Operating Instructions
VEGASOURCE 81
Source holder
Document ID: 66075

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGASOURCE 81 and is the answer not in the manual?

Questions and answers

Related Manuals for Vega VEGASOURCE 81

Summary of Contents for Vega VEGASOURCE 81

  • Page 1 Operating Instructions VEGASOURCE 81 Source holder Document ID: 66075...

  • Page 2: Table Of Contents

    What to do in case of emergency ................... 42 Dismount..........................44 Dismounting steps......................44 Return ..........................44 Supplement ..........................46 Technical data ........................ 46 Dimensions ........................54 Manufacturer declaration....................64 Industrial property rights ....................65 Trademark ........................65 VEGASOURCE 81 • Source holder...
  • Page 3 Contents Editing status: 2022-01-19 VEGASOURCE 81 • Source holder...

  • Page 4: About This Document

    Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, note, tip: This symbol indicates helpful additional infor- mation and tips for successful work.

  • Page 5: For Your Safety

    (e.g. lead, iron, concrete, etc.) provide effective shielding. Time: Stay as short a time as possible in radiation exposed areas. Distance: Your distance to the source should be as large as possible. The local dose rate of the radiation decreases in proportion to the square of the distance to the radiation source. VEGASOURCE 81 • Source holder...

  • Page 6: Appropriate Use

    We are at your disposal for further information concerning radiation protection and regulations in other countries. Appropriate use When in operating mode, the source container VEGASOURCE 81 de- scribed in this document contains a radiactive source for radiometric level, interface, switching and density measurement as well as mass flow detection. The source container shields the radiation off from the...

  • Page 7: Application Reference

    The combination lock can be opened with the number combination 000 on delivery. We recommend changing the number combination to a personal number sequence. Make a note of the number combination and keep it in a safe place. VEGASOURCE 81 • Source holder...

  • Page 8: Installation And Operation In The Usa And Canada

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" VEGASOURCE 81 • Source holder...

  • Page 9: Product Description

    • Serial number - Source • Loading date The serial number allows you to access the delivery data of the instru- ment via " www.vega.com", " Instrument search (serial number)". There are several versions available with different options for opening Versions or blocking the beam exit. Apart from the manual versions, there are also a version with pneumatic switchover. VEGASOURCE 81 • Source holder...
  • Page 10 3 Product description Fig. 2: Versions VEGASOURCE 81 (Overview) Version X: Standard version with manual changeover (lock for position: OFF) Version C: Standard version with manual changeover (lock for position: ON/OFF) Version B: with pneumatic switchover Features of the versions...
  • Page 11 Serial number of the source capsule (for traceability of the source) Order code - Source container Serial number - Source holder Beam exit angle 10 Manufacturer 11 QR code 12 Number of the corresponding operating instructions VEGASOURCE 81 • Source holder...

  • Page 12: Principle Of Operation

    Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the " Apple App Store" or the " Google Play Store" • Scan the QR-code on the type label of the device or •...

  • Page 13: Packaging, Transport And Storage

    3 Product description chemical influences. In case of large measuring ranges (e.g. with high vessels) two or more source holders are used. The VEGASOURCE 81 consists of the components: Fig. 6: Source holder VEGASOURCE 81 Source holder Cover (optional) Transport lug Mounting surface Functional principle The rays emitted by the gamma source are damped when penetrat- ing the medium.
  • Page 14 110 kg (244 lbs) Persons must never stand beneath the loads. When transporting, proceed according to the following illustrations. We recommend using a lift truck or a fork truck for transport to the place of use. VEGASOURCE 81 • Source holder...
  • Page 15 Additional equipment such as the ON/OFF position switches or a pneumatic switchover change the centre of gravity of the source holder. When lifting the source holder from the transport box, secure it against tipping with a strap loop on the side. See the following illustration. VEGASOURCE 81 • Source holder...
  • Page 16 Slowly lift the source holder upwards from the bottom plate using the lifting bands. Crane transport Use the lug of the source holder for transport on a crane hook. Fig. 9: Crane transport of the source holder VEGASOURCE 81 • Source holder...

  • Page 17: Shipment

    Transport of the loaded source holder is carried out by a company authorized by us, with official approval for such transports. The transport is carried out in a type A packaging (source holder) in compliance with the European and international convention on the transport of dangerous goods (ADR and DGR/IATA regulations). VEGASOURCE 81 • Source holder...

  • Page 18: Accessories

    For mounting on pipelines, there are corresponding clamp brackets. Contact our sales staff. Protective cap To protect the switching mechanism of the VEGASOURCE 81 from dirt or contamination, a metallic protective cap is available. This also allows the padlock to be permanently protected from dirt, moisture and corrosion.
  • Page 19 Any number of devices can be synchronized. To synchronize several gamma modulators, you need a controller. Set of labels There is a special label set for the source holder which can be or- dered as a spare part. VEGASOURCE 81 • Source holder...

  • Page 20: Mounting

    4 Mounting Mounting General instructions • General information For mounting of VEGASOURCE 81 you need a special handling permit. • Mounting may only be carried out by authorized, qualified person- nel who are monitored for radiation exposure according to local laws or the handling permit. Take note of the specifications in the handling permit. Also take the local conditions into account. • Carry out all work within the shortest possible time and at the larg- est possible distance.

  • Page 21: Mounting Instructions

    To do this you have to mount the source container so that the lugs are in a horizontal position. The source holder VEGASOURCE should be mounted as close as possible to the vessel. VEGASOURCE 81 • Source holder...
  • Page 22 In the case of bulk solids, the reaching of a limit level on a large container cross- section can be reliably detected. To do this, select the largest possible beam exit angle and mount the source holder rotated by 90°. VEGASOURCE 81 • Source holder...
  • Page 23 For pipeline diameters 50 … 100 mm (1.97 … 3.94 in), a diagonal radiation path is recommended. The distance of the beam through the medium is thus longer and an improved measuring effect is achieved. For this, the optional lead shielding for the detector is recommended in order to avoid influence from secondary radiation sources. VEGASOURCE 81 • Source holder...
  • Page 24 Vertical pipeline, diameter 50 … 420 mm (1.97 … 16.54 in) For pipeline diameters 50 … 420 mm (1.97 … 16.54 in), a straight radiation path is possible. The radiometric sensor can be mounted either horizontally or vertically. VEGASOURCE 81 • Source holder...
  • Page 25 Source holder (VEGASOURCE) Radiometric sensor (MINITRAC) Radiated area Mounting bracket Avoiding stray radiation - Vertical pipeline, diameter 50 … 420 mm (1.97 … 16.54 in) When mounting the radiometric sensor horizontally, the optional lead shielding is recommended in order to avoid influence from secondary radiation sources. VEGASOURCE 81 • Source holder...
  • Page 26 Mounting bracket Horizontal pipeline On a horizontal pipeline, the radiation should be directed horizontally to avoid interference from air pockets. Fig. 18: Measurement setup on a horizontal pipeline Source holder (VEGASOURCE) Radiated area Detector (MINITRAC) VEGASOURCE 81 • Source holder...
  • Page 27 Lock washers (2 pieces) Cover (optional) To protect the switching mechanism of the VEGASOURCE 81 from dirt or contamination, a metallic protective cap is available. This also allows the padlock to be permanently protected from dirt, moisture and corrosion.
  • Page 28 "Radioactive". The responsible radiation safety officer can allow access after having checked the safety measures with switched-off source holder. If work must be carried out in and on the vessel, it is absolutely neces- sary to switch off the radiation on the source holder. VEGASOURCE 81 • Source holder...

  • Page 29: Installation - Special Equipment

    Connect the ON/OFF position switches according to the following diagrams. Take note of the general installation regulations. As a rule, connect VEGASOURCE 81 to vessel ground (PA), or in case of plas- tic vessels, to the next ground potential. The data for power supply are specified in chapter " Technical data".
  • Page 30 ON/OFF position switch for switch position AUS - OFF (terminals 3 and 4) Switching amplifier For signal processing you need a NAMUR switching amplifier. We recommend the double channel switching amplifier VEGATOR 112. 5.1.2 Compressed air connection These instructions apply to source holders VEGASOURCE 81 Ver- sions B with pneumatic switchover. Note: The pneumatic switchover may only be put into operation after the source holder is mounted.

  • Page 31: Version X, C, B: Connection - Manual Switchover

    5 Installation - Special equipment Fig. 22: Connection of the pneumatic lines on VEGASOURCE 81 - version B 1 Ventilation filter/Sound absorber Voltage supply Voltage supply Terminal housing for connection of the ON/OFF position switches ON/OFF position switch for switch position AUS - OFF (terminals 3 and 4) ON/OFF position switch for switch position EIN - ON (terminals 1 and 2) ¾"...
  • Page 32 Connect the ON/OFF position switches according to the following diagrams. Take note of the general installation regulations. As a rule, connect VEGASOURCE 81 to vessel ground (PA), or in case of plas- tic vessels, to the next ground potential. The data for power supply are specified in chapter " Technical data".

  • Page 33: Setup

    (also not inside the vessel). Radiation must only be switched on by trained personnel. Switching the radiation The figures in brackets refer to the following illustration. Fig. 24: Switching the radiation on - VEGASOURCE 81 version X, C Loosen safety screw Fold up the safety screw Turn stirrup by 180°...
  • Page 34 Radiation ON ing status The marking arrow of the stirrup points to EIN - ON. Fig. 25: Radiation ON - VEGASOURCE 81 Version X, C Radiation OFF The marking arrow of the stirrup points to AUS - OFF Fig. 26: Radiation OFF - VEGASOURCE 81 Version X, C Switching the radiation Switching off the radiation is analogous to this procedure. To switch...

  • Page 35: Adjustment - Version B - Pneumatic Switchover

    6 Setup Fig. 27: Position indication with protective cap - VEGASOURCE 81 Version X, C Radiation OFF Radiation ON Version X With version X, the protective cap can be secured with a padlock in OFF position Version C With version C, the protective cap can be secured with a padlock in...
  • Page 36 6 Setup Fig. 28: Indication of the switching status with VEGASOURCE 81 - Version B - Pneumatic switchover Switching status AUS/OFF (symbol: closed padlock) Switching status EIN/ON (symbol: open padlock) • Remove padlock Note: The combination lock can be opened with the number combination 000 on delivery.
  • Page 37 Radiation OFF The operating lever is at the switching symbol AUS/OFF (closed padlock) Switching the radiation Analogue to this procedure, the radiation is switched off via the com- pressed air controls. When the pneumatic switchover is unpressurized, the VEGASOURCE 81 switches back automatically to switch position OFF. VEGASOURCE 81 • Source holder...

  • Page 38: Maintenance And Fault Rectification

    (µSv/h) must be measured in the surroundings. If the rate is clearly above the values during normal operation, then the area must be cordoned off and the responsible radiation safety officer informed. Corroded instruments and lock washers must be exchanged as soon as possible. Warning: Source containers with corroded locking device or source insert must be replaced immediately. VEGASOURCE 81 • Source holder...

  • Page 39: Test Of The Switchover

    Measure the local dose Measure the local dose rate of the source holder at regular intervals rate and document the measurement results. The measurement data allow conclusions to be drawn about leaks and possible changes in radiation power. VEGASOURCE 81 • Source holder...

  • Page 40: Tightness Test

    In such case, the tightness test must be prescribed by the responsible radiation safety officer under consideration of the ap- plicable regulations and comprise, apart from the source holder itself, all other affected parts of the process vessel. The tightness test must be carried out immediately after an incident. VEGASOURCE 81 • Source holder...
  • Page 41 185 Bq (5 nCi) are detected in the sample of the tightness test. Note: The specified value is valid for the USA. National regulations of other countries may prescribe other limit values. If the source is possibly leaky, carry out the following steps: • Inform the radiation safety officer VEGASOURCE 81 • Source holder...

  • Page 42: Rectify Faults

    24 hour service hotline For help with urgent technical problems, call the VEGA service hotline number +49 1805 858550. The hotline is manned 7 days a week round-the-clock. Since we offer this service worldwide, the support is only available in the English language.
  • Page 43 Informing the responsible Pass all necessary information immediately on to the responsible authority local and national authorities • After a thorough investigation of the situation on site, the respon- sible radiation safety officer must agree, together with the local authorities, on appropriate corrective measures for the existing problem Note: National regulations can prescribe deviating procedures and notifica- tion requirements. VEGASOURCE 81 • Source holder...

  • Page 44: Dismount

    Also inform the relevant authority. If a return in your country is not possible, contact the respective sales partner to decide on further action. The destination airport for a possible return shipment is Frankfurt a. M., Germany. VEGASOURCE 81 • Source holder...
  • Page 45 The return shipment must be made in a type-tested type A packaging in accordance with IATA rules. The source holder VEGASOURCE 81 is suitable for return shipment. In case of doubt, your sales partner will provide you with suitable transport packaging.

  • Page 46: Supplement

    = 1.2) Materials Ʋ Process fitting - Mounting surface 316L Ʋ Outer housing 316L or steel (1.0619) with PUR textured paint RAL 1018 Ʋ Tightness of the source insert Silicone Ʋ Shielding material Lead Ʋ Source holder 316L Ʋ Manual switching 316L Ʋ Pneumatic switching 316L VEGASOURCE 81 • Source holder...
  • Page 47 9 Supplement Materials - Device version X, C - Manual switchover Fig. 31: Materials VEGASOURCE 81 - Version X, C Position Component Material Locking screw 316L Collar screw 316L Rotary handle 1.4408 (CF8M) Closing plate 1.4408 (CF8M) Label - ON/OFF...
  • Page 48 9 Supplement Materials - Device version X, C - Manual switchover with ON/OFF position switches Fig. 32: Materials VEGASOURCE 81 - Version X, C - with ON/OFF position switches Position Component Material Locking screw 316L Collar screw 316L Safety screw - Torx with pin 316L Closing plate 1.4408 (CF8M)
  • Page 49 9 Supplement Materials - Device version X, C - Manual switchover with interlock switch Fig. 33: Materials VEGASOURCE 81 - Version X, C - with Interlock switch Position Component Material Housing - Interlock switch On site Screw On site On site Mounting plate...
  • Page 50 9 Supplement Materials - Housing version B - Pneumatic switchover Fig. 34: Materials VEGASOURCE 81 - Version B Position Component Material Bracket switching indication galvanized steel Screws 316L Cover Aluminium 3.3206 (AW 6063) Label - ON/OFF 316L Information label 316L Source holder 316L oder 1.0619...
  • Page 51 9 Supplement Materials - Device version B - Pneumatic switchover with ON/OFF position switches Fig. 35: Materials VEGASOURCE 81 - Version B - with ON/OFF position switches Position Component Material Bracket - Switching indication galvanized steel Screws 316L Cover Aluminium 3.3206 (AW 6063)
  • Page 52 The isodistance curve indicates the local dose rate at a certain distance from the surface of the source container. The following isodistance curve applies to a Cs-137 source as an example. The isodistance curve refers to the switching position OFF. VEGASOURCE 81 • Source holder...
  • Page 53 9 Supplement Dose rate diagram for Cs-137 Fig. 36: Dose rate diagram (distance: 1 m) - example: source holder VEGASOURCE 81 with Cs-137, 100 mCi (3.7 GBq) Distance: 1000 mm (39.4 in) Distance: 305 mm (12 in) Distance: 50 mm (2 in)

  • Page 54: Dimensions

    ø 114 mm (4.50") 152,4 mm 152,4 mm (6.00") (6.00") Fig. 37: Source holder VEGASOURCE 81, version X, C - Manual changeover Cover (optional) Free height for removal of the loading tube = 310 mm (12.21 in) Features • Stirrup for manual switching on/off •...
  • Page 55 152,4 mm 152,4 mm (6.00") (6.00") Fig. 38: Source holder VEGASOURCE 81, version X, C - Manual switchover with ON/OFF position switches Free height for removal of the loading tube = 335 mm (13.19 in) Features • ON/OFF position switch for signalling of the actual switching condition •...
  • Page 56 152,4 mm 152,4 mm (6.00") (6.00") Fig. 39: Source holder VEGASOURCE 81, version X, C - Manual switchover with Interlock switch Free height for removal of the loading tube = 335 mm (13.19 in) Features • Interlock safety switch for access control with active source •...
  • Page 57 (3.44") (11.16") 152,4 mm 152,4 mm (6.00") (6.00") Fig. 40: Source holder VEGASOURCE 81, version B - Pneumatic switching Free height for removal of the loading tube = 558 mm (21.97 in) Features • Facility for pneumatic switchover • Padlock for securing the switch position OFF...
  • Page 58 152,4 mm 152,4 mm (6.00") (6.00") Fig. 41: Source holder VEGASOURCE 81, version B - Pneumatic switchover with ON/OFF position switches Free height for removal of the loading tube = 558 mm (21.97 in) Features • Facility for pneumatic switchover •...
  • Page 59 9 Supplement VEGASOURCE 81, beam exit channel 53,6 mm (2.11") 158 mm (6.22") Fig. 42: Beam exit channel (e.g. version X, C) VEGASOURCE 81, base plate 76,2 mm (3.00") 127 mm (5.00") 152,4 mm (6.00") Fig. 43: Base plate with holes (e.g. version X, C)
  • Page 60 9 Supplement Gamma modulator (optional) ø 144 mm (5.67") 233 mm 160 mm (9.13") (6.30") Fig. 44: Gamma modulator for uninterrupted measurement even with X-ray radiation VEGASOURCE 81 • Source holder...
  • Page 61 Mounting brackets KV 31, for pipes from 50 … 220 mm (1.97 … 8.66 in) for 30° diagonal irradiation Fig. 45: Mounting brackets for diagonal mounting on pipes from 50 … 220 mm (1.97 … 8.66 in) VEGASOURCE 81 • Source holder...
  • Page 62 Mounting brackets KV 31, for pipes from 50 … 220 mm (1.97 … 8.66 in) Fig. 46: Mounting brackets for mounting on pipes from 50 … 220 mm (1.97 … 8.66 in) for 30° diagonal irradiation Source holder (VEGASOURCE) Radiometric sensor (MINITRAC) Radiated area Mounting bracket VEGASOURCE 81 • Source holder...
  • Page 63 Mounting brackets KV 31, for pipes from 50 … 220 mm (1.97 … 8.66 in) Fig. 47: Mounting brackets for mounting on pipes from 50 … 220 mm (1.97 … 8.66 in) Source holder (VEGASOURCE) Radiometric sensor (MINITRAC) Radiated area Mounting bracket VEGASOURCE 81 • Source holder...

  • Page 64: Manufacturer Declaration

    9 Supplement Manufacturer declaration VEGASOURCE 81 • Source holder...
