Flight Display Systems FD171CV-C-4 Installation And Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MAN – FD171CV-C-4
Manufactured by MILIC, LLC with marketing support from Flight Display Systems.
This product does not have FAA PMA approval.
TECHNICAL SUPPORT
470-239-7421, or
www.FlightDisplay.com
Rev:
B
Installation and Operation Manual
Revision Date:
10/17/2014
Page 1 of 15
FD171CV-C-4

Advertisement

Table of Contents
loading

Related Manuals for Flight Display Systems FD171CV-C-4

Summary of Contents for Flight Display Systems FD171CV-C-4

  • Page 1 Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 1 of 15 FD171CV-C-4 Installation and Operation Manual Manufactured by MILIC, LLC with marketing support from Flight Display Systems. This product does not have FAA PMA approval. TECHNICAL SUPPORT 470-239-7421, or www.FlightDisplay.com...

  • Page 2: Table Of Contents

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 2 of 15 Table of Contents General Information ........................3 1. Front View ..........................3 2. Additional Information ....................3 Specifications ..........................4 Installation Instructions ......................4 1. Power ..........................4 Wiring Suggestions ........................5 1. Composite/S-Video ......................5 2. VGA Wiring……………………………………………………………………………...6 3.

  • Page 3: General Information

    MAN – FD171CV-C-4 Page 3 of 15 General Information The FD171CV-C-4 is a special mission panel mounted 17” monitor with quad view HDSDI. Front View Additional Information The LCD supports 7 video source inputs. Four (4) HD-SDI inputs for the quad view, one (1) VGA, one (1) S-Video and one (1) composite.

  • Page 4: Specifications

    Test Certifications Installation Instructions All cabin equipment, such as the FD171CV-C-4, should be installed on a non-essential bus and have a dedicated circuit breaker. It is a requirement that a switch be installed in the cockpit so that the flight crew can de-energize the system should it become necessary.

  • Page 5: Wiring Suggestions

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 5 of 15 Wiring Suggestions For balanced signals on twisted pair cable, all shields should be grounded to the connector at the source, and floating at the display. Avoid routing video wiring parallel to: ...

  • Page 6: Vga Wiring

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 6 of 15 VGA Wiring Coax cables should be terminated using solder sleeve coaxial cable terminators, Raychem P/N: CWT-4174-W122-5/9...

  • Page 7: Power And Ground Wiring

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 7 of 15 Power and Ground Wiring 22 AWG wire is recommended for Power and Ground applications. This is a 28VDC monitor that requires 2 amps of power to operate. To operate properly this monitor requires an input voltage of 24-29VDC.

  • Page 8: Power/Video

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 8 of 15 POWER and VIDEO P1 (Video/Power) High Density DB-15 Receptacle (supplied) Connector P/N: M24308/2-286 or Equivalent Crimp Contacts P/N: M39029/57-354 or Equivalent Description Number 28VDC Power 28VDC Ground Composite Video 1 - Signal...

  • Page 9: Rear View With Connectors

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 9 of 15 * For Quad View to function properly a connection must exist between J8 and J2.

  • Page 10: Operation Instructions

    No pilot or aircrew action is necessary during flight or ground operation. The operator can change the video from the FD171CV-C-4 using the Source button on the top of the display (SDI, Analog, S-Video & Composite). When the SDI source is selected, the buttons on the front of the display will control the quad inputs to be displayed.
  • Page 11 MAN – FD171CV-C-4 Page 11 of 15 Located on the front of the FD171CV-C-4 are 5 buttons for HDSDI quad control. With HDSDI source selected on the monitor, these buttons select the input to display. When “Q” is selected all 4 HDSDI inputs will be displayed.

  • Page 12: Technical Drawing

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 12 of 15 Technical Drawing...

  • Page 13: Troubleshooting

    Rev: Revision Date: 10/17/2014 MAN – FD171CV-C-4 Page 13 of 15 Troubleshooting Video Noise Check for an incorrect ground in the installation wiring. See specific examples of video noise below, or visit http://FlightDisplay.com/Grounding.pdf Snow or Sweeping Lines Lines that slowly sweep up and down are a result of AC noise. This AC noise can be generated by a power cart on the aircraft.

  • Page 14: Technical Support

    MAN – FD171CV-C-4 Page 14 of 15 Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (470) 239-7421. Flight Display Systems 6435 Shiloh Road, Suite D...

  • Page 15: Warranty

    If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion.
