MAN – FD102ARM
Manufactured by MILIC, LLC with marketing support from Flight Display Systems.
This product does not have FAA PMA approval.
TECHNICAL SUPPORT
678-867-6717, or
www.FlightDisplay.com
All manuals and user guides at all-guides.com
Rev:
F
Installation and Operation Manual
10.2" Widescreen LCD on Arm
Revision Date:
08/24/12
Page 1 of 15
FD102ARM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FD102ARM and is the answer not in the manual?

Questions and answers

Related Manuals for Flight Display Systems FD102ARM

Summary of Contents for Flight Display Systems FD102ARM

  • Page 1 MAN – FD102ARM Page 1 of 15 FD102ARM Installation and Operation Manual 10.2” Widescreen LCD on Arm Manufactured by MILIC, LLC with marketing support from Flight Display Systems. This product does not have FAA PMA approval. TECHNICAL SUPPORT 678-867-6717, or www.FlightDisplay.com...
  • Page 2 Rev: Revision Date: 08/24/12 MAN – FD102ARM Page 2 of 15 FD102ARM 10.2" Widescreen LCD on Arm © 2006 Flight Display Systems. All Rights Reserved Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004 678-867-6717 Phone 678-867-6742 Fax sales@flightdisplay.com www.flightdisplay.com For the most current copy of all product manuals, please visit our website at www.flightdisplay.com...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/24/12 MAN – FD102ARM Page 3 of 15 Table of Contents General Information ........................4 1. Front View ..........................4 2. Additional Information ....................4 Specifications ..........................5 Installation Instructions ......................5 1. Power ..........................5 Wiring Suggestions ........................6...

  • Page 4: General Information

    The articulating arm rotates 180 degrees, tilts forward and aft, and the monitor can turn 180 degrees on the end of the mount. The FD102ARM can also be connected to existing video switchers and can take a composite video input from a selector interface box. Multiple input sources can be selected and displayed on the monitor.

  • Page 5: Specifications

    This is a 12VDC monitor that requires 2 Amps of power to operate. This is also available as FD102ARM (28V) which is a 28VDC monitor that requires .5 Amp of power to operate. The unit turns on automatically upon power application.

  • Page 6: Wiring Suggestions

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/24/12 MAN – FD102ARM Page 6 of 15 Wiring Suggestions All shields should be grounded to the connector at the source, and floating at the display. Avoid routing video wiring parallel to: ...

  • Page 7: Vga Wiring

    & green wires, and Raychem caps for the blue, white, and black wires. Mounting and Base Information The FD102ARM mates with a drink rail mount (FDBASE, below left), a wall mount (FDBASE-W, below right) or a flush wall mount (FDBASE-W-FM, not shown).

  • Page 8: Power/Video

    HD15F pins P/N M39029/57-354 Wiring Diagram Number Description 12VDC Power (28VDC for FD102ARM (28V)) 12VDC Ground (28VDC for FD102ARM (28V)) Composite Video #1 - Signal Composite Video #1 - Shield Composite Video #2 - Signal Composite Video #2 - Shield...

  • Page 9: Operations Instructions

    No pilot or aircrew action is necessary during flight or ground operation. The passengers will be able to change the video output from the FD102ARM using the video source select switch on the LCD monitor, or remotely throughout the cabin with the included IR remote.
  • Page 10 All manuals and user guides at all-guides.com Rev: Revision Date: 08/24/12 MAN – FD102ARM Page 10 of 15 Remote Control Buttons The remote control included with the FD102CV contains the same functionality available on the display buttons, to include power, source, menu, and directional arrows.

  • Page 11: Technical Drawing

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/24/12 MAN – FD102ARM Page 11 of 15 Technical Drawing Troubleshooting...

  • Page 12: Vga

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/24/12 MAN – FD102ARM Page 12 of 15 Video Noise Check for an incorrect ground in the installation wiring. See specific examples of video noise below, or visit http://flightdisplay.com/Grounding.pdf VGA Shadowing Most of shadowing problems are due to shielding on the wire.

  • Page 13: Technical Support

    08/24/12 MAN – FD102ARM Page 13 of 15 Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (678) 867-6717. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004...

  • Page 14: Warranty

    If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion.

  • Page 15: Log Of Revisions

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/24/12 MAN – FD102ARM Page 15 of 15 Log of Revisions Date Page Description 01/25/2007 Fixed page numbering. 04/11/2007 Changed required amperage to 2 Amps. 02/13/2009 2,11 Updated specifications, warranty info...
