treesse Shadow Installation Manual page 10

Installation
PREPARATION OF CONNECTION TO AN OPTIONAL EXTERNAL EXCHANGER (NOT SUPPLIED)
The Exchanger
is the device with
which domestic
water is heated
(in this manual
represented by a
boiler connected
to the solar
panels)
Circulator
(not supplied)
The circulator must be in-
stalled according to the cha-
racteristics of the domestic
system (prevalence, length,
etc.) and the water content
(in litres) of the mini-pool.
EV
S
230V
heater/exchanger control cable
C:
switch (recommended)
OUT:
outgoing cold water
Room for
the electrical
connections
I N
O U
T
IN:
incoming
hot domestic
water
OUT: outgoing cold
water
in
P
out
C
P:
circulator (not supplied)
PR: recirculation pump
S:
exchanger (not supplied)
EN
IN
OUT
Drain
Technical
inspection
port
P2
BL 1
BL2
Cromo
230V~
230V
10
Shadow
minipool
Inlet connection:
1 "1/4 female - socket
Outlet connection:
1 "1/4 female - socket
I N
EVc
PR
HTR
J48 J49
If you don't need to
heater, disconnect plug
J44
+ -
EVs EVclv
