NEW COMBINE PRODUCT SUPPORT KITS
Part No. 87535919
• This kit mounts to the left side of the
feeder and has cables that connect to
a pair of engagement pins that latch the
header to the combine
• Combine kit includes cables, handle
guards, springs, hardware, and I-sheet
• Header kits include engagement pins
and mounting hardware
• These kits are designed to make it easier
to attach various Case IH headers to
Case IH Combines
Part No. 87298938
Part No. 87561634
Grain Tank Unloading Speed-up Kit
• Faster unloading speeds for mid-range combines
• Kit includes sprockets, chain assemblies, mounting supports, bearings,
and hardware
• Drive chains increased one size to improve load capacity and chain life
• Kit is designed to increase unloading rates from 1.9 Bu/sec to 2.4 Bu/sec
like the new 2577/2588 combines
Part No. 87539791 -
Combines with field tracker (shown)
Part No. 87539793 -
Combines without field tracker
Round Bar Concave Kit
• Kit consists of one 87456655 - Position 1 (shown) and two 412396A1 -
Position 2 and 3
• One piece high strength design
• The round bars function to prevent silks or husks from hair pinning on the
bars/wires in high moisture corn
• Concaves also have large wires that run 90 degrees to the round bars for
soybean harvesting
Stainless Steel Auger Trough Wear Liner Kit
• Kit includes two stainless steel grain tank auger liners and 70 stainless steel
pop rivets
• Restore life to a worn tank bottom or protect new tanks from wear. The liners
slip under the grain tank cross augers. Drill holes and pop rivets in place.
• For all mid-range Axial-Flow
Part No. 87336803 - 1010/1020 Header (shown)
Part No. 87337673 - 2200/2400 Corn Head
Part No. 87352570 - 1015 Pick-up Header
Part No. 87352569 - 1000 Corn Heads
Part No. 87368703 - 2015 Pick-up Header
Combines
®
