NEW COMBINE PRODUCT SUPPORT KITS
Heavy-duty Rotor Drive Gear Box Kit
• For 2388 model year 2003-2005
• Kit includes heavy-duty gear box, mounting brackets, new style rotor drive belt,
and hardware
• Wider and larger diameter gears for increased strength and durability
• Increased reliability
Power-Clean™ Evacuation System
Two new kits are now available to substantially reduce the cleaning requirements
of the rotary air screen (RAS), radiators, coolers, and engine air cleaners.
Rotary Air Screen Metal Conversion and Vacuum Kit
• Minimizes the chances of the RAS plugging from crop debris (corn leaf,
corn sucrose mist, and fine/sticky dust)
• Reduces the cleaning requirements of the RAS, radiator, coolers, and engine
air cleaner
• Kit includes metal RAS, hydraulic driven vacuum components, hoses, mounting
brackets, outlet ducts for debris, mounting hardware, and instruction manual
Spring Loaded Rotary Air Brush Kit
• Cleans the interior of the RAS to dislodge any debris stuck to the rotary air screen
• Reduces the cleaning requirements of the RAS, radiator, coolers, and engine air cleaner
• Kit includes rotary air brush assembly, stationary brush, mounting hardware,
and instruction manual
Part No. 87362263 RAS Metal Conversion and Vacuum Kit for 2377 and 2388 Combines
Part No. 87382753 Rotary Brush Kit for 2377 and 2388 Combines
Sieve Kit
• Original equipment sieves
• Kit includes sieve with installed rubber flaps,
seals, wire harness, and grain loss sensor
with brackets
• Complete – ready to install
• Application – 1680 with long sieves and later
• Selection – 80 size combines
34
Part No. 87397334
Part No. 87362263
Metal Rotary Air Screen
Part No. 87382753
Rotary Brush
Part No. 1347372C7E – Chaffer – Petersen
Part No. 1322467C6E – Chaffer – 1-1/8" Grain
Part No. 1322659C6E – Chaffer – 1-5/8" Corn
Part No. 1322673C6E – Chaffer – 1-5/8" Closz slat
Part No. 1979328C8E – Shoe – 1-5/8" Corn
Part No. 1322464C7E – Shoe – 1-1/8" Grain
