OPERATOR'S & PARTS MANUAL
MODEL 2400
Universal Pup
PART # 290204

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2400 and is the answer not in the manual?

Questions and answers

Related Manuals for Spudnik 2400

Summary of Contents for Spudnik 2400

  • Page 1 OPERATOR’S & PARTS MANUAL MODEL 2400 Universal Pup PART # 290204...
  • Page 2 Operator's manual MODEL 2400 Mission Statement Our mission is to consistently provide high quality, reliable, safe, and well-designed products and services to meet and exceed the needs of our customers. Service Centers Phone: (208) 785-0480 E-Mail: spudnik@spudnik.com Web Site: www.spudnik.com...

  • Page 3: Table Of Contents

    Operator's manual MODEL 2400 Table Of Contents Description Page # Introduction ……………………………………………………………………………... Foreword to the operation manual ...………………………………………………...… Warranty …...…………………………………………………………………………… General …..……………………………………………………………………………… Product Characteristics …..…….……………………………………………………… Dangers, operation errors and exemption from liability ………………………….. Safety ……………...………………………………………………………………….. General safety and accident prevention regulations ………………………………...

  • Page 4: Introduction

    We strive to put the best quality and workmanship into each of our machines, and hope as you use your MODEL 2400 Universal Pup that you will find this to be true. This owner’s/operator’s manual has been prepared to aid you in the safe operation and service of your universal pup.

  • Page 5: Foreword To The Operation Manual

    Operator's manual MODEL 2400 Foreword to the Operating Manual This operating manual is intended to familiarize the user with the MODEL 2400 Universal Pup and its designated use. This operating manual contains important information on how to operate the machine safely, properly, and efficiently.

  • Page 6: Warranty

    The selling dealer has no authority to make any representation or promise on behalf of Spudnik, or to modify the terms or limi- tations of this warranty in any way.

  • Page 7: General

    Particular attention should be paid to the section entitled “Safety”. Any instructions which are not understood must be clarified before initial operation of the machine. In such cases, please consult your SPUDNIK agent or contact us directly.

  • Page 8: Product Characteristics

    Operator's manual MODEL 2400 Product Characteristics Manufacturer’s address SPUDNIK EQUIPMENT COMPANY LLC 584 W 100 N PO Box 1045 Blackfoot, ID 83221 Phone: (208) 785-0480 Fax: (208) 785-1497 www.spudnik.com E-mail: spudnik@spudnik.com Advice concerning inquiries and orders Please quote the type designation and the machine number when ordering accessories and spare parts.

  • Page 9: Dangers, Operation Errors And Exemption From Liability

    Operator's manual MODEL 2400 SAFETY You are responsible for the safe operation and maintenance of your SPUDNIK UNIVERSAL PUP. All operators and anyone doing work or maintenance on the Universal Pup must be trained in the operation, maintenance procedures, and related SAFETY information contained in this manual.

  • Page 10: Safety

    Operator's manual MODEL 2400 SAFETY SAFETY ALERT SYMBOL THE SAFETY ALERT SYMBOL MEANS: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! The SAFETY ALERT SYMBOL identifies important safety information on the safety labels and in this manual. When you see this symbol be alert to the possibility of personal injury or death.

  • Page 11: General Safety And Accident Prevention Regulations

    Operator's manual MODEL 2400 SAFETY PRACTICES • The primary responsibility for safe operation of the Spudnik Universal Pup lies with the owner/operator. • OSHA (Occupational Safety and Health Administration) requires that all operators be trained at the time of initial assignment and annually thereafter by the employer in the safe operation of the machine.
  • Page 12 Operator's manual MODEL 2400 SAFETY PRACTICES • This machine is designed to require one operator standing on the same side of the Universal Pup as the hydraulic control valve. Operating the Universal Pup from the opposite side of the hydraulic control valve can result in bodily injury.

  • Page 13: Saftey Labels

    Operator's manual MODEL 2400 SAFETY LABELS • Keep safety labels and stickers clean and legible at all times. • Replace safety labels and stickers that are missing or have become illegible. • When replacing parts that display a safety label, make sure that the new parts also display the safety label.
  • Page 14 Operator's manual MODEL 2400 SAFETY LABELS Page 13...

  • Page 15: Maintenance

    Operator's manual MODEL 2400 MAINTENANCE • The hydraulic system used to power auxiliary functions uses Dexron III ATF (automatic transmission fluid) for prime mover. Hydraulic reservoir fill level should be checked at start of each season, and filled as needed.

  • Page 16: Belt Alignment Procedure

    Operator's manual MODEL 2400 Belt runs to loose side (narrowest space between belt and side). Tighten loose side as necessary or loosen other side as necessary. Belt tension must be great enough to prevent slippage between drive pulley and belt.

  • Page 17: Machine Operation

    Operator's manual MODEL 2400 MACHINE OPERATION The model 2400 Universal Pup has been designed to speed up the transfer and reduce the bruising of potatoes from the truck to the piler, conveyor, eliminator, etc. 1. Check that all pivot bolts and hinge pins are in good condition.

  • Page 18: Machine Parts Breakdown

    Operator's manual MODEL 2400 Machine Parts Breakdown Description Page # Stickers and Safetly Label Placement ..…..……………………………………... 18-20 10' Belt Pup Assembly ….….………...………………………...……..…………..… 21-25 12' Belt Pup Assembly ……………………………………..….…………………... 27-31 10' Chain Pup Assembly ………………………………….…….……………………. 33-37 12' Chain Pup Assembly ………………………….……………….……..…………… 39-43 10' Dirt Roll Hopper Pup Assembly ….….……..……………...……..…………..…...

  • Page 19: Stickers And Safetly Label Placement

    Operator's manual MODEL 2400 STICKERS AND SAFETY LABELS BELT PUP Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: LABEL,CAUTION,MACHINE STARTS WITHOUT/SML 300112 SERIAL,NUMBER,PLATE 2"x3" ALUM W/HOLES 300055 LABEL,CAUTION,MOVING,DRIVES,CAN CAUSE 300086 BRIGHT OR DARK RED PAINT LABEL,DANGER,HIGH,VOLTAGE,WILL CAUSE/SML 300107 STICKER,MDL 2400 WHITE 2.3"...
  • Page 20 Operator's manual MODEL 2400 STICKERS AND SAFETY LABELS CHAIN PUP Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: LABEL,CAUTION,MACHINE STARTS WITHOUT/SML 300112 SERIAL,NUMBER,PLATE 2"x3" ALUM W/HOLES 300055 LABEL,CAUTION,MOVING,DRIVES,CAN CAUSE 300086 BRIGHT OR DARK RED PAINT LABEL,DANGER,HIGH,VOLTAGE,WILL CAUSE/SML 300107 STICKER,MDL 2400 WHITE 2.3"...
  • Page 21 Operator's manual MODEL 2400 STICKERS AND SAFETY LABELS DIRT ROLL HOPPER PUP Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: LABEL,CAUTION,MACHINE STARTS WITHOUT/SML 300112 SERIAL,NUMBER,PLATE 2"x3" ALUM W/HOLES 300055 LABEL,CAUTION,MOVING,DRIVES,CAN CAUSE 300086 BRIGHT OR DARK RED PAINT LABEL,DANGER,HIGH,VOLTAGE,WILL CAUSE/SML 300107 STICKER,MDL 2400 WHITE 2.3"...

  • Page 22: 10' Belt Pup Assembly

    Operator's manual MODEL 2400 10' BELT PUP ASSEMBLY DETAIL A Page 21...
  • Page 23 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BRNG,PB,1-7/16"BORE,TTB,1/7/16,FAFNIR 231241 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CASE, OPERATORS MANUAL 981360 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 CHN,RLR,60 PITCH x 5.375 LNF 351005...
  • Page 24 Operator's manual MODEL 2400 10' BELT PUP ASSEMBLY DETAIL B Page 23...
  • Page 25 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BRNG,PB,1-7/16"BORE,TTB,1/7/16,FAFNIR 231241 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CASE, OPERATORS MANUAL 981360 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 CHN,RLR,60 PITCH x 5.375 LNF 351005...
  • Page 26 Operator's manual MODEL 2400 10' BELT PUP ASSEMBLY SECTION A-A 30" WIDTH OPTION 42" WIDTH OPTION Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: BELT,ASSY,2200,30"x21'2",FLAT,10' PUP 261553 BELT,ASSY,2200,42"x21'2",FLAT,10' PUP 261817 PSC,TL,29-1/2" 6-3/16" O.D. 781180 PSC,TL,41-1/2" 6-3/16" O.D. 781251 RBO,30-1/2"...
  • Page 27 Notes: Page 26...

  • Page 28: 12' Belt Pup Assembly

    Operator's manual MODEL 2400 12' BELT PUP ASSEMBLY DETAIL A Page 27...
  • Page 29 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 CASE, OPERATORS MANUAL 981360 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CHN,RLR,60 PITCH x 5.375 LNF 351005 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 COLLAR,SHAFT,SET,SCREW,1" 501945...
  • Page 30 Operator's manual MODEL 2400 12' BELT PUP ASSEMBLY DETAIL B Page 29...
  • Page 31 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 CASE, OPERATORS MANUAL 981360 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CHN,RLR,60 PITCH x 5.375 LNF 351005 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 COLLAR,SHAFT,SET,SCREW,1" 501945...
  • Page 32 Operator's manual MODEL 2400 12' BELT PUP ASSEMBLY SECTION A-A 30" WIDTH OPTION 42" WIDTH OPTION Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: BELT,ASSY,2400,30"x25'2",FLAT,12' PUP 262418 BELT,ASSY,2400,42"x25'2",FLAT,12' PUP 262416 PSC,TL,29-1/2" 6-3/16" O.D. 781180 PSC,TL,41-1/2" 6-3/16" O.D. 781251 RBO,30-1/2"...
  • Page 33 Notes: Page 32...

  • Page 34: 10' Chain Pup Assembly

    Operator's manual MODEL 2400 10' CHAIN PUP ASSEMBLY DETAIL A Page 33...
  • Page 35 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BREATHER #8 PORT O-RING 602181 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 BRNG,PB,1-7/16"BORE,TTB,1/7/16,FAFNIR 231241 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CASE, OPERATORS MANUAL 981360 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 CHN,RLR,60 PITCH x 5.375 LNF 351005...
  • Page 36 Operator's manual MODEL 2400 10' CHAIN PUP ASSEMBLY DETAIL B Page 35...
  • Page 37 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BREATHER #8 PORT O-RING 602181 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 BRNG,PB,1-7/16"BORE,TTB,1/7/16,FAFNIR 231241 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CASE, OPERATORS MANUAL 981360 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 CHN,RLR,60 PITCH x 5.375 LNF 351005...
  • Page 38 10' CHAIN PUP ASSEMBLY SECTION A-A 30" WIDTH OPTION - 36MM 30" WIDTH OPTION - 42MM Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: ASSY,BC,30"x11MMx36MM STR CUSH 20'7" 352154 ASSY,BC,30"x11MMx42MM STR CUSH 20'7" 352155 SPRCKT,CAST,10T 36MM 1-7/16"B 321555 SPRCKT,CAST,10T 42MM 1-7/16"B 321557 36"...
  • Page 39 Notes: Page 38...

  • Page 40: 12' Chain Pup Assembly

    Operator's manual MODEL 2400 12' CHAIN PUP ASSEMBLY DETAIL A Page 39...
  • Page 41 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BREATHER #8 PORT O-RING 602181 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 BRNG,PB,1-7/16"BORE,TTB,1/7/16,FAFNIR 231241 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CASE, OPERATORS MANUAL 981360 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 CHN,RLR,60 PITCH x 5.375 LNF 351005...
  • Page 42 Operator's manual MODEL 2400 12' CHAIN PUP ASSEMBLY DETAIL B Page 41...
  • Page 43 PLATE,LOWER SHIELD MOUNT,MDL 2400 175966 BREATHER #8 PORT O-RING 602181 PLATE,UPPER SHIELD MOUNT MDL 2400 175964 BRNG,PB,1-7/16"BORE,TTB,1/7/16,FAFNIR 231241 PLATE,UPPER SHIELD MOUNT SPACER MDL 2400 175965 CASE, OPERATORS MANUAL 981360 PUP, HOPPER, GROUND BUMPER, LH, BOLT ON 196242 CHN,RLR,60 PITCH x 5.375 LNF 351005...
  • Page 44 Operator's manual MODEL 2400 12' CHAIN PUP ASSEMBLY SECTION A-A 30" WIDTH OPTION - 36MM 30" WIDTH OPTION - 42MM Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: ASSY,BC,30"x11MMx36MM STR CUSH 24'7" 353201 ASSY,BC,30"x11MMx42MM STR CUSH 24'7" 353202 SPRCKT,CAST,10T 36MM 1-7/16"B...
  • Page 45 Notes: Page 44...

  • Page 46: 10' Dirt Roll Hopper Pup Assembly

    Operator's manual MODEL 2400 10' DIRT ROLL HOPPER PUP ASSEMBLY DETAIL B DETAIL A Page 45...
  • Page 47 DESCRIPTION PART #: BODY,30"x10' UNIVERSAL PUP MDL 2400 197781 BODY,42"x10' UNIVERSAL PUP MDL 2400 197783 DIRT ROLL HOPPER PUP FRAME,30" MDL 2400 197799 DIRT ROLL HOPPER PUP FRAME,42" MDL 2400 197801 DIRT ROLL HOPPER,30" MDL 2400 197802 DIRT ROLL HOPPER,42" MDL 2400 197804 FRAME,HYD ADJUST,DRT RL HPR,30"...
  • Page 48 Operator's manual MODEL 2400 10' DIRT ROLL HOPPER PUP ASSEMBLY DETAIL C 28 75 Page 47...
  • Page 49 DESCRIPTION PART #: BODY,30"x10' UNIVERSAL PUP MDL 2400 197781 BODY,42"x10' UNIVERSAL PUP MDL 2400 197783 DIRT ROLL HOPPER PUP FRAME,30" MDL 2400 197799 DIRT ROLL HOPPER PUP FRAME,42" MDL 2400 197801 DIRT ROLL HOPPER,30" MDL 2400 197802 DIRT ROLL HOPPER,42" MDL 2400 197804 FRAME,HYD ADJUST,DRT RL HPR,30"...
  • Page 50 Operator's manual MODEL 2400 10' DIRT ROLL HOPPER PUP ASSEMBLY SECTION A-A 30" WIDTH OPTION - 36MM 30" WIDTH OPTION - 42MM Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: ASSY,BC,30"x11MMx36MM STR CUSH 17'5" 353207 ASSY,BC,30"x11MMx42MM STR CUSH 17'5"...
  • Page 51 Notes: Page 50...

  • Page 52: 12' Dirt Roll Hopperpup Assembly

    Operator's manual MODEL 2400 12' DIRT ROLL HOPPER PUP ASSEMBLY DETAIL B DETAIL A Page 51...
  • Page 53 DESCRIPTION PART #: BODY,30"x12' UNIVERSAL PUP MDL 2400 197784 BODY,42"x12' UNIVERSAL PUP MDL 2400 197786 DIRT ROLL HOPPER PUP FRAME,30" MDL 2400 197799 DIRT ROLL HOPPER PUP FRAME,42" MDL 2400 197801 DIRT ROLL HOPPER,30" MDL 2400 197802 DIRT ROLL HOPPER,42" MDL 2400 197804 FRAME,HYD ADJUST,DRT RL HPR,30"...
  • Page 54 Operator's manual MODEL 2400 12' DIRT ROLL HOPPER PUP ASSEMBLY DETAIL C Page 53...
  • Page 55 DESCRIPTION PART #: BODY,30"x12' UNIVERSAL PUP MDL 2400 197784 BODY,42"x12' UNIVERSAL PUP MDL 2400 197786 DIRT ROLL HOPPER PUP FRAME,30" MDL 2400 197799 DIRT ROLL HOPPER PUP FRAME,42" MDL 2400 197801 DIRT ROLL HOPPER,30" MDL 2400 197802 DIRT ROLL HOPPER,42" MDL 2400 197804 FRAME,HYD ADJUST,DRT RL HPR,30"...
  • Page 56 Operator's manual MODEL 2400 12' DIRT ROLL HOPPER PUP ASSEMBLY SECTION A-A 30" WIDTH OPTION - 36MM 30" WIDTH OPTION - 42MM Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: ASSY,BC,30"x11MMx36MM STR CUSH 21'5" 353213 ASSY,BC,30"x11MMx42MM STR CUSH 21'5"...
  • Page 57 Notes: Page 56...

  • Page 58: Dirt Roll Options

    Operator's manual MODEL 2400 DIRT ROLL OPTIONS FINGER ROLL OPTION ELIMINATOR ROLL OPTION Page 57...
  • Page 59 Operator's manual MODEL 2400 DIRT ROLL OPTIONS FINGER ROLLS 30" FINGER ROLL OPTION Item # DESCRIPTION PART #: SHFT,PUP,30",ELIM/FNGR FULL D/SPR CMPLT 822036 SHFT,PUP,30",FINGR HLF, D/SPR CMPLT 822037 SHFT,PUP,30" FNGR FULL D/SPR CMPLT 822038 36" FINGER ROLL OPTION Item #...
  • Page 60 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,38",1-1/2x28-1/4,SLD,PUP 198316 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822036 SHFT,PUP,30",ELIM/FNGR FULL D/SPR CMPLT...
  • Page 61 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,FINGER,LH 1-1/2"BR 2-1/4"HUB 981289 ROLL,RUBBER,FINGER,RH 1-1/2"BR 2-1/4"HUB 981290 SHFT,SQ,38",1-1/2x28-1/4,SLD,PUP 198316 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822037 SHFT,PUP,30",FINGR HLF, D/SPR CMPLT...
  • Page 62 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,38",1-1/2x28-1/4,SLD,PUP 198316 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822038 SHFT,PUP,30" FNGR FULL D/SPR CMPLT...
  • Page 63 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 SHFT,SQ,38",1-1/2x28-1/4,SLD,PUP 198316 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822039 SHFT,PUP,30",ELIM ROLL FULL D/SPR CMPLT Page 62...
  • Page 64 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,38",1-1/2x28-1/4,SLD,PUP 198316 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822040 SHFT,PUP,30",ELIM ROLL HLF D/SPR CMPLT...
  • Page 65 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,44",1-1/2x34-1/4,SLD,PUP 198317 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822041 SHFT,PUP,36",ELIM/FNGR FULL D/SPR CMPLT...
  • Page 66 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,FINGER,LH 1-1/2"BR 2-1/4"HUB 981289 ROLL,RUBBER,FINGER,RH 1-1/2"BR 2-1/4"HUB 981290 SHFT,SQ,44",1-1/2x34-1/4,SLD,PUP 198317 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822042 SHFT,PUP,36",FINGR HLF, D/SPR CMPLT...
  • Page 67 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,44",1-1/2x34-1/4,SLD,PUP 198317 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822043 SHFT,PUP,36" FNGR FULL D/SPR CMPLT...
  • Page 68 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 SHFT,SQ,44",1-1/2x34-1/4,SLD,PUP 198317 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822044 SHFT,PUP,36",ELIM ROLL FULL D/SPR CMPLT Page 67...
  • Page 69 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,44",1-1/2x34-1/4,SLD,PUP 198317 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822045 SHFT,PUP,36",ELIM ROLL HLF D/SPR CMPLT...
  • Page 70 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,50",1-1/2x40-1/4,SLD,PUP 198318 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822046 SHFT,PUP,42",ELIM/FNGR FULL D/SPR CMPLT...
  • Page 71 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,FINGER,LH 1-1/2"BR 2-1/4"HUB 981289 ROLL,RUBBER,FINGER,RH 1-1/2"BR 2-1/4"HUB 981290 SHFT,SQ,50",1-1/2x40-1/4,SLD,PUP 198318 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822047 SHFT,PUP,42",FINGR HLF, D/SPR CMPLT...
  • Page 72 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,1-1/2"BORE 3" HUB 981287 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,50",1-1/2x40-1/4,SLD,PUP 198318 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822048 SHFT,PUP,42" FNGR FULL D/SPR CMPLT...
  • Page 73 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 SHFT,SQ,50",1-1/2x40-1/4,SLD,PUP 198318 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822049 SHFT,PUP,42",ELIM ROLL FULL D/SPR CMPLT Page 72...
  • Page 74 Operator's manual MODEL 2400 DIRT ROLL OPTIONS Item # DESCRIPTION PART #: BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 SHFT,SQ,50",1-1/2x40-1/4,SLD,PUP 198318 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 822050 SHFT,PUP,42",ELIM ROLL HLF D/SPR CMPLT...

  • Page 75: Gearbox & Motor

    Operator's manual MODEL 2400 GEARBOX AND MOTOR RIGHT HAND DRIVE LEFT HAND DRIVE RIGHT HAND DRIVE LEFT HAND DRIVE Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: GRBX,R/F,C-FACE,30AKV 15: 1 4.64HP GROVE 571382 GRBX,L/F,C-FACE,30AKV 15: 1 4.64HP GROVE...

  • Page 76: Yoke Options

    Operator's manual MODEL 2400 YOKE OPTIONS LEFT OFFSET YOKE RIGHT OFFSET YOKE STRAIGHT YOKE NOTE: 12' PUPS USE ONLY STRAIGHT YOKE Page 75...
  • Page 77 Operator's manual MODEL 2400 YOKE OPTIONS ITEM # PART # DESCRIPTION 173729 HITCH,PUP,SIDE HANDLE QUICK CONNECT 181275 PIN,PUP,SWING,1-1/4"x16" 981460 SPRING,COMPRESSION,3/4"ODx.085WIREx2.25" 30" WIDE PUPS ITEM # DESCRIPTION PART # YOKE,30-1/2",LEFT OFFSET,PUP MDL 2004 192569 YOKE,30-1/2",RIGHT OFFSET,PUP MDL 2004 192570 YOKE,30-1/2",STRAIGHT,PUP MDL 2004 192568 36"...

  • Page 78: Schematics

    Page 77...
  • Page 79 Page 78...
  • Page 80 Page 79...
  • Page 81 Page 80...
  • Page 82 Page 81...
  • Page 87                                                                                  ...
