Chester
Assembly Instructions
Dimensions
Width - 120cm
Depth - 50cm
Height - 74,3cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call t h e C u stomer Helpline: 03456 400 800.
-
Solid Pine Desk
- Please keep for future reference
389/6400
418/8124
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 389/6400
Summary of Contents for Argos 389/6400
- Page 1 Chester Solid Pine Desk Assembly Instructions - Please keep for future reference 389/6400 418/8124 Dimensions Width - 120cm Depth - 50cm Height - 74,3cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call t h e C u stomer Helpline: 03456 400 800.
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly This product has been produced We do not Check you have all the components and tools listed on from natural timber; you may recommend the notice some variation in the grain use of power pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below 2 Right side panel Top panel (120 x 50cm) (72,5 x 46,9cm) Right front frame (72,5 x 4,6cm) Left front frame (72,5 x 4,6cm) 3 Division (72,5 x 45,8cm) Left side panel (72,5 x 45,8cm) Top front frame...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Insert dowels into the indicated parts. (4x) (2x) (2x) (2x) Step 2 Fixing runners. Attach side drawer runners to division using screws Attach side drawer runners to left side panel using screws Attach brackets through pre drilled holes on left side panel and division using screws...
- Page 6 Assembly Instructions Step 3 (3x) Fixing left front frame Yes! to the left side panel (Two people required for an easier assembly) Insert left front frame into left side panel through joints. Note: Before fixing brakets into place it is important to ensure that the slot and groove of parts are fully pushed...
- Page 7 Assembly Instructions Step 5 Attention: Attach small back rail top front frame bottom front frame left side panel using screws Fit middle front frame to left front frame Make sure panels are correctly positioned as shown in the diagram. Step 6 Fixing the division Two people are required for an easier assembly.
- Page 8 Assembly Instructions Step 7 Fixing top panel Two people are required for an easier assembly. Caution: Carefully lay the top panel on a soft and clean surface to avoid damaging the product. Attach assembled frame to the top panel using screws Note correct position of parts as shown.
- Page 9 Assembly Instructions Step 9 Two people are required for an easier assembly. Fit back panels division and right side panel to top panel as shown. Then, fix the parts using screws Step 10 Fixing back panel. Important: Desk MUST square when back panel is attached.
- Page 10 Assembly Instructions Step 11 Drawer assembly. Attachdrawer sides to the drawer usingscrews front slide drawer bottom into slots on drawer sides attach drawer back using screws Using screw attach the drawer handle (2X) the drawer front. Repeat step 11 to the other drawer.
