EMOJO Panther Pro Assembly Instructions Manual page 10

It is highly recommended you install the front fender before
the front wheel to allow you more room to secure the fender
nuts and bolts to the fork.
10-ATach the curved support bracket to the front fender
11- Using the threaded eye holes on the front forks, aTach both plas/c
bar clamps to each side using the screws provided.
12- ATach the top bracket of the fender and the headlamp to the forks, using the long
bolt provided. Once the long bolt is thru the hole at the top of the forks, secure it with
the nut on the back.
FRONT
FENDER
AND
HEADLAMP
(10) (11) (12)
Con/nues next page...
Secure long bolt with
the safety nut on
the back
