5 Connector Pinouts

5.1 JTAG

Pin
1
2
3,5,9
4
6
10
7,11,12,13,14,15,17,18,19,20

5.2 High Density Connector

11 / 18
Arduino® Portenta Vision Shield - LoRa
Function Type
VDDIO Power
SWD I/O
GND Power
SCK Output
SWO I/O
RESET Input
NC Not Connected
Arduino® Portenta Vision Shield - LoRa
Description
Positive Reference voltage for debug interface
Single Wire Debug Data
Negative reference voltage for debug interface
Single Wire Debug Clock
Single Wire Debug Trace
CPU Reset
