- Page 1 Operating Instructions Ball valve fitting PASVE for VEGABAR 82 Document ID: 30177...
-
Page 2: Table Of Contents
Exchange seals ......................15 How to proceed if a repair is necessary ................16 Dismount..........................17 Dismounting steps......................17 Disposal ......................... 17 Supplement ..........................18 Technical data ........................ 18 Dimensions ........................19 Editing status: 2021-05-07 Ball valve fitting PASVE • for VEGABAR 82... -
Page 3: About This Document
Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, note, tip: This symbol indicates helpful additional infor- mation and tips for successful work. -
Page 4: For Your Safety
Arbi- trary conversions or modifications are explicitly forbidden. For safety reasons, only the accessory specified by the manufacturer must be used. PASVE is a trade name of Satron Instruments Inc. Ball valve fitting PASVE • for VEGABAR 82... -
Page 5: Safety Label On The Instrument
The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" Ball valve fitting PASVE • for VEGABAR 82... -
Page 6: Product Description
This enables rinsing of the sensor diaphragm in the Service position without removing the sensor. Process side rinsing This version assumes that a rinsing connection is available. It ad- ditionally enables continuous rinsing of the sensor diaphragm in the Operation position. Ball valve fitting PASVE • for VEGABAR 82... -
Page 7: Principle Of Operation
Application area The ball valve fitting PASVE enables mounting or dismounting of the VEGABAR 82 pressure transmitter without the vessel having to be emptied or the pipeline depressurized. Depending on the version, the ball valve fitting PASVE is suitable for: •... -
Page 8: Packaging, Transport And Storage
Unless otherwise indicated, the packages must be stored only under the following conditions: • Not in the open • Dry and dust free • Not exposed to corrosive media • Protected against solar radiation Ball valve fitting PASVE • for VEGABAR 82... - Page 9 Technical data - Ambient conditions" • Relative humidity 20 … 85 % Lifting and carrying With instrument weights of more than 18 kg (39.68 lbs) suitable and approved equipment must be used for lifting and carrying. Ball valve fitting PASVE • for VEGABAR 82...
-
Page 10: Mounting
Chemical properties of the medium • Abrasion and mechanical influences Mounting instructions The Standard version is mounted vertically, the ventilation/dehydra- Mounting arrangement tion points downward. The movement of the swivelling and locking level is also vertical. Ball valve fitting PASVE • for VEGABAR 82... - Page 11 Fig. 5: Mounting configuration for the version with rinsing air connection Rinsing water input Rinsing water output Welding Note the following drawing for welding: Ball valve fitting PASVE • for VEGABAR 82...
-
Page 12: Handling
The swivelling and locking lever is moved with the handle and locked with the catch. Fig. 7: Handling of the ball valve fitting PASVE Handle Release ring Catch Operation Service Cleaning Mount pressure transmitter Proceed as follows: Ball valve fitting PASVE • for VEGABAR 82... -
Page 13: Dismount Pressure Transmitter
4. Unscrew the pressure transmitter 5. Bring the ball valve into the " Cleaning" position. The measure- ment aperture on the process side is now visible. 6. Clean the opening with a suitable water jet. Ball valve fitting PASVE • for VEGABAR 82... - Page 14 10. Turn handle 3½ turns to the right so that the catch is locked again Caution: We recommend you to pull off the handle after locking the catch. This protects the fitting against unauthorised access. Ball valve fitting PASVE • for VEGABAR 82...
-
Page 15: Maintenance And Fault Rectification
24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is manned 7 days a week round-the-clock. Since we offer this service worldwide, the support is only available in the English language. -
Page 16: How To Proceed If A Repair Is Necessary
Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Ask the agency serving you to get the address for the return ship- ment. You can find the agency on our homepage. Ball valve fitting PASVE • for VEGABAR 82... -
Page 17: Dismount
Materials: see chapter " Technical data" If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. Ball valve fitting PASVE • for VEGABAR 82... -
Page 18: Supplement
The lowest possible temperature value is valid. Operating pressure max. 40 bar Note nominal pressure of the pressure transmitter and temperature derating of the flange. The lowest permis- sible operating pressure is applicable. Ball valve fitting PASVE • for VEGABAR 82... -
Page 19: Dimensions
" " " " " " JIS 10K 80 " " " JIS 40K 80 Fig. 8: Ball valve fitting PASVE With compression flange For welding to vessels For welding to pipelines Ball valve fitting PASVE • for VEGABAR 82... - Page 20 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2021 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
