treesse Shadow Installation Manual page 11

Installation
PREPARATION OF CONNECTION TO AN "SPA PACK" EXTERNAL (OPTIONAL)
The circulator must be in-
IN:
stalled according to the cha-
racteristics of the domestic
OUT: outgoing
system (prevalence, length,
etc.) and the water content
(in litres) of the mini-pool.
F
230V
Circulator control cable
OUT:
outgoing water
IN:
incoming water
Room for
the electrical
connections
O U
T
I N
incoming
water
water
Drain
PR
PR: recirculation pump
F:
filter
C:
control unit
EN
IN
OUT
Technical
inspection
port
C
IN
230V
11
Shadow
minipool
Inlet connection:
1 "1/4 female - socket
Outlet connection:
1 "1/4 female - socket
CP
