Unloading Auger Support Band and Strap
A revised unloading tube strap assembly has been released for
208" unloading augers for 2366, 2377, and 2388 combines
(see figure 27.1).
• The new band provides additional strength at the transport
saddle area of the tube; this supports the weight of the
auger when grain remains in the tube while the auger is in
the transport position.
• Case IH dealers can provide additional information, and can
reference Service Bulletin NHE SB 028 05
Poor Grain Tank Sample or Excessive Losses in High
Volume/Moisture Crops
For 2100 and 2300 series combines that are equipped with
the slower cleaning system speed, it may be too slow for these
crop conditions. A speed-up pulley is released for production
and service.
Unloading System Shear Bolts
Do not substitute unknown bolts for the unloading system
shear bolts. Incorrect bolts can cause extensive damage to
the system.
Field Tracker Field Operation in Automatic Mode
A Service Bulletin has been released with information to aid
in a better understanding and operation of the field tracker
in the automatic mode while using a 1020 header or 1000
series corn head. For more information, contact your Case IH
dealer.
Bring Your AXIAL-FLOW Combine Up-to-Date for
Increased Productivity and Profitability
Many improvements have been made in Case IH combines over
the years. You'll want to check with your Case IH dealer to see
which of the following optional equipment or improvements
can be incorporated in your combine to help you harvest your
crops more efficiently.

UPDATES AND KITS

• Heavy-duty Lower Feeder Jackshaft
• Cross Flow™ Fan Package Retrofit
• Shaker System Slip Clutch Drive Hub
• Extended Life Augers
• Spreading Width Options
• High-Wear Rasp Bars for Specialty Rotors
• External Straw Chopper Adapter Kit
• External Sieve Adjustment Kit
• AFX Rotor and Recommended Product Support Kits
• Fifty-two (52) Hole Configuration Cones
• Cone Kits for 52 Hole Cones
• Larger Rotor Drive Pulley Kit for 2388 Combines
• Poly Hoods, Divider Kits, and Completing Kits
Bring Your Older Corn Head Up-to-Date
Case IH engineers spend every harvesting season in the field
searching for ways to improve AXIAL-FLOW combines and corn
heads. Your local Case IH dealer can assist you with optional
Figure 27.1
equipment and improvements will help make your machine
operate more efficiently.
• Stalk Roll Spiral Assemblies
• Field Tracker Drive Shaft and Bearing Support
• Lower Stalk Roll Bearing Shield
• Auger Trough Material Thickness
• Stalk Roll Weed Knives
• Gatherer Rear and Side Extensions
• Auger Slip Clutch
• Stalk Roll Lower Bearings (see figure 27.2)
for positive mounting and removal.
New lower bearings feature a full
3/4" shaft with flat and pilot holes
Figure 27.2
