. -
Page 9: Power & Ground Wiring
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 9 of 16 Power and Ground Wiring This is a 28VDC monitor that requires 1 amp of power to operate. To operate properly this monitor requires an input voltage of 18-29VDC. -
Page 10: Power/Video
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 10 of 16 Power/Video Pin out for P1 (High Density DB-15 Receptacle) (Connector supplied with contacts and hood) Connector P/N: M24308/2-286 or Equivalent Crimp Contacts P/N: M39029/57-354 or Equivalent Description... -
Page 11: Operations Instructions
No pilot or aircrew action is necessary during flight or ground operation. The passengers will be able to change the video output from the FD104CV using the video source select switch on the LCD monitor, or remotely throughout the cabin with the included IR remote. -
Page 12: Technical Drawing
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 12 of 16 Technical Drawing... -
Page 13: Troubleshooting
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 13 of 16 Troubleshooting Video Noise Check for an incorrect ground in the installation wiring. See specific examples of video noise below, or visit http://flightdisplay.com/Grounding.pdf VGA Shadowing Most of shadowing problems are due to shielding on the wire. Locate the point where all of the shields are connected. -
Page 14: Technical Support
01/27/2011 MAN – FD104CV Page 14 of 16 Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (678) 867-6717. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004... -
Page 15: Warranty
If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion. -
Page 16: Log Of Revisions
Document Number: Rev: Revision Date: 01/27/2011 MAN – FD104CV Page 16 of 16 Log of Revisions Date Page Description 01/25/2007 Initial Release 08/15/2007 Corrected button functions 03/30/2009 Updated Specifications, Warranty Info 12/11/2009 Revised Product Number Added Rear Connector Orientation, revised technical drawing,...
