NEW COMBINE PRODUCT SUPPORT KITS
Part No. 87298864
EZ Latch Single Level Hydraulic Coupler Kit
• Kit includes coupler assembly, hydraulic lines, and hardware
• Kit is designed to make it easier to connect the hydraulics on the
combine to the header
• Coupler for 1010/1020 Headers, 2200 Corn Heads, and mid-range
Axial Flow Combines
• Combine these kits with the centralized header latch kit for even
greater convenience
Part No. 87552504 - coupler half for 1000 Series Headers
Part No. 87301386E - coupler half for 1644, 1666, 1688, and later combines
Part No. 87662931E - coupler half for 2200 Corn Head
Not New But Improved
• The material thickness on these elbows
and vertical tubes have been increased
by 30% for improved service life
• HVOF wear resistant coating included
with Part No. B96190A–extended
wear elbow
• The elbow grease ring groove has been
modified to provide more uniform
grease flow and improved service life
Grease lines and mounting hardware
included but not shown.
New Style Header Auger Finger Kits
• For 2006-2007, Model 2010 and 2020 Grain Headers
• Long wearing heat treated auger finger and hardware
Part No. 87298864 - complete set - 30' Header (shown)
Part No. 87298865 - complete set - 25' Header
Part No. 87298860 - complete set - 20' Header
Part No. 87298867C - two pack kit
Part No. 87298954C - deluxe finger kit
Connected Couplers
Part No. B94090A - standard wear
Part No. B96190A - extenda-wear
Heavy-duty Unloading Auger Elbow
Part No. B95650A
Heavy-Duty Vertical Tube
